Simrad ES60

Marine computer for reliable operation

MAXIMIZING YOUR PERFORMANCE AT SEA

www.SIMRAD.com

The popular Simrad ES60

echo sounder system can be

installed on any commercial

computer, provided that the

technical specications are met.

However, ofce computers

have not proven to be very

dependable on shing vessels.

In order to meet an increasing

demand for a rugged and

reliable computer, we now

introduce the ES60 Marine

Computer.

Based on a commercial design,

the ES60 Marine Computer provides

a rugged design, small physical size,

adequate performance and no moving

parts.

The traditional hard disk has

been replaced with a 4 Gb FlashDisk

memory device, while fans and CD

player has been omitted.

The computer supports four

RS-232 serial lines, two ethernet

connections, as well as six USB

sockets and one LVDS interface. It

will also operate on DC voltages.

305466 / Rev.A / August 2006

Strandpromenaden 50

P.O.Box 111

N-3191 Horten,

Norway

Simrad Horten AS

Telephone: +47 33 03 40 00

Telefax: +47 33 04 29 87

simrad.sales@simrad.com

www.simrad.com

Simrad ES60 Marine Computer

Specications can be altered without prior notication.

Technical specications

Mechanical construction

• Aluminum chassis with fanless

design

• Dimensions: 195 x 268 x 80 mm

• Mounting brackets

Processor and memory

• Celeron®M processor

• 1.3 GHz clock

• 400 MHz FSB

• Intel®852 GM(E) chipset

• 512 Mb RAM (Max 2 Gb)

• 4 Gb FlashDisk

• Supports one PCI card

Interfaces

• USB 2.0 x 6

• PS/2 keyboard/mouse

• RS-232 x 4

• Audio microphone input

• Loudspeaker output

• LVDS

• 10/100 Ethernet LAN x 2

• VGA

• S-Video TV out

Power requirements

• External power supply

• Power input: 100 to 240 Vac

• Power putput: +19 Vdc

• DC operation: +12 to 30 Vdc

Environment specications

• Operating temp: -10 to +50°C

• Storage temp: -20 to +80°C

• Relative humidity: 10 to 90%

(non-condensing)

Certication

• CE

• FCC

Simrad ES60 Marine Computer (rear side) Power supply
