SICK ReLy TIME1 Manuale utente
OPERATING INSTRUCTIONS
ReLy TIME1
Safety relay
Described product
ReLy TIME1
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 8024303/1FH0/2022-10-27 | SICK
Subject to change without notice
Contents
1 About this document........................................................................ 5
1.1 Purpose of this document........................................................................ 5
1.2 Scope......................................................................................................... 5
1.3 Target groups of these operating instructions........................................ 5
1.4 Additional information.............................................................................. 5
1.5 Symbols and document conventions...................................................... 6
2 Safety information............................................................................ 7
2.1 General safety notes................................................................................ 7
2.2 Intended use............................................................................................. 7
2.3 Inappropriate use..................................................................................... 8
2.4 Requirements for the qualification of personnel.................................... 8
3 Product description........................................................................... 9
3.1 Device overview........................................................................................ 9
3.2 Structure and function............................................................................. 9
3.3 Product characteristics............................................................................ 9
3.3.1 Interfaces................................................................................. 9
3.3.2 Compatible sensor types......................................................... 10
3.3.3 Release-delayed enabling current paths................................ 10
3.3.4 Restart interlock...................................................................... 10
3.3.5 External device monitoring...................................................... 10
3.3.6 Cross-circuit detection............................................................. 10
3.3.7 Status indicators...................................................................... 11
4 Project planning................................................................................ 12
4.1 Manufacturer of the machine.................................................................. 12
4.2 Operating entity of the machine.............................................................. 12
4.3 Design........................................................................................................ 12
4.4 Electrical integration................................................................................. 13
4.4.1 Voltage supply.......................................................................... 13
4.4.2 Enabling current paths............................................................ 14
4.4.3 Application diagnostic output................................................. 14
4.4.4 Restart interlock...................................................................... 15
4.4.5 External device monitoring (EDM).......................................... 15
4.4.6 Connection diagrams.............................................................. 16
4.5 Testing plan............................................................................................... 16
4.5.1 Planning the thorough check during commissioning and in
certain situations..................................................................... 16
4.5.2 Planning the regular thorough check..................................... 17
5 Mounting............................................................................................. 18
5.1 Mounting procedure................................................................................. 18
5.2 Disassembly.............................................................................................. 19
CONTENTS
8024303/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 3
Subject to change without notice
5.3 Module exchange...................................................................................... 19
6 Electrical installation........................................................................ 21
6.1 Device connection.................................................................................... 21
7 Configuration..................................................................................... 24
7.1 DIP switch.................................................................................................. 24
7.2 Configuring release delay......................................................................... 24
7.3 Configuring sensor type........................................................................... 25
7.4 Activating configuration............................................................................ 26
7.5 Resetting the configuration...................................................................... 26
8 Commissioning.................................................................................. 27
8.1 Safety......................................................................................................... 27
8.2 Check during commissioning and modifications.................................... 27
9 Troubleshooting................................................................................. 28
9.1 Safety......................................................................................................... 28
9.2 Status indicator (LED)............................................................................... 28
10 Decommissioning............................................................................. 30
10.1 Disposal..................................................................................................... 30
11 Technical data.................................................................................... 31
11.1 Data sheet................................................................................................. 31
11.2 Dimensional drawings.............................................................................. 38
11.3 Internal circuitry........................................................................................ 38
12 Ordering information........................................................................ 39
12.1 Ordering information for ReLy.................................................................. 39
13 Annex.................................................................................................. 40
13.1 Conformities and certificates................................................................... 40
13.1.1 EU declaration of conformity................................................... 40
14 List of figures..................................................................................... 41
15 List of tables....................................................................................... 42
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 8024303/1FH0/2022-10-27 | SICK
Subject to change without notice
1 About this document
1.1 Purpose of this document
These operating instructions contain the information required during the life cycle of the
safety relay.
These operating instructions must be made available to everyone who works with the
safety relay.
1.2 Scope
Product
This document applies to the following products:
•Product code: ReLy TIME1
•“Operating instructions” type label entry: 8024299
Document identification
Document part number:
•This document: 8024303
•Available language versions of this document: 8024299
You can find the current version of all documents at www.sick.com.
