SIMOLIO SM-825D Pro Manuale utente

2.4GHz Wireless TV Headphones

User Manual

SM-825D Pro

Sales & Support Email: [email protected] (for NA/AU)

[email protected] (for UK)

Sales & Support Email: support@simolio.com (for NA/AU)

support_uk@simolio.com (for )UK

SAFETY INSTRUCTIONS

1. Please read this instruction manual carefully and completely before using the

products. Keep this manual easily accessible at all times.

2. Always keep the product dry, and do not expose them to extreme temperatures.

3. The receiver must keep the minimum volume before switching the unit on.

High volume may cause hearing damage to persons with normal hearing,

especially to children.

4. Keep devices away from liquid. Before cleaning the product and its accessories,

disconnect the transmitter from the power adapter, and use only a slightly damp

cloth to clean the devices.

5. Use only the supplied power adapter.

6. Use the products with care and set them up on a stable surface of a clean,

dust-free environment.

7. The unit may get hot during use. Ensure the unit has adequate ventilation.

8. Please put the product far away from microwave oven, mobile phones, WiFi

router etc. to avoid unnecessary electronic wave interference.

9. Please switch off the transmitter and receiver after use, and pull out the power

adapter from the wall socket when not using for a long time.

10. Only qualified person can provide services! Do not attempt to open the unit!

Pacemaker Safety:

CAUTION!

Before using this product with a pacemaker or other medical device, consult

your physician or the manufacturer of your pacemaker or other medical device.

Thank you for choosing the SIMOLIO SM-825D Pro Wireless TV Headphone. Please

read this guide carefully and keep it in a safe place for future reference. If you need

any further assistance, please contact our customer support team at:

[email protected] (NA/AU)

[email protected] ( )

Response Time: 2-24h, excl. Holidays

Welcome to subscribe to our Yo uTube channel - “Simolio Direct” for more

product information.

Table of Contents

SM-825D Pro

Safety Instruction.................................................................... 01

Overview ............................................................................... 02

Features ................................................................................. 02

Product Diagram .................................................................... 04

Package Contents ................................................................... 04

LED Indication ...................................................................... 05

How to Use ............................................................................. 06

1. Check Your TV/Audio Source Output Options before the Set up .. 06

2. Turn on the Transmitter and Headphone .................................. 07

2.1 Power the Transmitter ...................................................... 07

2.2 Turn on the Transmitter .................................................... 07

2.3 Turn on the Headphone .................................................... 07

3. Connect the Transmitter to Your TV/Audio Source ................... 07

3.1 Digital Optical Connection ............................................... 08

3.2 RCA Analog Connection ................................................... 09

3.3 3.5mm/AUX Analog Connection ....................................... 11

3.4 Other Connections in Special Cases ................................... 12

4. Use Two Sets of SIMOLIO 2.4GHz Wireless TV Headphones

Simultaneously in the Same House ......................................... 15

5. Charge the Headphone ......................................................... 16

6. Customizing your SM-825D Pro ............................................ 17

Troubleshooting ..................................................................... 18

Limited Warranty .................................................................. 20

Technical Specifications ......................................................... 21

..........

(3) Long Distance Transmission

Supported with the latest technology, you can have wireless freedom and crystal

clear voice within a range of up to 100 feet.

(4) Voice Highlighting Tech

Reduce background voice in TV to highlight the dialogues, so that words hard to

hear can easily stand out, making television dialogues to be understood easily.

(5) Noise Cancelling Tech (NCT)

Reduce the ambient noise to help the users to focus on listening to the dialogues

in TV.

(6) Automatic Signal Control (ASC)

Our special circuit design can adjust the sudden volume change and make the

output volume stable. It will avoid strong signal hurting the users' hearing.

(7) BALANCE Control

The balance control allows for right/left volume adjustment. Adjust the balance

so that you hear equally well with both ears.

(8) TONE Control

It is specially designed for people who have different sound frequency

sensitiveness. They can select TONE (Treble/Normal/Bass) to find the optimum

parameters, and hear the target audio source clearly.

(9) MONO/STEREO Optional

You can switch to STEREO for enjoying Hi-Fi sound quality music or select

MONO for enjoying more clear TV dialogues.

(10) Good Compatibility

Compatible with any brand of TV/Smart TV box/ Cable TV box/Set-top

box/DVD/other audio device that has a Digital Optical, RCA or 3.5mm AUDIO

OUT port(s).

