Sitecom WL-347 Manuale utente

WL-347/WL-348

Wireless Broadband

modem/router

(ADSL2+, 802.11B/G/N draft 2.0)

User Manual

Version: 1.0

ABLE OF

ONTENTS

KEY FEATU ES ...................................................................................................................... 5

PACKAGE CONTENTS......................................................................................................... 6

P ODUCT LAYOUT .............................................................................................................. 7

NETWO K + SYSTEM EQUI EMENTS ................................................................... 9

WL-347/WL-348 PLACEMENT...................................................................................... 9

SETUP LAN, WAN............................................................................................................... 10

PC NETWO K ADAPTE SETUP (WINDOWS XP).............................................11

B INGING UP THE WL-347/WL-348 ..................................................................... 13

INITIAL SETUP WL-347/WL-348 ............................................................................ 13

CONFIGU ATION WIZA D...................................................................................... 22

WI ELESS SETTINGS ................................................................................................. 24

FI EWALL SETTINGS ................................................................................................. 35

ADVANCED SETTINGS................................................................................................ 41

TOOLBOX SETTINGS ................................................................................................... 53

Introduction

Congratulations on your purc ase of t e WL-347/WL-348 Wireless Network

Broadband modem/Router. T e WL-347/WL-348 is compliant wit draft

802.11n v 2.0 and up to 6 times faster t an standard 802.11g based routers

w ile still being compatible wit 802.11g & 802.11b gadgets. T e WL-

347/WL-348 is not only a Modem or Wireless Access Point, but also doubles

as a 4-port full-duplex Switc t at connects your wired-Et ernet devices

toget er at.

At 300 Mbps wireless transmission rate, t e Access Point built into t e

Modem/Router uses advanced MIMO (Multi-Input, Multi-Output) tec nology to

transmit multiple steams of data in a single wireless c annel, giving you

seamless access to multimedia content. Robust RF signal travels fart er,

eliminates dead spots and extends network range. For data protection and

privacy, t e WL-347/WL-348 encodes all wireless transmissions wit WEP,

WPA, and WPA2 encryption.

Wit an inbuilt DHCP Server & powerful SPI firewall t e WL-347/WL-348

protects your computers against intruders and most known Internet attacks

but provides safe VPN pass-t roug . Wit t e incredible speed and QoS

function of 802.11n(draft2.0), t e WL-347/WL-348 is ideal for media-centric

applications like streaming video, gaming, and VoIP telep ony to run multiple

media-intense data streams t roug t e network at t e same time, wit no

degradation in performance.

1 Key Features

Features Advantages

Incredible Data Rate up to

300Mbps**

Heavy data payloads suc as MPEG

video streaming

IEEE 802.11n draft 2.0 Compliant

and backward compatible wit

802.11b/g

Fully Interoperable wit IEEE

802.11b / IEEE802.11g compliant

devices wit legacy protection

Four 10/100 Mbps Fast Switc Ports

(Auto-Crossover)

Scalability, extend your network.

Firewall supports Virtual Server

Mapping, DMZ, IP Filter, ICMP

Blocking, SPI

Avoids t e attacks of Hackers or

Viruses from Internet

Support 802.1x aut enticator,

802.11i (WPA/WPA2, AES), VPN

pass-t roug

Provide mutual aut entication (Client

and dynamic encryption keys to

en ance security

Integrated modem (Annex A) Fully compatible wit t e fastest

ADSL2+ connections up-to-date.

** Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset

used. Actual throughput ma var . Network conditions and environmental factors

lower actual throughput rate. All specifications are subject to change without notice.

2 Package Contents

Open t e package carefully, and make sure t at none of t e items listed

below are missing. Do not discard t e packing materials, in case of return;

t e unit must be s ipped back in its original package.

1. WL-347/WL-348 modem/router

2. 220V ~ 240V Power Adapter

3. Quick Install Guide

4. CD (User’s Manual)

5. Warranty card

6. UTP cable

3 Product Layout

Port Description

ADSL Connect your telep one/ADSL cable t is port

LAN

Connect t e cable from your PC’s or network

devices to t is port

Power connector Blinks on traffic for specific LAN PORT

Reset button

Power connector

LAN / computer connections

Modem connection

Front panel

T e front panel describes t e corresponding LED indications and port

functionality.

LED Description

POWER Lig ts up w en powered ON. Blinks

on TEST/RESET

Wan Lig ts up w en an ADSL cable is

connected.

Online Lig ts up w en internet connection is

UP.

WLAN Lig ts up in Blue w en WLAN is

enabled. Blinks on traffic

WPS Blinks w en WPS mode is on

Lan1 - Lan4 W en a lan cable is connected t e

corresponding lig t lig ts up.

4 Network + System equirements

To begin using t e WL-347/WL-348, make sure you meet t e following

as minimum requirements:

• PC/Notebook.

• Operating System – Microsoft Windows XP/2000/VISTA

• 1 Free Et ernet port.

• Wi-Fi card/USB dongle (802.11 b/g/n) – optional.

• Annex A, ADSL internet connection.

• PC wit a Web-Browser (Internet Explorer, Safari, Firefox, Opera)

• Et ernet compatible CAT5 cables.

5 WL-347/WL-348 Placement

You can place t e WL-347/WL-348 on a desk or ot er flat surface, or

you can mount it on a wall. For optimal performance, place your

Wireless Broadband Modem/Router in t e center of your office (or your

ome) in a location t at is away from any potential source of

interference, suc as a metal wall or microwave oven. T is location

must be close to a power connection and t e ADSL/p one line s ould

not be over 2 meters long.

6 Setup LAN, WAN

LAN / computer connections

Modem connection
