Sigma NUGGET II Manuale utente
ca. 2 h
1 x click = on
+ 1 x click = off
ON/OFF
unten/bottom
30 % 70 %
BATTERIESTATUS/
BATTERY CONTROL
oben/top
Wenn die LED leuchtet,
dann umgehend
aufladen!/
If light appears,
please charge!
oben/top
Nach dem Ladevorgang
erlöschen beide
Indikatoren./
Both indicators will go
out after charging
oben/top
90°
17°
90°
NUGGET II MONTAGE / MOUNTING AUSRICHTUNG/ALIGNMENT
LADEVORGANG /CHARGINGMODUS /MODE
Achten Sie bitte darauf, dass die Abdichtung stets korrekt verschlossen ist/
Please always keep the silicone plug closed after charging.
2
1
Die Lichtverteilung darf nicht verdeckt sein!/
Do not cover the rear light!
Abschlussseite der Schlussleuchte senkrecht zur Fahrbahn und rechtwinklig
zur Fahrzeugmittelachse / Final side of the tail lamp perpendicular to the
roadway and at right angles to the vehicle center axis
Fahrzeug-
mittelachse/
Vehicle
center axis
5 V / 500 -
1000 mA
Micro
158050-1_Manual_NUGGET II.indd 1 26.01.2017 15:37:40
CHARGING
CABLE
INSIDE
MICRO USB KABEL
CHARGING CABLE MICRO-USB
ZUBEHÖR / ACCESSORIES
Art.-Nr. 18553
ZUBEHÖR / ACCESSORIES
LADEGERÄT + MICRO USB KABEL
CHARGER + CHARGING CABLE MICRO-USB
LIGHTING SYSTEMS TOPLINE
NUGGET II
SIGMA-ELEKTRO GmbH
Dr.-Julius-Leber-Straße 15
D-67433 Neustadt / Weinstraße
SIGMA SPORT ASIA
4 F, No.192, Zhonggong 2nd Rd.,
Xitun Dist., Taichung City 407, Taiwan
SIGMA SPORT USA
1860B Dean St.
St. Charles, IL 60174, U.S.A.
158050/1
Art.-Nr. 18552
158050-1_Manual_NUGGET II.indd 2 26.01.2017 15:37:42