(11) Multiple Charging Methods

The headphone is recharged by the supplied Micro USB cable into a compatible

USB charger (transmitter USB port/PC or TV USB port). It is ok to use most

mobile phone chargers on market. The spare battery is charged and always ready

to avoid TV watching being interrupted by the charging process.

0102

OVERVIEW

FEATURES

(1) Wireless TV Hearing Assistance and Hearing Protecting Function

Soften the background sound, make the TV conversation stand out, help the

hearing impaired people to understand the TV clearly, solve the problem that

regular hearing aid cannot do. The unique voice highlighting tech and customized

tone adjustment allow people to enjoy TV programs in safe sounds, protecting

people's hearing from the progressive hearing damage caused by watching TV

with normal headphones for a long time.

The unique “one-button push” sound amplifier function allows you to hear clearly

what people are talking nearby without taking off the headphones.

Would you like to watch television with crystal-clear sound that won’t disturb

others in your family? Do you want to avoid hearing damage that could be caused

by wearing normal wireless headphones for a long time? SIMOLIO SM-825D Pro

wireless TV hearing assistance and protecting headphone is just made for you.

Apply with the latest 2.4GHz Digital Automatic Frequency-Hopping Spread

Spectrum (FHSS) technology, it gives you crystal-clear sound with the freedom

of a wireless connection - up to 100 feet without obstacles. You can customize

your listening at a most comfortable volume level, via balance and tone controls.

Our voice highlighting and noise cancelling technology dynamically reduce TV

background sounds and make TV dialogues stand out. At last you can easily

understand the TV dialogues at a healthy volume without worrying about your

hearing being damaged.

The SIMOLIO SM-825D Pro is especially helpful for hearing-impaired people. It

overcomes the weakness of regular hearing aids, which amplify both speech and

environmental background at the same time. Normal wireless headphones for TV

watching don’t help either, they also amplify everything together. Also, over

time you’ll keep turning the volume up and up, and that can make your hearing

worse and worse. Our hearing protecting headphone solves these problems.

It’s compatible with both digital and analog audio output ports and suitable for

almost all TVs and the set-top boxes on the market.

(2) Personal Sound Amplifier

A MIC button is designed as an additional & unique feature to help you to

temporarily hear what people are talking to you when watching TV without

taking off the headphone.

SM-825D Pro

(12) Headphone Designed with Auto Power Off Function for Power

Saving

When no signal is received for 10 minutes, the headphone will be powered off

automatically.

(13) Audio Sharing Function

You can have another headphone plug into the sharing port on the right side of the

SIMOLIO headphone to share audio with your buddy .

PRODUCT DIAGRAM

POWER IN

DC 5V

OFF/ON

OFF/MONO/STEREO

Power &Working

Indicator (Green)

AUDIO IN

TONE

TREBLE/NORMAL/BASS

2. Transmitter

OPTICAL IN

Battery Charging

Compartment

POWER OUT

DC 5V/500mA

STEREO

MONO

OFF

OFF/ON

DC 5V

POWER IN

OPTICAL INAUDIO INBASS

TREBLENORMAL

TONE

POWER OUT

(charging port)

USB DC 5V

Charging Indicator (Red)

Battery Cover

Spare Li-battery

1. Receiver

Built-in Mic

BALANCE

(Left Right)

VOLUME

Power ON/OFF

Personal Sound

(MIC ON/OFF)

Amplifier Button

Wireless Receiving Indicator

(Green LED 1)

Personal Sound Amplifier Indicator

(Green&Red LED 2)

Audio In Charging Indicator

(Red LED 3)

Li-battery

Battery

Compartment

USB Charging Socket

PACKAGE CONTENTS

LED INDICATION

LED Status Transmitter Status

Green LED flashes slowly No audio signal in within 5 minutes

Bright green LED lighting steadily

Red LED lighting steadily

Red LED off

Dark green LED lighting steadily In standby mode (no audio signal in

for more than 5 minutes)

Wireless working mode

Spare battery charging

Battery charging completed/no charging

LED Indicators of the Transmitter

8. User Manual 9. Quick Guide

USA UK

7. Power Adapter

5. If no Optical Audio Out port available, we suggest to connect the transmitter base to the red and white

RCA ports which labeled as AUDIO OUT of your TV. If the RCA AUDIO OUT port of your TV is unavailable,

you can connect the transmitter base to your

which is hooked up with your TV.

