PARTS LIST
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1-1 Snap Ring HY01-00585 1-21 Lock ring HY01-00604
1-2 Wheel HY01-00586 1-22 Washer HY01-00605
1-3 Bolt HY01-00587 1-23 Bolt HY01-00606
1-4 Washer HY01-00588 1-24 Handle link HY01-00607
1-5 Right frame HY01-00589 1-25 Cover HY01-00608
1-6 Bolt HY01-00590 2 Hydraulic pump HY01-00609
1-7 Washer HY01-00591 4-1 Saddle D HY01-00610
1-8 Bolt HY01-00592 4-2 Saddle C HY01-00611
1-9 Washer HY01-00593 4-3 Saddle B HY01-00612
1-10 Bolt HY01-00594 4-4 Nut HY01-00613
1-11 Washer HY01-00595 4-5 Washer HY01-00614
1-12 Frame HY01-00596 4-6 Washer HY01-00615
1-13 Handle frame HY01-00597 4-7 Support plate HY01-00616
1-14 Left frame HY01-00598 4-8 Pin HY01-00617
1-15 Handle base HY01-00599 4-9 U-bolt HY01-00618
1-16 Screw HY01-00600 4-10 Saddle A HY01-00619
1-17
Spring washer
5 Handle HY01-00620
HY01-00601
1-18 6-1 / 6-24 Air motor HY01-00621
1-19 Universal Joint HY01-00602 7 Air hose HY01-00622
1-20 Pin HY01-00603
5
SAFETY INSTRUCTIONS….cont
WARNING! Only operate on a level and stable surface and never use on soft ground
where the Floor Jack is likely to “sink” whilst in operation.
NEVER STAND ON THE FLOOR JACK: The Floor Jack is not designed for this purpose.
DO NOT dismantle or tamper with the Floor Jack, as this may be dangerous and will
invalidate the warranty.
ALWAYS ensure the load is central on the saddle.
If a problem with the Floor Jack is experienced or suspected stop using the Floor
Jack immediately and contact your distributor for repair.
Do not attempt to lift a load that exceeds the rated capacity of the Floor Jack.
Do not attempt to lift a load beyond the maximum height of the Floor Jack.
This Floor Jack is a lifting device only.
Immediately after lifting, support the load with a pair of appropriately rated jack
stands.
Never work on, under or around a load supported only by the Floor Jack.
Regularly inspect and lubricate the Floor Jack, ensuring that it is in good working or-
der and condition.
Always ensure that the work area is clean and tidy, free from unrelated materials and
has adequate lighting.
When lifting a vehicle ensure a minimum distance of 0.5m between vehicle and
static objects such as doors, walls, etc. to allow for tilting during jacking.
Ensure that all persons are out of the vehicle before jacking.
DO NOT enter the vehicle whilst it is supported on the Floor Jack or axle stands.
Check vehicle weight and recommended lifting points by referring to the vehicle’s
manual. Ensure that the lifting point is not corroded.
DO NOT allow the vehicle to move, or try to start the engine, during jacking.
DO NOT start the engine when vehicle is jacked up.
DO NOT jack a vehicle if this may result in the spillage of fuel, battery acid, or other
dangerous substances.
Check that the Floor Jack saddle is centred and stable on the lifting point (off-centre
loads can slip).
Position the Floor Jack to avoid operating it from under vehicle.
Keep hands, limbs etc. clear of moving parts during the raising and lowering of the
vehicle.
DO NOT top-up the Floor Jack with brake fluid, or other oil types; use only hydraulic
oil.
DO NOT adjust the safety overload valve.
Ensure that there are no persons or obstructions beneath the load before lowering.
Clean and stow the Floor Jack correctly, with the ram in the down position, DO NOT
leave it extended; ensure storage area is dry.
IMPORTANT! Ensure that you can see the saddle and jacking point throughout the
jacking operation in case there is any relative movement.
Failure to follow the warnings in this manual, may result in personal injury and/or prop-
