Singer SDHM-16L-55DIA Manuale utente
GB
INSTRUCTION MANUAL
GR
ΒΙΒΛΙΟ ΟΔΗΓΙΩΝ
BG
ИНСТРУКЦИИ ЗА ЕКСПЛОАТАЦИЯ
Dehumidifier
Αφυγραντήρας
Влагоабсорбатор
SDHM-16L-55DIA &
SDHM-20L-55DIA
2
ENGLISH
Please keep this manual for future reference
INTRODUCTION
• Before using your new dehumidifier for the
first time, please read carefully the following
instructions.
• After removing the packaging, make sure that
the appliance is in good condition.
• Do not allow children to play with the packag-
ing materials as there is risk of suffocation.
The dehumidifier will remove excess moisture
from the air, creating a comfortable environment
for your home. Its compact design allows you to
easily move it to every room.
SAFETY INFORMATION
Please read the operating instructions care-
fully before using your dehumidifier for the
first time.
1. Install the unit on a stable flat surface to avoid loud
noises and vibrations.
2. Never immerse the unit in water or other liquids.
3. Never operate the unit if the cable or other con-
nector is damaged. If something abnormal hap-
pens, please call customer service for help.
3
ENGLISH
4. Disconnect the unit from power supply when it is
not in use or before relocating or cleaning it.
5. Operate the unit only at the specified voltage.
6. Do not put heavy objects on the appliance.
7. Do not tip the unit to any side as spilt water could
damage the appliance.
8. Never insert any other object into the unit body to
avoid any hazard or unit failure.
9. Do not put the unit close to heat-generating devic-
es or near flammable and dangerous materials.
10. This appliance is not intended for use by persons
(including children) with reduced physical, sen-
sory or lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person re-
sponsible for their safety. Children should be su-
pervised to ensure that they do not play with the
appliance.
11. If the supply cord is damaged, it must be replaced
by a qualified person in order to avoid any hazard.
12. The appliance must be positioned so that the plug
is accessible.
13. The ambient temperature range for the appliance
is 5°-35°.
14. Use the appliance only in the household and only
for the purpose it was developed for.
4
ENGLISH
15. The appliance shall be installed in accordance
with national wiring regulations.
16. Do not hang curtains or wet clothes in front of the
air outlet, this will overload the device.
17. The drainage hose may not be installed outdoors
at low temperatures.
18. To prevent spillage, empty the water tank before
relocating the appliance.
19. If you smell smoke during start-up or if you can
see smoke, immediately disconnect the power
plug and contact your dealer.
20. The device may not be connected to a power strip
with other household appliances.
21. If the device is not used for a long time, please
use the function of the internal drying. This will
prevent formation of mildew and unpleasant smell
inside the unit.
5
ENGLISH
SERVICE & REPAIR
1. For service or repair under warranty, please contact the authorized ser-
vice company that is mentioned on the guarantee card and accompanies
the product.
2. Do not operate any product with a damaged cord or plug. If the supply
cord is damaged, return the appliance to a SINGER service center for
examination, repair or adjustment. Do not attempt to dismantle any part
of the appliance. This should only be done at an authorized SINGER
service centre.
3. The partial or total non-respect of the safety instructions in the present
instruction manual will automatically release Singer of any type of re-
sponsibility in case of malfunction of the machine or injuries to persons
or animals.
4. In case of manipulation, repairing or any modification of the machine
made by unqualified persons or in case of improper use, the guarantee
will be automatically cancelled.
INSTALLATION
6
ENGLISH
Install the unit in a stable & flat floor and keep the room ventilated.
Leave at least 20cm space around the unit (when the hose is not connected).
1. Push the rubber adaptor of the water pipe on the drainage port of the rear
panel.
2. Connect the water pipe to bathroom, outdoor or a container, such as a
bucket.
NOTE:
1. Do not block the drainage port or water pipe.
2. Do not fold the water pipe or make it 0.5m higher than the bottom of unit.
3. Do not replace the rubber adaptor of the water pipe. It’s a special accessory
for the unit only; other adaptors may not fit the unit. If it’s damaged or lost,
please call the customer service for replacement.