Smart TV box/Cable TV box/Set-top box/DVD/other audio

device

TV Rear

Transmitter 3.5mm

Audio In

Audio Out

TV or Cable Box

QUICK GUIDE for SM-823D, SM-824D & SM-825D

IMPORTANT:

When use it as a wireless TV headset, the working

indicator is on. As a personal sound amplifier, the MIC indicator is on.

TV/Smart TV box/

Cable TV box/Set-top box/DVD/other audio device

1. The unit will not work with the optical audio if the optical cable is carrying a Dolby Digital or DTS signal.

In this case, set the Audio Out Format of your TV and TV related AV devices (e.g., cable box/DVD etc) to

PCM to get the unit to work.

2. Three different audio cords: digital optical cord, RCA cord and 3.5mm cord. In the end, only one of these

cords is needed to complete the installation.

3. This device is a wireless TV headset as well as a personal sound amplifier. You can find a MIC ON/OFF

button at the rear of headset. It is designed for hearing impaired people to clearly hear what people’s

talking to him/her nearby when watching TV. Just press MIC ON/OFF button , you can turn this headset to

a personal sound amplifier which could amplify the people's voice around. When you want to back to

watching TV, just press the MIC button again.

4.We suggest to hook up the transmitter base to the Optical Audio Out port of your

in priority, for enjoying the super sound quality.

For streaming media watching (Netflix, Amazon Prime Video, etc.), place the transmitter base at least 4

feet away from your smart WiFi TV/WiFi TV box/TV sticks to avoid interference.

green

red

Page 1

TONE

TREBLE

NORMALBASSAUDIO IN

STEREO

MONO

OFF

DC 5V

OPTICAL

TONE

TREBLE

NORMALBASSAUDIO IN

STEREO

MONO

OFF

DC 5V

OPTICAL

Optical

Audio Out

TV Rear Optical Splitter

Optical In

Optical Out

Sound Bar Transmitter Audio In

Optical

Audio Out

TONE

TREBLE

NORMALBASSAUDIO IN

STEREO

MONO

OFF

DC 5V

OPTICAL

Audio In

Optical

TV Rear

Transmitter

If you has a sound bar/HiFi need to be connected

with, we suggest to buy an optical splitter, so you

can connect your sound bar/HiFi and the transmitter

to your TV at the same time, shown as figure 2.

TV or Cable Box TV or Cable Box

Figure 2

Figure 1

Figure 3 Figure 4

SEVEN F REQUE NCY ASKE D QUEST IONS (FAQ ) from marketing statistical analysis:

1.Outside noise overpowers the TV voice.

It is possible that the MIC ON/OFF button at the rear of headset is pressed on inadvertently, in this case the MIC

indicator is solid red . To back to watching TV, just press the MIC ON/OFF button again or switch off the headset

and then restart with the red MIC indicator off and the green TV receiving indicator on.

2.The connections are correct and in place, but no TV sound is heard or sound cuts in and out.

1) It is possible that the volume of the audio source is set too low. If you connect STB/Cable box/DVD etc to the

TV to watch programs, then the audio source is the STB/Cable box/DVD etc. Please use the audio source's

remote control to set its volume to a sufficient level to ensure a steady sound signal. If you want to mute the TV

sound and only hear from this headset, please use your TV remote control to click MUTE menu. (For most TVs,

the TV's speakers are separately controlled from the TV's audio out).

2) When do connection with the optical cable, set the Audio Out Format of your TV and TV related AV devices

(e.g., cable box/DVD etc ) to PCM to get the unit to work. ( Settings > Sound > Digital Audio Out Format >

VIDEO IN

COMPONENT

AUDIO IN

RCA

AUDIO OUT

RCA

BASS

TREBLENORMAL

STEREO

TONE

AUDIO IN

MONO

OFFDC 5V

OFF/ONPOWER IN

POWER OUT

DC 5V/500mA

OPTICAL IN

BASS

TREBLENORMAL

STEREO

TONE

AUDIO IN

MONO

OFFDC 5V

OFF/ON

POWER IN

OPTICAL IN

SM-823D

SM-824D

SM-825D

2.4GHz Wireless TV Headphone

User Manual

Sale s & Suppo rt Emai l:

[email protected]

for US A, or

[email protected]

for Eu rope

SM-825D

3. Optical Fiber Cable

2. Transmitter

1. Headphone

A Spare Li-ion battery

for headphone

(included)

5. Micro USB

charging Cable

6. -

Audio Cable

Ø3.5mm RCA

4. 3.5mm

Audio Cable

o C

(for headphone)

SM-825D Pro

(14) One Transmitter Can Support Multiple Headphones

Additional SIMOLIO 2.4GHz wireless headphone receivers can be added to the

SM-825D Pro system, allowing multiple listeners to enjoy the same audio source.

