Silvercrest SHBS 3.7 A1 Manuale utente
HAIR & BEARD TRIMMER SHBS 3.7 A1
IAN 103906
HAIR & BEARD TRIMMER
Operating instructions
HAAR- UND BARTSCHNEIDER
Bedienungsanleitung
ΚΟΥΡΕΥΤΙΚΗ ΜΗΧΑΝΗ ΓΙΑ
ΜΑΛΛΙΑ ΚΑΙ ΓΕΝΙΑ
Οδηγία χρήσης
KRA103906_Haar_und_Bartschneider_Cover_LB6.indd 2 11.12.14 15:03
English.................................................... 2
ƧnjnjLjǎNJNjƽ .............................................. 24
Deutsch................................................. 48
ID: SHBS 3.7 A1_15_V1.2
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
Overview / ƧǑNJǔNjǝǑLjǔLj / Übersicht
B
A
12
3
4
5
6
7
8
10
9
11
13
12
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
2 GB
Contents
1. Overview ..................................................... 3
2. Intended purpose .......................................... 5
3. Safety information ......................................... 5
4. Items supplied .............................................. 9
5. Charging ................................................... 10
6. Operation .................................................. 10
6.1 Changing the cutting attachments ........ 11
6.2 Changing the comb attachments.......... 11
6.3 Cutting hair ...................................... 12
6.4 Trimming a beard.............................. 13
6.5 Cutting a hairline............................... 14
6.6 Shaving............................................ 14
6.7 Trimming nose and ear hair................ 14
7. Cleaning and care ...................................... 15
8. Storage ..................................................... 17
9. Reordering parts ......................................... 17
10. Disposal .................................................... 17
11. Troubleshooting .......................................... 19
12. Technical specifications ............................... 20
13. Warranty of HOYER Handel GmbH .............. 20
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
3
GB
1. Overview
1Adjustable (3, 4, 5, 6 mm) comb attachment for the
beard trimmer attachment
2Comb attachments for the hair trimmer attachment 3, 6,
9, 12 mm
3Shaving attachment
4Precision trimmer attachment
5Hair and beard trimmer with connection for plug-in
power unit cable/battery charger
6Switch for cutting length fine tuning 1: 0.8 mm /
2: 1.3 mm / 3:1.8mm
7On/off switch (ON/OFF)
8Charging indicator
lit green: device in operation / charging: battery is fully
charged
flashing red: battery almost empty
lit red: battery is being charged
9Power unit
10 Battery charger with charge contact
11 Nose/ear hair trimmer attachment
12 Hair trimmer attachment
13 Beard trimmer attachment
not shown:
14 Scissors
15 Blade oil
16 Cleaning brush
17 Comb
18 Storage bag (for the hair and beard trimmer and its
accessories)
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
4 GB
Thank you for your trust!
Congratulations on your new 5in1 hair and beard trimmer.
For a safe handling of the device and in order to get to know
the entire scope of features:
• Thoroughly read these operating instructions
prior to initial commissioning.
• Above all, observe the safety instructions!
• The device should only be used as described in
these operating instructions.
• Keep these operating instructions for reference.
• If you pass the device on to someone else,
please include these operating instructions.
We hope you enjoy your new 5in1 hair and beard trimmer!
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
5
GB
2. Intended purpose
The 5in1 hair and beard trimmer is intended exclusively for
trimming human hair. Only use the device for dry hair.
The device is designed for private home use and must not be
used for commercial purposes. The device must only be used
indoors.
Foreseeable misuse
WARNING! Risk of material damage!
Do not use the device to cut artificial hair or animal hair.
3. Safety information
Warnings
If necessary, the following warnings will be used in these op-
erating instructions:
DANGER! High risk: failure to observe this warning
may result in injury to life and limb.
WARNING! Moderate risk: failure to observe this warning
may result in injury or serious material damage.
CAUTION: low risk: failure to observe this warning may result
in minor injury or material damage.
NOTE: circumstances and specifics that must be observed
when handling the device.