1.3 Target groups of these operating instructions
Some sections of these operating instructions are intended for certain target groups.
However, the entire operating instructions are relevant for intended use of the product.
Table 1: Target groups and selected sections of these operating instructions
Target group Sections of these operating instructions
Project developers (planners, developers,
designers)
"Project planning", page 12
"Configuration", page 24
"Technical data", page 31
Installers "Mounting", page 18
Electricians "Electrical installation", page 21
Safety experts (such as CE authorized repre‐
sentatives, compliance officers, people who
test and approve the application)
"Project planning", page 12
"Configuration", page 24
"Commissioning", page 27
"Technical data", page 31
Operators "Troubleshooting", page 28
Maintenance personnel "Troubleshooting", page 28
1.4 Additional information
www.sick.com
The following information is available on the Internet:
•Data sheets and application examples
•CAD data and dimensional drawings
•Certificates (e.g. EU declaration of conformity)
•Guide for Safe Machinery Six steps to a safe machine
ABOUT THIS DOCUMENT 1
8024303/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 5
Subject to change without notice
1.5 Symbols and document conventions
The following symbols and conventions are used in this document:
Safety notes and other notes
DANGER
Indicates a situation presenting imminent danger, which will lead to death or serious
injuries if not prevented.
WARNING
Indicates a situation presenting possible danger, which may lead to death or serious
injuries if not prevented.
CAUTION
Indicates a situation presenting possible danger, which may lead to moderate or minor
injuries if not prevented.
NOTICE
Indicates a situation presenting possible danger, which may lead to property damage if
not prevented.
NOTE
Indicates useful tips and recommendations.
Instructions to action
bThe arrow denotes instructions to action.
1. The sequence of instructions for action is numbered.
2. Follow the order in which the numbered instructions are given.
✓The check mark denotes the result of an instruction.
LED symbols
These symbols indicate the status of an LED:
oThe LED is off.
ÖThe LED is flashing.
OThe LED is illuminated continuously.
1 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 8024303/1FH0/2022-10-27 | SICK
Subject to change without notice
2 Safety information
2.1 General safety notes
Product integration
DANGER
The product can not offer the expected protection if it is integrated incorrectly.
bPlan the integration of the product in accordance with the machine requirements
(project planning).
bImplement the integration of the product in accordance with the project planning.
Mounting and electrical installation
DANGER
Death or severe injury due to electrical voltage and/or an unexpected startup of the
machine
bMake sure that the machine is (and remains) disconnected from the voltage
supply during mounting and electrical installation.
bMake sure that the dangerous state of the machine is and remains switched off.
Repairs and modifications
DANGER
Improper work on the product
A modified product may not offer the expected protection if it is integrated incorrectly.
bApart from the procedures described in this document, do not repair, open, manip‐
ulate or otherwise modify the product.
2.2 Intended use
The safety relay is an evaluation unit device for switching safety-related circuits on and
off for the following sensor types:
•Electro-mechanical switch/safety switch (EMSS)
•Safety sensors with monitored semiconductor output (OSSD)
The safety relay complies with class A, group 1 as per EN 55011. Group 1 encom‐
passes all ISM devices in which intentionally generated and/or used conductor-bound
RF energy that is required for the inner function of the device itself occurs.
The product may be used in safety functions.
The product must only be used within the limits of the prescribed and specified techni‐
cal specifications and operating conditions at all times.
Incorrect use, improper modification or manipulation of the product will invalidate any
warranty from SICK; in addition, any responsibility and liability of SICK for damage and
secondary damage caused by this is excluded.
UL/CSA applications
If the product is being used in accordance with UL 508 or CSA C22.2 No.14, the
following conditions must also be met:
•To protect the device’s 24-volt voltage supply, use a fuse with a maximum voltage
of 4A and a minimum of 30VDC in accordance with UL248.
SAFETY INFORMATION 2
8024303/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 7
Subject to change without notice
NOTE
The safety functions have not be evaluated by UL. Authorization is in accordance with
UL 508, general applications.