LED Indicators of the Headphone

Headphone charging

LED Status Headphone Status

Green flashes slowly ( LED LED 1) No signal received

Green LED quickly and

headphone beeps every minute LED 1)

flashes

(

Green LED lighting steadily (LED 1) Wireless working mode

Low power indication

Built-in MIC working mode

Red LED on (LED 3)

LED flashing red and green alternately LED 2) (

Headphone charging completed

Red LED off (LED 3)

Note:

• The transmitter will automatically enter standby mode within 5 minutes of no

signal input, and it will automatically restart when there is an audio signal input.

HOW TO USE

SM-825D Pro is compatible with OPTICAL output, AUX 3.5mm output, and RCA

(labeled “AUDIO OUT”)

1. Check Your TV/Audio Source Output Options before the Set up

• The headphone will power off automatically after 10 minutes of no audio signal

in. Using it again, you need to slide ON/OFF switch to “OFF” position, then slide

to “ON”. Be aware, the headphone will not automatically power off in the personal

sound amplifier mode unless the battery is dead.

Other RCA

jacks(usually

audio in)

AUDIO IN

Digital Optical

AUDIO OUT

OPTICAL

AUDIO OUT

(need extra 6.35mm

to 3.5mm adapter,

purchase separately)

(need extra digital to

analog converter,

purchase separately)

Digital

AUDIO OUT

Coaxial

COAXIAL

Jack

Options

Natively

supported?

Please refer

to Point

6.35mm

Phone jack

PHONE

3.1

AUX/3.5mm

3.3

RCA jacks

labled

AUDIO OUT

3.2 N/A 3.4 3.4

Fig 1-1

2.1 Power the Transmitter (Ref. Fig 2-1)

Plug the supplied AC adapter into a standard electrical outlet, plug the other end

of the AC adapter into the port labeled “DC 5V” on the back of the transmitter.

2. Turn on the Transmitter and Headphone

Note:

• Three different audio cables included: digital optical cable, RCA cable and

3.5mm cable. In the end, only one of these cables is needed to complete the

installation.

• If your audio source device has an optical audio out port, please connect

SIMOLIO to this port preferentially. If not, you can also connect SIMOLIO to the

RCA or AUX/3.5mm or other audio out port of the audio source device.

SM-825D Pro

2.2 Turn on the Transmitter (Ref. Fig 2-2)

Slide OFF/MONO/STEREO switch to “MONO” or “STEREO” position.

2.3 Turn on the Headphone

Slide ON/OFF switch to “ON” position .

(Ref. Fig 2-3).

Note: Please charge the headset for 3 hours before using it for the first time.

3.Connect the Transmitter to Your TV/Audio Source

Set the audio output of your audio sources to a sufficient level to ensure the normal

hearing level people can hear TV clearly.

i.e. set the TV box VOL ≥ 30 % & TV VOL ≥ 40% (Ref. Fig 3-1) (Ref. Fig 3-2)

For watching TV quietly without disturbing others, the right way is: Mute your TV

by pressing the MUTE button on the remote control or choose any speaker option

other than TV Speaker in the TV Sound Output settings.(Ref. Fig 3-3)

• The above settings may differ from various TVs.

TV box VOL ≥ 30 %

Fig 3-1

STEREO

MONO

OFF

OFF/ON

Fig 2-2

POWER OUT

DC 5V/500mA

STEREO

MONO

OFF

OFF/ON

DC 5V

POWER IN

OPTICAL IN AUDIO IN BASS

TREBLE NORMAL

TONE

Transmitter

TV VOL ≥40 %

Fig 3-2

Power in

POWER IN

DC 5V

Power adapter

Fig 2-1

Fig 2-3

Mute

Fig 3-3

Plug either end of the optical audio cable into the “Digital Audio Out (Optical)”

port on the back of the TV. Plug the other end of the optical digital audio cable

into the port on the back of the transmitter labeled “OPTICAL IN”.