Instructions for safe operation
~
This device can be used by children
from the age of 8 and people with re-
stricted physical, sensory or intellectual
abilities or people without adequate ex-
perience and/or understanding, if they
are supervised or instructed on how to
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
6 GB
use this device safely and if they are
aware of the resulting danger. Children
must not play with the device. Cleaning
and maintenance by the user must not
be performed by children without su-
pervision.
~
Keep children under the age of 8 away
from the device and the power cable.
~
Only use the included original power
adaptor for mains operation.
DANGER for children
~Packing materials are not children's toys. Children should
not be allowed to play with the plastic bags: There is a
risk of suffocation!
~Keep the device out of the reach of children.
DANGER! Risk of electric shock due to mois-
ture
~Protect the device from moisture, water drops and water
splashes.
~Never touch the device with wet hands.
~The device, the battery charger and the power unit must
not fall into water or other liquids and must not be rinsed
under running water.
~If the device has fallen into water, pull out the power unit
immediately, and only then remove the device from the
water. Do not use the device again, but have this checked
by a specialist.
~Should liquid enter the device, have it checked before
starting the device up again.
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
7
GB
~If the device is used in a bathroom, the power unit must be
pulled out after use, as the proximity of water represents a
hazard, even when the device is switched off.
~Installation of a residual current device (FI/RCD) with a rat-
ed residual operating current of no more than 30 mA is
recommended to provide additional protection. Ask your
electrician for advice. The installation should only be car-
ried out by a qualified electrician.
DANGER! Risk of electric shock
~Never put the device into operation if there are visible
damages to the device, the battery charger or the cable or
if the device has been dropped before.
~Connect the cable to the device/battery charger before
plugging the power unit into a wall socket.
~Only connect the power unit to a properly installed, easily
accessible wall socket, the voltage of which corresponds
to the specifications on the rating plate. The wall socket
must continue to be easily accessible after the device is
plugged in.
~Ensure that the cable cannot be damaged by sharp edges
or hot surfaces.
~Ensure that the cable is not trapped or crushed.
~When removing the power unit from the wall socket, al-
ways pull the power unit and never the cable.
~Pull the power unit out of the wall socket, …
… after every use,
… after each charging process,
… if there is a fault,
… before connecting the device to the cable,
… before you clean the device and
… during thunderstorms.
~To avoid any risk, do not make modifications to the de-
vice. Repairs must be carried out by a specialist workshop
or the Service Centre.
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
8 GB
DANGER from batteries
~Protect the battery against mechanical damages. Fire
hazard!
~Do not expose the device to direct sunshine or heat. The
ambient temperature should not be lower than -10 °C and
higher than +40 °C.
~The charge contacts on the device must not be connected
by metallic objects.
~The
battery
may only be charged with the original acces-
sory (power unit).
~The battery only removed for disposal must not be used
again.
~Should the electrolyte solution leak out of the
battery
,
avoid contact with eyes, mucous membranes and skin.
Rinse immediately with plenty of clean water and consult a
doctor. The electrolyte solution can cause irritation.
WARNING! Risk of injury from cutting
~The points of the comb attachments, the hair trimmer at-
tachment, the beard trimmer attachment and the precision
trimmer attachment are sharp. Handle with care.
~Do not use the device if the attachment shows damages.
~Switch off the device before pinning up or changing the
attachments and each time before cleaning.
WARNING! Risk of injury
~Place the cable in such a way that no one trips over it or
steps on it.
~Do not push the nose/ear hair trimmer attachment too
deep into the nostril or the ear canal.
~Do not use the device on open wounds, cuts, sunburn or
blisters.
WARNING! Risk of material damage
~
The battery charger is fitted with non-slip silicon feet. As fur-
niture is coated with a variety of different varnishes and
acrylics and treated with different cleaning agents, we can-
not rule out that some of these substances could damage
and soften the rubber feet. If necessary, place a non-slip mat
under the battery charger.
BB.5$B%ERRN6HLWH'LHQVWDJ'H]HPEHU