2.3 Inappropriate use
The safety relay is not suitable for the following applications (this list is not exhaustive):
•At altitudes of over 4,000m above sea level
•In explosion-hazardous areas
2.4 Requirements for the qualification of personnel
The product must be configured, installed, connected, commissioned, and serviced by
qualified safety personnel only.
Project planning
You need safety expertise to implement safety functions and select suitable products
for that purpose. You need expert knowledge of the applicable standards and regula‐
tions.
Mounting, electrical installation and commissioning
You need suitable expertise and experience. You must be able to assess if the machine
is operating safely.
Configuration
You need suitable expertise and experience. You must be able to assess if the machine
is operating safely.
Operation and maintenance
You need suitable expertise and experience. You must be instructed in machine oper‐
ation by the machine operator. For maintenance, you must be able to assess if the
machine is operating safely.
2 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 8024303/1FH0/2022-10-27 | SICK
Subject to change without notice
3 Product description
3.1 Device overview
RELY
PWR
OUT
13
23
I1
Y1
14
24
I2
Y2
A2
S1
37
A1
38
X1 X2
R1
1
2
3
4
Figure 1: Device overview
1Device unlocking
2LEDs
3Front connector unlocking
4Front connector
3.2 Structure and function
The safety relay ReLy TIME1 is an electrical switching device with inputs and outputs.
The safety capable inputs of the safety relay are connected to safety sensors or safety
switches.
2 safety capable inputs control the internal relays, which are used to reliably switch the
enabling current paths.
The enabling current paths close only when the two safety capable inputs close within
3s of one another.
At the enabling current paths it is possible to connect, for example, actuators with
positively guided contacts.
Opening the input circuit causes the two enabling current paths to open immediately
and for the release-delayed enabling current path to open after a delay. The delay time
is adjustable.
3.3 Product characteristics
3.3.1 Interfaces
Inputs
•2 safety capable inputs
•Input for reset pushbutton or external device monitoring
PRODUCT DESCRIPTION 3
8024303/1FH0/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 9
Subject to change without notice
Outputs
•2 enabling current paths (safe)
•1 enabling current path for stop category 1 applications (safe)
•2 application diagnostic outputs (not safe)
•3 test outputs (not safe)
3.3.2 Compatible sensor types
Table 2: Compatible sensor types
Sensor type Description Examples
Electro-mechanical
switch/safety switch
(EMSS)
EMSS Dual-channel equivalent electro-
mechanical switch/safety switch
with contacts and without signal
processing unit
•Emergency stop push‐
button
•Safety door limit switch
Safety sensors with
monitored semicon‐
ductor output (OSSD)
OSSD Safety sensors with dual-chan‐
nel cross-circuit monitored semi-
conductor outputs
•Transponder safety
switch e.g., Sistra
•Safety light curtains,
e.g. deTec4
•Safety laser scanner,
e.g., microScan3, nano‐
Scan3
Further topics
•"Configuring sensor type", page 25
3.3.3 Release-delayed enabling current paths
The release-delayed enabling current path opens with a set delay time.
3.3.4 Restart interlock
A restart interlock can be implemented with a reset pushbutton.
3.3.5 External device monitoring
Permanent external device monitoring can be implemented using external wiring.
3.3.6 Cross-circuit detection
A cross-circuit is detected on the safety inputs if the “EMSS” sensor type is configured.
Further topics
•"Configuring sensor type", page 25
3 PRODUCT DESCRIPTION
10 O P E R A T I N G I N S T R U C T I O N S | ReLy TIME1 8024303/1FH0/2022-10-27 | SICK
Subject to change without notice
Altri manuali per ReLy TIME1
1
Indice
Altri manuali SICK Staffetta
SICK
SICK ReLy OSSD4 Manuale utente
SICK
SICK ReLy LOOP1 Manuale utente
SICK
SICK ReLy TIME1 Manuale utente
SICK
SICK ReLy EMSS1 Manuale utente
SICK
SICK ReLy OSSD1 Manuale utente
SICK
SICK ReLy LOOP1 Manuale utente
SICK
SICK ReLy OSSD1 Manuale utente
SICK
SICK ReLy MULT1 Manuale utente
SICK
SICK ReLy HAND1 Manuale utente
SICK
SICK ReLy OSSD2 Manuale utente