Step 2. TV Audio Format and Speaker Setting (use TV remote control)

If you can not hear sound from your headphones after connecting:

3.1 Digital Optical Connection

This part will instruct you on how to connect the SIMOLIO SM-825D

transmitter to your television, satellite, or cable box using an optical digital audio

cable.

Pro

CAP

Optical Audio Cable

Digital Audio Out

(Optical)

Step 1. Hook up SIMOLIO to the Optical Audio Out Port of the TV/other

Audio Device

Remove the protective plastic caps

from both ends of the optical digital

audio cable.

• Be aware that the base should be placed at least 4 feet away from your Router/

smart WiFi TV/TV sticks/WiFi TV box to avoid interference.

Fig 3-4

Fig 3-5

• If you cannot get to the back of your TV and you only watch the programs

through a fixed TV box (cable/satellite box/DVD etc.), you can also use these

instructions to install the system to your TV box.

• Ensure TV Audio Format is set to “PCM” or “Dolby/DTS” is OFF (This is

IMPORTANT, Ref. Fig 3-6)

PS: for certain smart Samsung models, the TV is retaining separate settings for

regular TV and internet TV setup. When you turn to the Smart Hub for Internet

source, please use the TV remote to go to Settings > Sound > Expert Settings >

Audio Format or Digital Output Audio Format, then select PCM.

POWER OUT

DC 5V/500mA

STEREO

MONO

OFF

OFF/ON

DC 5V

POWER IN

OPTICAL IN AUDIO INBASS

TREBLE NORMAL

TONE

OPTICAL IN

3.2 RCA Analog Connection

This Part is an alternative to 3.1 on page 8. This part will explain how to connect

the SIMOLIO SM-825D Pro transmitter to your television, satellite, or cable box

using an RCA analog audio cable.

Notes: If your TV only support single sound out, the TV’s speakers will be either

automatically muted when you plug something into an audio out port (Optical/

AUX/RCA, etc.) or they become disabled once you choose "External Speakers"

as your TV's audio output. It depends on TV circuit design.

Plug the red and white ends of the audio cable into the analog RCA Audio Out

ports (red and white ports labeled “AUDIO OUT”) on the back of the TV. Plug

the single end of the audio cable into the port labeled “AUDIO IN” on the back of

the transmitter. (Ref. Fig 3-8)

• Ensure your TV speaker is set to “External Speakers”. (Ref. Fig 3-7)

Fig 3-6 Fig 3-7

* Setting menu may be different depending on different TV brands and models.

For most TVs, the TV's internal speakers and an external audio device can work

simultaneously. Such as, for some newer LG TVs, when do optical audio

connection, you can set the “Sound Out” to “Internal TV Speaker + Audio Out

(optical)”. And for some newer Samsung TVs, you can enable this feature by

selecting “TV Speaker” from the TV Sound Output lists.

• Be aware that the base should be placed at least 4 feet away from your Router/

smart WiFi TV/TV sticks/WiFi TV box to avoid interference.

• If you cannot get to the back of your TV and you only watch the programs

through a fixed TV box (cable/satellite box/DVD etc.), you can also use these

instructions to install the system to your TV box.

Step 1. Hook up SIMOLIO to the RCA Audio Out Port of the TV/other Audio

Device

Speakers

Internal speakers

External speakers

Headset

Settings

Audio Format

Dolby Digital

DTS

DTS Neo 2:5

PCM

SM-825D Pro

* Your TV’s analog audio settings may be set to “Variable” or “Fixed”. If you

want to be able to control your TV volume level separate from your SIMOLIO

SM-825D Pro volume level, you will need to make sure your TV is set to “Fixed”.

Contact your TV manufacturer for assistance. (Ref. Fig 3-12)

3.3 3.5mm/AUX Analog Connection

This part is an alternative to 3.1 and 3.2 on page 8-10. This part will explain how

to connect the SIMOLIO SM-825D Pro transmitter to your television, satellite, or

cable box using a 3.5mm/AUX analog audio cable.

