1
CyberParallel Dual
Quick Installation Guide
04-0328B
Introducing the CyberParallel Dual
The CyberParallel Dual is a high-speed parallel I/O card
for parallel device connections. It provides 2 ECP/EPP
parallel ports which support data transfer rates up to
1.5 MB/sec.
FeaturesandBenefits
•Conforms to PCI v2.2 Plug and Play
•Can be installed in 32-/64-bit, 3.3v/5v PCI and
PCI-X slots
•Full support for DOS and Windows based software
•PCI IRQ sharing feature reduces IRQ conflicts
• Compliant with IEEE 1284-1994 parallel port
standard
• Works with various types of parallel port devices
including printers, removable drives, scanners,
CD-R/RWs, and more
• Supports ECP/EPP, Bi-directional Parallel Port
(PS2) and Standard Parallel Port (SPP) modes
SystemRequirements
•Pentium or equivalent computer with an available
PCI slot
•DOS, Windows 95/98/98 SE/ME/NT 4.0/2000/
XP/Server 2003
2
PackageContents
• (1)CyberParallelDualboard
• (1) Driver CD
• (1) DB25 parallel port cable (for 2nd parallel port)
• This quick installation guide
BoardLayout
Figure 1. Cyber Parallel Dual layout
*Note: When connecting the DB25 parallel port
cable to Parallel Port 2 (P2), position the ribbon
cable so the colored stripe is on the side closest to
the slot bracket.
Parallel Port 1
(P1)
Parallel Port 2
(P2)*
3
Hardware Installation
General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer’s reference
manual for further information, if needed.
Caution: Static Electricity Discharge may permanently
damage your system. To avoid possible static electricity
discharge during the installation, please follow the
guidelines below:
•Discharge any static electricity build up in your
bodybytouchingalargegroundedmetalsurfaceor
the computer’s case (if plugged in), for a few
seconds.
•During the installation, avoid any contact with
internal parts. Handle cards only by their external
edges.
1. Turn OFF the power to your computer.
2. Unplugthepowercordandremoveyourcomputer's
cover.
3. Remove the slot bracket from an available PCI slot.
4. CarefullyalignthecardtotheselectedPCIslotpush
the board down firmly, but gently, until it is well
seated.
5. Replace the slot bracket's holding screw to secure
the card.
6. Replacethecomputercoverandreconnectthepower
cord.
4
Figure 2. Inserting the PCI Board
Software Installation
This section provides the steps on how to install the
CyberParallel Dual drivers. Please make sure the board is
installed before proceeding with the driver installation.
Windows95DriverInstallation
1. At the Update Device Driver Wizard, click Next.
2. Insert the driver CD and click Other Locations.
3. Type in X:\2P\95, click OK, then click Finish.
(Change X: to match your CD-ROM drive letter)
4. From the Insert Disk window, click OK. When the
CopyingFilesdialogboxappears,typeinX:\2P\95,
then click OK. (Change X: to match your CD-ROM
drive letter)
5. RestartWindowstocompletethedriverinstallation.
5
Windows98/98SEDriverInstallation
1. At the Add New Hardware Wizard, click Next.
2. Select Search for the best driver for your device
(Recommended), then click Next.
3. Select Specify a location, uncheck the other boxes,
insert the driver CD, type in X:\2P\98, then click
Next. (Change X: to match your CD-ROM drive
letter)
4. Click Next, then Finish.
5. RestartWindowstocompletethedriverinstallation.
WindowsMEDriverInstallation
1. AttheAddNewHardwareWizard,chooseSpecify
the location of the driver (Advanced), then click
Next.
2. Check Specify a location, uncheck the other box,
insert the driver CD, type in X:\2P\ME, then click
Next. (Change X: to match your CD-ROM drive
letter)
3. Click Next, then Finish.
4. RestartWindowstocompletethedriverinstallation.
WindowsNT4.0DriverInstallation
1 From the desktop, click Start,then Run.
2. Insert the driver CD, type X:\2P\NT4\setup.exe,
then click OK. (Change X: to match your CD-ROM
drive letter)
3. At the Welcome window, click Continue.
4. Atthe Multi-IODriversSetupwindow,clickNext.
5. SelectYesandclickFinishtorestartNTtocomplete
the driver installation.