PARTS
Front
Front panel
Castor
Control panel
Air Flow Cover
Water Tank
7
ENGLISH
Back
SPECIFICATIONS
MODEL No. SDHM-16L-55DIA SDHM-20L-55DIA
Dehumidify Capacity 16L/day (30℃,80%) 20L/day (30℃,80%)
Rated Voltage AC220-240V AC220-240V
Rated Frequency 50Hz 50Hz
Rated Power 340W (30℃,80%) 380W (30℃,80%)
Rated Current 2.0A (30℃,80%) 2.1A (30℃,80%)
Water Tank Capacity 5.5L 5.5L
Noise Level (min-max) 40 - 45dB(A) 40 - 45dB(A)
Refrigerant Charge R134a/140g R134a/160g
Product Dimension 335 x 240 x 587mm 335 x 240 x 587mm
Net Weight 14,5kg 15kg
Suction Side Pressure 0.5MPa 0.5MPa
Discharge Side Pressure 1.5MPa 1.5MPa
Handle
Filter Grid
Drainage Hole
Back Panel
8
ENGLISH
OPERATIONS
Indication
1. Power indicator
The power indicator lights up with a green color when the device is plugged in.
2. Water full indicator
When the water tank is full, the water tank indicator lights up with a red color,
the unit buzzes for 20 times and then stops. You must empty the water tank
and put it back to the correct position. If the water tank indicator is frequently
on, there might be some malfunction in the unit.
3. Timer indicator
The timer indicator lights up with a green color while the timer is running.
4. Low fan speed indicator
The low fan speed indicator lights up with a green color when the device is
working in low fan speed.
5. High fan speed indicator
The high fan speed indicator lights up with a green color when the device is
working in high fan speed.
9
ENGLISH
6. Drying clothes indicator
This indicator lights up with a green color when the drying clothes function is
on. At that mode, the compressor works continuously without the influence
of the room humidity. High fan speed is fixed and the humidity cannot be ad-
justed.
7. Normal mode indicator
This indicator lights up with a green color when normal dehumidifying function
is on. When you turn on the unit first time, the appliance will enter into normal
dehumidifying mode. At that mode, the default setting humidity is 60% and you
can set the desired humidity level and adjust the fan speed at your desired
speed.
8. Ionizer indicator
The ionizer will work automatically when the device is plugged in. This indica-
tor will light up with a green color.
9. Clean filter indicator
This indicator will light up with a red color and the unit buzzes for 20 times
when the accumulated running time has reached 600 hours in order to remind
the user to change the filter.
If you want to turn off this indicator, press the power button for 5 seconds, the
indicator light will turn off.
10. Display
This display shows the following 3 functions:
• The indoor humidity when the power is on.
• The selected humidity data when you adjust humidity.
• The timer data when you set the timer on/off.
10
ENGLISH
Button Operation
1.
p
Power
Press this button to turn on the device. The device will start to work in the de-
fault mode (humidity setting is 60%RH and fan speed depends on the speed
set on last dehumidification mode). The compressor will start to work after the
fan has already worked for 3 seconds, the indicator will light up with a green
color and the ionizer (purify) will start to work with the default setting.
If you want to turn off the device, press this button again. The display will show
“--” and the device will be in stand-by mode. The fan will turn off after 60 sec-
onds and the power indicator light and fan speed indicator light will turn off.
2. Timer button
Timer boot: press the Timer button to set up the auto- start time while the
device is on standby (you can choose between 1-24hours a cycle). The Timer
symbol will flash for 5 seconds. If no further operation is instructed, the device
will quit the setting mode automatically. LED will show the set time and the
countdown will start. The device will start dehumidification automatically when
the countdown ended. At that time, LED will show the humidity number instead
of the time.
Timer shutdown: Press the Timer button while the device is working to set
up the auto-stop time (you can choose between 1-24hours a cycle). LED will
show timing data and the Timer symbol will flash for 5 seconds. If no further
operation is instructed, the device will quit the setting mode automatically. LED
will switch to humidity number and the countdown will start. When the count-
down ends, LED will show “--” and the machine will stop without making any
buzzing alert.
Note: Timer does not have a memory function. Please set up the timer manu-
ally every time.
3. button
Press this button to adjust humidity as following (the initial humidity is 60%).
You can set the humidity as you want; 20%-25%-30%-35%-40%-45%-50%-
55%-60%-65%-70%-75%-80%. The machine will stop automatically when the
indoor humidity is lower than the set humidity.