POWER OUT

DC 5V/500mA

STEREO

MONO

OFF

OFF/ON

DC 5V

POWER IN

OPTICAL IN AUDIO IN BASS

TREBLE NORMAL

TONE

AUX/3.5mm Audio Cable

H/P or Audio Out

Fig 3-13

RCA Audio Cable

R AUDIO OU T L

Plug one end of the 3.5mm audio cable into the “Audio Out” port on the back of

the TV. Plug the other end of the audio cable into the port labeled “AUDIO IN” on

the back of the transmitter.

• If you cannot get to the back of your TV and you only watch the programs

through a fixed TV box (cable/satellite box/DVD etc.), you can also use these

instructions to install the system to your TV box.

• If you connect the 3.5mm audio cable to the 3.5mm Audio Out port which is

usually a Headphone port on your TV, your SIMOLIO SM-825D Pro will still

function properly, but the sound to your TV internal speakers will be muted. The

port is usually labeled with an headphone icon.

• Be aware that the base should be placed at least 4 feet away from your

Router/smart WiFi TV/TV sticks/WiFi TV box to avoid interference.

* Setting menu may be different depending on different TV brands and models.

Step 1. Hook up SIMOLIO to the 3.5mm Audio Out Port of the TV/other

Audio Device

AUDIO IN

SETTINGS

ANALOG AUDIO OUT

VARIABLE

FIXED

SOUND / AUDIO

Step 2. TV Audio Out Checking and TV Speaker Setting (use TV remote

control)

If you can not hear sound from your headphones after connecting:

Notes:

* If your TV only support single sound out, the TV’s speakers will be either

automatically muted when you plug something into an audio out port (Optical/

Fig 3-8

Fig 3-11 Fig 3-12

• Ensure use TV Red/White ports labeled “AUDIO OUT” or “OUTPUT”, other

Red/White ports are incorrect. (Ref. Fig 3-9)

• Ensure your TV speaker is set to “External Speakers”. (Ref. Fig 3-10)

• Use the RCA cable to plug the headphone into the RCA output of the TV to test

if you can hear the TV sound. (Ref. Fig 3-11)

For most TVs, the TV's internal speakers and an external audio device can work

simultaneously. Such as, for some newer LG TVs, when do analog RCA audio

connection, you can set the “Sound Out” to “Internal TV Speaker + Headphones”.

And for some newer Samsung TVs, you can enable this feature by selecting “TV

Speaker” from the TV Sound Output lists.

RCA Audio Cable

TV REAR

R AUDIO OUT L

POWER OUT

DC 5V/500mA

STEREO

MONO

OFF

OFF/ON

DC 5V

POWER IN

OPTICAL IN AUDIO IN BASS

TREBLE NORMAL

TONE

AUDIO IN

AUDIO OUT

COMPONENT IN

VIDEO IN

TV REAR

Fig 3-9 Fig 3-10

Speakers

Internal speakers

External speakers

Headset

SM-825D Pro

AUX/RCA, etc.) or they become disabled once you choose "External Speakers"

as your TV's audio output. It depends on TV circuit design.

wireless

transmitter

Coaxial

Digital Out

UDIO IN

Digital to Analog Converter

RCA OUT

COAXIAL IN

POWER OUT

DC 5V/500mA

STEREO

MONO

OFF

OFF/ON

DC 5V

POWER IN

OPTICAL IN AUDIO IN BASS

TREBLE NORMAL

TONE

Step 2. TV Audio Format and Speaker Setting (use TV remote control)

If you can not hear sound from your headphones after connecting:

Note:

Setting menu may be different depending on different TV brands and models.

Fig 3-17

RCA

OUT

COAXIAL IN

Connect TV/

Cable box/

STB etc.

RCA Audio Cable

H/P

COAXIAL IN

3.5mm Audio Cable

Connect TV/

Cable box/

STB etc.

Fig 3-20

• Ensure TV Audio Format is set to “PCM” or “Dolby/DTS” is OFF (This is

IMPORTANT, Ref. Fig 3-18)

PS: for certain smart Samsung models, the TV is retaining separate settings for

regular TV and internet TV setup. When you turn to the Smart Hub for Internet

source, please use the TV remote to go to Settings > Sound > Expert Settings >

Audio Format or Digital Output Audio Format, then select PCM.

• Ensure your TV speaker is set to “External Speakers”. (Ref. Fig 3-19)

• Take turns to test RCA connection and 3.5mm headphone connection.

