SMART Board M600 series Manuale utente

SMARTBoard® M600

series

Interactive whiteboard

User’s guide

For models M680, M685, M680V and M685V

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

smarttech.com/kb/170410

FCC warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio communications. Operation of

this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Trademark notice

SMARTBoard, SMARTNotebook, DViT, SMARTInk, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of

SMARTTechnologiesULC in the U.S. and/or other countries. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the U.S.

and/or other countries. Mac is a trademark of Apple Inc., registered in the U.S. and other countries. All other third-party product and company names may be trademarks of

their respective owners.

into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to change without notice

and does not represent a commitment on the part of SMART.

This product and/or use thereof covered by one or more of the following U.S. patents: smarttech.com/patents. Contents are subject to change without notice.

09/2013

i smarttech.com/kb/170410

Important information

Before you install and use your SMARTBoard® M600 series interactive whiteboard, read and

understand the safety warnings and precautions in this user’s guide and the included warnings

document. The included warnings document describes the safe and correct operation of your

SMARTBoard interactive whiteboard and its accessories, helping you to prevent injuries and

equipment damage.

N O T E

In this document, the term “interactive whiteboard” refers to your interactive whiteboard and its

accessories and options.

iii smarttech.com/kb/170410

Contents

Important information i

Chapter 1: Introducing your SMARTBoard M600 series interactive whiteboard 1

Introduction 1

Features 2

Computer requirements 2

How does your SMARTBoard interactive whiteboard work? 3

Installation tips 4

Accessories and replacement parts 5

Chapter 2: Connecting your interactive whiteboard to a computer 7

Overview 7

Installing SMARTProductDrivers 8

Calibrating your interactive whiteboard 8

Orienting your interactive whiteboard 9

Chapter 3: Using your interactive whiteboard 11

Using the Pen Tray 12

Using the Floating Tools toolbar 14

Using gestures, dual touch and dual write 15

Updating your SMART software 19

Chapter 4: Maintenance and troubleshooting 21

Tips for trouble-free performance 21

Cleaning your interactive whiteboard 22

General troubleshooting 23

Transporting your interactive whiteboard 29

Contacting SMARTSupport 29

Appendix A: Hardware environmental compliance 31

Waste Electrical and Electronic Equipment and Battery regulations (WEEE and Battery

Directives) 31

Batteries 31

Index 33

Chapter 1

1 smarttech.com/kb/170410

Chapter 1: Introducing your SMARTBoard

M600 series interactive

whiteboard

Introduction 1

Features 2

Feature highlights 2

Pen tray 2

DViT technology 2

Multitouch gestures 2

Dual touch and dual write 2

Durable surface 2

Computer requirements 2

How does your SMARTBoard interactive whiteboard work? 3

Windows and Mac computers 3

Installation tips 4

Extending your USB cable 4

Avoiding electromagnetic interference (EMI) 5

Accessories and replacement parts 5

Introduction

Your SMART product is a wall-mounted, front projection interactive whiteboard. It enables you to do

everything that you can do at your computer—open and close applications, scroll through files, teach

collaborative lessons, create new documents or edit existing ones, visit websites, play video clips

and more—by touching the interactive surface with your finger or the included pen. When you connect

your interactive whiteboard to a computer and a projector, your computer image displays on the

interactive surface. You can write over any application in digital ink, and then save these notes to a

file in SMARTNotebook™ collaborative learning software for future reference and distribution.

Your SMARTBoard M600 series interactive whiteboard is a full-speed USB 2.0 device with an

external power supply. Your interactive whiteboard receives power from a wall outlet through the

included country-specific power supply and cable.

C H A P T E R 1

Introducing your SMART Board M600 series interactive whiteboard

2 smarttech.com/kb/170410

Features

Your SMARTBoard M600 series interactive whiteboard is durable and reliable. It features a rugged,

hardened interactive surface, two damage-resistant pens and SMART’s proprietary DViT®

(DigitalVisionTouch) technology. The SMARTBoard M680 interactive whiteboard measures

195.6cm(77") diagonally and has a 4:3 aspect ratio, while the M685 interactive whiteboard measures

221cm (87") diagonally and has a 16:10 aspect ratio.

Feature highlights

Pen tray

The pen tray connects to the interactive whiteboard and holds the two included pens. It features color

select buttons to change digital ink colors. The on-screen keyboard, the right-click and the orient

features are also accessible with pen tray buttons.