6
Windows2000DriverInstallation
1. At the Found New Hardware Wizard, click Next.
2. Select Search for a suitable driver for my device
(Recommended), then click Next.
3. SelectSpecifythelocation,unchecktheotherboxes,
then click Next.
4. Insert the driver CD, type in X:\2P\2000, then click
OK. (Change X: to match your CD-ROM drive
letter)
5. Click Next, then click Finish to complete the driver
installation.
WindowsXPDriverInstallation
1. AttheFoundNewHardwareWizard,chooseInstall
from a list or specific location (Advanced), then
click Next.
2. Insert the driver CD, check Include this location in
thesearch,unchecktheotherbox,typeinX:\2P\XP,
thenclickNext. (ChangeX:tomatchyourCD-ROM
drive letter)
3. At the Hardware Installation window, click
ContinueAnyway,thenclickFinish. Ourdriverhas
beenthoroughlytestedforstabilityandcompatibility.
4. Repeat steps 1-3 two more times.
5. Restart your system for the new setup to take effect.
WindowsServer2003DriverInstallation
1. AttheFoundNewHardwareWizard,chooseInstall
from a list or specific location (Advanced), then
click Next.
7
2. Insert the driver CD, check Include this location in
the search, uncheck the other box, type in
X:\2P\2003, then click Next. (Change X: to match
your CD-ROM drive letter)
3. At the Hardware Installation window, click
ContinueAnyway,thenclickFinish. Ourdriverhas
beenthoroughlytestedforstabilityandcompatibility.
4. Repeat steps 1-3 two more times.
5. Restart your system for the new setup to take effect.
DOSDriverInstallation
1. Insert the driver CD. From the C:\> prompt, type
copy X:\2P\dos\*.*,and press <Enter>. (Change
X: to match your CD-ROM drive letter)
2. Type edit autoexec.bat, and press <Enter>.
3. Add C:\nmdosin.exe -a at the bottom of the
autoexec.bat file.
4. Go to File, save the changes and exit.
5. Restart your system for the new setup to take effect.
VerifyProperWindowsDriverInstallation
For Windows 95/98/98SE/ME:
1. Right click My Computer, click Properties, click
Device Manager.
2. Double click NetMosMultiFunction, NetMos
PCI...Controller should be listed.
3. Doubleclick Ports(COM&LPT),twoNetMosPCI
Parallel Ports should be listed.
8
For Windows NT 4.0:
1. Click Start, Settings, Control Panel.
2. Double click NetMos Multi-I/O Ports icon, click
ParallelPorttab, two parallel portsshouldbe listed
under Ports.
For Windows 2000/XP/Server 2003:
1. Right click My Computer, click Manage, then click
Device Manger.
2. DoubleclickMultifunctionadapters,NetMos9835
PCI... Controller should be listed.
3. Doubleclick Ports(COM&LPT),twoNetMosPCI
Parallel Ports should be listed.
Troubleshooting
Problem:Iaminstallingaparallel port(s)andmysystem
freezes up when Windows tries to install the driver for
my printer port.
Solution:Enteryoursystembios,settheonboardparallel
port I/O address to 278h, save and exit. In certain
systems, the address 278h is reserved for ISA boards. So
when the PCI parallel port tries to capture this address,
your system gets confused and freezes up.
9
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers!
Simply visit our website at www.siig.com and click on Support.
Our online support database is updated daily with new drivers
and solutions. Answers to your questions could be just a few clicks
away. Youcanalsosubmitquestionsonlineandoneofourtechnical
supportanalysts will promptly respond.
A lifetime manufacturer warranty supplied with this product is
offered by SIIG, Inc. Please see SIIG website for more warranty
details. If you should happen to encounter any problems with this
product,pleasefollowtheproceduresbelow.
If it is within the store's return policy period, please return the
producttothestorewhereyoupurchasedfrom.
If your purchase has passed the store's return policy period, please
followthese steps tohave theproduct repaired or replaced.
Step1: SubmityourRMArequest.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective,anRMAnumberwillbeissued. SIIGRMAdepartment
can also be reached at (510)413-5333.