• Use the AUX/RCA cable to plug the headphone into the H/P port or RCA output

of the DAC to test if you can hear the TV sound. (Ref. Fig 3-20)

Fig 3-18 Fig 3-19

Speakers

Internal speakers

External speakers

Headset

Settings

Audio Format

Dolby Digital

DTS

DTS Neo 2:5

PCM

Fig 3-14

Step 2. TV Audio Out / TV Speaker Setting (use TV remote control)

If you can not hear sound from your headphones after connecting:

3.5mm Audio Cable

Notes:

* Your TV’s audio settings may be set to “Variable” or “Fixed”. We recommend

that you set your audio settings to “Fixed” for better audio quality when using

this installation option. If you want to be able to control your TV volume level

separate from your SIMOLIO SM-825D Pro volume level, you will need to make

sure your TV is set to “Fixed”. Contact your TV manufacturer for assistance.

• Use the AUX/3.5mm cable to plug the headphone into the headphone/3.5mm

audio output of the TV to test if you can hear the TV sound. (Ref. Fig 3-15)

Fig 3-15

1) TV/Audio Source only has Digital Coaxial Audio Out port

Fig 3-16

3.4 Other Connections in Special Cases

* Setting menu may be different depending on different TV brands and models.

Step 1. Purchase a Digital to Analog Converter and Set up as Shown in

Fig 3-17

If your TV/Audio Source only has a digital coaxial audio out port, you will need

a digital to analog converter (DAC) for installation.

• Ensure your TV speaker is set to “Headset”. (Ref. Fig 3-14)

H/P or Audio Out

SETTINGS

ANALOG AUDIO OUT

VARIABLE

FIXED

SOUND / AUDIO

Speakers

Internal speakers

External speakers

Headset

SM-825D Pro

• Use the AUX cable and 6.35 to 3.5mm converter to plug the headphone into the

port on AV receiver to check whether the sound is normal.

•

headphone and make sure the green LED indicators are facing towards each other

for about 5 seconds.

Take the headphone close to the transmitter, then turn on the transmitter and

Note: If two headphones are used on the same TV, only one transmitter needs to

be connected, because one transmitter supports multiple headphones to work

simultaneously.

• The two sets of SIMOLIO 2.4GHz units should be put at least 10 meters away

from each other when using them simultaneously.

Fig 3-23

AV Receiver

6.35mm Audio adapter

(purchase separately)

3.5mm Audio Cable

6.35mm Phone jack

4. Use Two Sets of SIMOLIO 2.4GHz Wireless TV Headphones

Simultaneously in the Same House

Fig 4-1

room 1 room 2

SM-825D

(Transmitter 2)

Pro

SM-825D

(Transmitter 1)

Pro

Distance >10M (at least)

If you can not hear sound from your headphones after connecting:

MIC ON/OFF

Wireless Receiving

Indicator (Green)

(Receiver)

(Transmitter)

Power &Working

Indicator (Green)

POWER OUT

DC 5V/500mA

STEREO

MONO

OFF

OFF/ON

DC 5V

POWER IN

OPTICAL INAUDIO IN BASS

TREBLE NORMAL

TONE

Fig 4-2

Phones

2) If your TV/Audio Source’s Digital Optical Audio Out port is occupied

by soundbar, you will need an optical splitter for installation.

Step 2. If you can not hear sound from your headphones after connecting,

follow the part of 3.1 on page 8-9 to check your settings.

Step 2. Check the Performance of the AV Receiver's Audio Output as Shown

in Fig 3-23

Step 1. Purchase an Optical Splitter and Set up as Shown in Fig 3-21

Optical Splitter

Optical Fiber

Cable

Sound Bar

Optical Fiber

Cable

SM-825D

(Transmitter)

Pro

Fig 3-21

Phones

AV Receiver

6.35mm Audio adapter

(purchase separately)

3.5mm Audio Cable

6.35mm Phone jack

POWER OUT

DC 5V/500mA

STEREO

MONO

OFF

OFF/ON

DC 5V

POWER IN

OPTICAL IN AUDIO IN BASS

TREBLE NORMAL

TONE

Fig 3-22

Step 1. Purchase a 6.35mm to 3.5mm Adapter and Set up as Shown

in Fig 3-22

3) Connect SIMOLIO SM-825D Pro to your AV Receiver with 6.35mm

PHONE jack

SM-825D Pro is not compatible with ANY RCA(L/R) ports on your AV Receiver,

ONLY use the BIG 6.35mm PHONE OUT on front side of your AV Receiver

with the 6.35mm to 3.5mm adapter (purchase separately).