SMARTBoard M680V and M685V interactive whiteboards feature a durable pen ledge that holds the

two included pens.

DViT technology

Four digital cameras, one in each of the interactive whiteboard’s corners, track the position of your

finger or the pen as it moves across the interactive surface.

Multitouch gestures

Your interactive whiteboard supports multitouch gestures (Windows® and Mac only). You can use

two fingers to resize an object on a page, to zoom in and out, to rotate an object and more.

Dual touch and dual write

Your interactive whiteboard supports dual touch (Windows and Mac only). Two users can use their

fingers to simultaneously perform mouse functions or write on the interactive whiteboard.

Durable surface

The interactive surface is scratch-resistant, dent-resistant and optimized for projection.

Computer requirements

To successfully power your interactive whiteboard and run SMARTProductDrivers, your computer

must meet certain minimum requirements. For a complete list of computer requirements, go to

smarttech.com/downloads and browse to the latest SMARTNotebook software release notes

applicable to your operating system.

C H A P T E R 1

Introducing your SMART Board M600 series interactive whiteboard

3 smarttech.com/kb/170410

How does your SMARTBoard interactive

whiteboard work?

Your interactive whiteboard functions as an input device for your computer, enabling you to work in

any application on your connected computer. You need two additional components to use your

interactive whiteboard: a computer and a digital projector. These components work together as

follows:

lYour computer runs an application and sends the image to your projector.

lYour projector casts the image onto your interactive whiteboard.

lYour interactive whiteboard detects contact with its screen and sends each contact point to the

connected computer.

Use the pen tray buttons to select different tools. For example, press the left-click button so that

when you touch your interactive whiteboard’s surface, the touch of your finger becomes a mouse

click and you can control your computer from your interactive whiteboard. When you pick up a pen

and press one of the color buttons, digital ink appears, enabling you to write over your desktop or any

open application.

When you install SMARTProductDrivers, a Floating Tools toolbar appears on your desktop. You can

change pen settings such as the transparency, color and width of the ink. You can then save your

notes to a file in SMARTNotebook software. You can also customize other tools, such as the width

of the eraser tool you use to erase your notes.

Windows and Mac computers

SMARTNotebookcollaborative learning software includes SMARTInk™ and

SMARTProductDrivers. SMARTInk works with SMARTProductDrivers to enable you to write on

your screen in digital ink using your interactive product’s pen or your finger.

SMARTInk starts automatically when you start your computer, and the

SMARTInk toolbar appears in the title bar of each open window on your

computer.

N O T E

SMARTNotebook software doesn’t display the SMARTInk toolbar because it includes its own ink

tools that you can use to write directly in your file.

You can press SMARTInk to select ink properties and to perform common tasks such as

capturing your notes.

C H A P T E R 1

Introducing your SMART Board M600 series interactive whiteboard

4 smarttech.com/kb/170410

SMARTInk includes SMARTInk Notes which enable you to write in digital ink anywhere on your

desktop. When you write outside of the open windows on your computer, a SMARTInk Note appears

and you can write inside the note.

SMARTInk also includes the SMARTInk Document Viewer, which enables you to view your

PDFfiles and to write over them in digital ink.

For more information on using SMARTInk, see the SMARTInk user’s guide

(smarttech.com/kb/170191).

Installation tips

For the installation instructions for your SMARTBoard M600 series interactive whiteboard, see the

SMARTBoard M600 series interactive whiteboard installation guide (smarttech.com/kb/170429). If

you purchased a floor stand, wall-mount or an interactive whiteboard system that includes a projector

or other components, refer to the installation documents included with those components.

The optimal mounting height is 196 cm (77") from the floor to the center of the installation brackets.

However, consider the general height of your user community when you choose a location for

wall-mounting your interactive whiteboard and adjust accordingly.

Ensure that you use the correct mounting hardware for your wall type. You can also order the

SMARTBoard interactive whiteboard hardware kit (Part No. 1020342) from your authorized SMART

reseller.

Extending your USB cable

The USB cable included with your SMARTBoard M600 series interactive whiteboard is within the

limit defined by the USB standard for maximum length. Your interactive whiteboard includes a 5 m

(16') USB cable.

I M P O R T A N T

The combined USB cables connected from your interactive whiteboard to your computer should not

exceed 5 m (16' 5").

However, if this cable isn’t long enough to reach from your computer to your interactive whiteboard,

you can use a bus-powered hub, such as the active USB extension cable (Part No. USB-XT) to

extend your USB connection.