Step2: After obtaining an RMA number, ship the product.
•Properlypacktheproductforshipping. Allsoftware,cable(s)
andanyotheraccessoriesthatcamewiththeoriginalpackage
mustbeincluded.
•Clearly write your RMA number on the top of the returned
package. SIIGwillrefusetoacceptanyshippingpackage,and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•YouareresponsibleforthecostofshippingtheproducttoSIIG
at the following address:
SIIG,Inc.
6078 Stewart Avenue
Fremont, CA 94538
RMA#:
•SIIG will ship the repaired or replaced product via Ground
in the U.S and International Economy outside of the U.S at
nocosttothecustomer.
CyberParallelDual is a trademark of SIIG, Inc.
SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are
registeredtrademarksofMicrosoftCorporation. PentiumisaregisteredtrademarkofIntelCorporation.
Other names used in publication are for identification only and may be trademarks
oftheirrespectivecompanies.
February, 2005 Copyright ©2005 by SIIG, Inc. All rights reserved.
PRODUCT NAME
CyberParallelDual
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS
B OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCCCOMPLIANCESTATEMENT:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG, Inc.
6078 Stewart Ave.
Fremont, CA 94538-3152
About SIIG, Inc.
Foundedin1985,SIIG,Inc.isaleadingcomputerupgrademanufacturer
ofI/Oconnectivityproducts,includingPCI&ISAserialandparallel
ports,USB,SerialATA&UltraATAcontrollers,FireWire(1394a/b),
Networking,SoundCards,andotheraccessories. SIIGisthepremier
one-stopsourceofupgrades.
SIIGproductsoffercomprehensiveusermanuals,manyuser-friendly
features, and are backed by an extensive manufacturer warranty.
High-quality control standards are evident by the overall ease of
installation and compatibility of our products, as well as one of the
lowest defective return rates in the industry. SIIG products can be
foundincomputerretailstores,mailordercatalogs,ande-commerce
sitesintheAmericasandtheUK,aswellasthroughmajordistributors,
systemintegrators,andVARs.
Altri manuali per CyberParallel Dual
4
Indice
Altri manuali SIIG Scheda PCI
SIIG
SIIG SC-SA1012-S1 Manuale utente
SIIG
SIIG SC-SAEE22-S1 Manuale utente
SIIG
SIIG CyberPro PCI 2S Manuale utente
SIIG
SIIG ID-P40311-S1 Manuale utente
SIIG
SIIG JU-EC2012-S1 Manuale utente
SIIG
SIIG DP 4-Port USB 3.0 PCIe i/e Manuale utente
SIIG
SIIG SATA II-150 PCI Manuale utente
SIIG
SIIG Low Profile USB 2.0 Manuale utente
SIIG
SIIG JJ-P00212-S6 Manuale utente
SIIG
SIIG NN-400M12-S6 Manuale utente
SIIG
SIIG Serial ATA PCI Manuale utente
SIIG
SIIG CyberSerial Dual PCIe Manuale utente
SIIG
SIIG DP CyberSerial Dual PCI RJ Manuale utente
SIIG
SIIG PCI Express Serial Cards Manuale utente
SIIG
SIIG Hi-Speed USB 4-Port PCI Manuale utente
SIIG
SIIG Low Profile PCI-2S Manuale utente
SIIG
SIIG DP SuperSpeed USB 3.0 2-Port PCIe i/e Manuale utente
SIIG
SIIG UltraATA 133 PCI Manuale utente
SIIG
SIIG CyberPro PCI 4S Manuale utente
SIIG
SIIG SC-SA3012-S1 Manuale utente
Manuali Scheda PCI popolari di altre marche
ADLINK Technology
ADLINK Technology cPCI-3548 Manuale utente
Digium
Digium TE200 Series Manuale utente
Allo.com
Allo.com 2nd Gen E1/T1/J1 Manuale utente
Western Digital
Western Digital FireWire PCI Adapter Manuale utente
Pyle
Pyle Gamelink PLINK1 Manuale utente
Alpha Networks
Alpha Networks WMP-A13V Manuale utente