AUDIO IN

Digital Optical

Audio Out

SM-825D Pro

You can only rotate it

90 degrees in a specific

direction as above.

Notes: The charging time is approx. 3 hours. Before using the spare rechargeable

battery for the first time, charge it for at least 3 hours. The headphone battery will

last around 10 hours on a full charge, but will last a lesser or greater amount of

time depending on the average volume level of the headphone.

2) Balance Control: If the hearing abilities of two ears are not the same, you can

open the decorative cover on the right side of the headphone and then rotate the

BAL dial for right/left volume adjustment so that you hear equally well with both

ears.

3) Tone Control: Select the TONE (TREBLE/NORMAL/BASS) at the rear of

transmitter to find the best feature, make sure you can hear the TV voice clearly.

(Ref. Fig 6-4)

A. Each side of the headphone has a letter to

guide the wearer: "L" for left and "R" for right.

You can adjust the retractable headband to fit

you better. (Ref. Fig 6-1)

6. Customizing your SM-825D Pro

Fig 6-1

Fig 6-3

BALANCE

(Left Right)

( )

A: Through the USB charging port on the rear of the transmitter base

You can use the included micro USB charging cable to connect the headphone to

the USB charging port on the rear of the transmitter base for charging.(make sure

the transmitter base is powered on)

POWER OUT

DC 5V/500mA

STEREO

MONOOFF

OFF/ON

DC 5V

POWER IN

OPTICAL IN AUDIO IN BASS

TREBLE NORMAL

TONE

(Transmitter)

(Receiver)

micro USB charging cable

B: Through the universal USB charger/outlet

You can charge your headphone by plugging the micro USB power cable into a

phone charger (5V/500mA-2A output), PC USB port, TV USB port or any other

USB outlet. You don't need to go back to the transmitter base next to the TV to

charge. It takes about 3 hours to fully charge the headphones. The LED will turn

RED during charging and turn off once charging is completed.

(Headphone)

micro USB charging cable

(phone charger / PC USB port/

TV USB port / any other USB outlet)

C: Through the battery charging compartment in the base

A spare battery in the battery charging compartment at the side of the transmitter

is always ready. When the headphone battery is low power, pull the spare battery

out of the battery charging compartment for replacement, and the discharged

battery can be put into the compartment for recharging.

1716

Li-ion

battery

(Receiver)

PUSH

MADE IN CHINA

Li-ion

battery

(Transmitter)

battery

cover

5.Charge the Headphone

battery

cover

Fig 5-1

Fig 5-2

Fig 5-3

Power

adapter

SM-825D Pro

1) Please make sure the headphones are being worn properly.

B. It's a 90-degree rotation design that can't be folded up.If you experience

resistance while rotating, please check and change to the correct rotation

direction.

Fig 6-2

Caution

Altri manuali per SM-825D Pro

Indice

Altri manuali SIMOLIO Cuffie senza fili

SIMOLIO

SIMOLIO SM-561 Manuale utente

Manuali Cuffie senza fili popolari di altre marche

Audity

Audity Infinite Manuale utente

Bowers & Wilkins

Bowers & Wilkins PI4 Manuale utente

Niceboy

Niceboy Hive Sport 2 Manuale utente

Aiwa

Aiwa HST-250BT Manuale utente

Sennheiser

Sennheiser TR 185 Manuale utente

JBL

JBL DUET Arc Manuale utente

UNDER ARMOR

UNDER ARMOR UA STREAK Manuale utente

Krüger & Matz

Krüger & Matz Play Manuale utente

JLab Audio

JLab Audio FLEX Manuale utente

Bang & Olufsen

Bang & Olufsen Beoplay 500 Manuale utente

Mixx

Mixx StreamQ C1 Manuale utente

Srhythm

Srhythm NiceComfort 75 Manuale utente

MOB

MOB MO6249 Manuale utente

Skullcandy

Skullcandy Uproar Manuale utente

JBL

JBL Everest 310 Manuale utente

Pioneer

Pioneer SE-E8TW Manuale utente

Harman

Harman JBL TUNE 500BT Manuale utente

JVC

JVC HA-Z77T Guida utente
