USER’S GUIDE

FOR MODELS KAPP42 AND KAPP84

smarttech.com/kb/170769

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

Trademark notice

DViT, kapp, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of SMARTTechnologiesULC in the U.S. and/or other

countries. Apple, App Store, iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries. Android and GooglePlay are trademarks

of Google Inc. The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative

Commons 3.0 Attribution License. The Bluetooth word mark is owned by the Bluetooth SIG, Inc. and any use of such marks by SMARTTechnologiesULC is under

license. All other third-party product and company names may be trademarks of their respective owners.

translated into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to change

without notice and does not represent a commitment on the part of SMART.

This product and/or use thereof covered by one or more of the following U.S. patents.

www.smarttech.com/patents

02/2015

i smarttech.com/kb/170769

Important information

WARNING

lYour SMART product includes instructions for installation on metal and wood stud walls and

certain masonry wall types only. A SMART hardware kit is available for these types of

installation (Part No. 1024563). In the event that you need to install your SMART product on

reinforced concrete walls, walls with plaster lath finishing or other types of walls, refer to

your local building authority for instructions, recommendations and safe work practices.

lDo not open or disassemble the SMART product. You risk electrical shock from the high

voltage inside the casing. Opening the casing also voids your warranty.

lEnsure that any cables extending across the floor to your SMART product are properly

bundled and marked to avoid a trip hazard.

lEnsure your installation complies with local building and electrical codes.

lFailure to follow the installation instructions shipped with your SMART product could result in

personal injury and product damage which may not be covered by your warranty.

lTo reduce the risk of fire or electric shock, do not expose the SMART product to rain or

moisture.

lUse SMART supplied mounting hardware or hardware that is designed to properly support

the weight of your product.

lUse the power cable provided with this product. If a power cable is not supplied with this

product, please contact your supplier. Use only power cables that match the AC voltage of

the power outlet and that comply with your country’s safety standards.

lDo not place any heavy objects on the power cable. Damage to the cable could cause

shock, fire or product damage which may not be covered by your warranty.

iii smarttech.com/kb/170769

Contents

Important information i

Chapter 1: Welcome 1

About your SMARTkapp 42" capture board 2

About your SMARTkapp 84" capture board 3

About this guide 5

Supported browsers 5

Other documentation and resources 5

Specifications 5

Installation instructions 6

Tutorial and Help 6

Training 6

Frequently asked questions 6

Support center and knowledge base 7

This chapter introduces you to your SMARTkapp™ capture board and this guide.

CHAPTER 1

WELCOME

2 smarttech.com/kb/170769

About your SMARTkapp 42" capture board

The SMARTkapp 42" capture board enables you to collaborate with others in a simple but

powerful way. Write and draw on the capture board like you would a regular dry erase board. You

can then connect a Bluetooth®-enabled mobile device to the capture board by scanning a

QuickResponse (QR) code or by tapping the NearField Communication (NFC) tag. When you first

connect your mobile device, you’re directed to the AppleAppStore or GooglePlay™ store to

download the SMARTkapp app. After you download and install the app, you can use it to connect

to your capture board and share content with others.

The SMARTkapp 42" capture board product consists of the following components:

lCapture board

lDry erase markers and eraser

lMounting bracket and hardware

lSMARTkapp app

Capture board

The capture board features SMART’s proprietary DViT® (DigitalVisionTouch)

technology on a 42" (107cm) writing surface. DViT technology captures the

notes you make on the capture board using the dry erase markers and eraser.

The capture board’s Bluetooth 4.0 wireless technology (for Apple mobile

devices) or Bluetooth 2.1 + EDR wireless technology (for Android™ mobile

devices) then transfers your notes as a digital image to a connected mobile

device. Alternatively, you can save your notes to a FAT-formatted USB drive by

connecting it to the capture board’s USB 2.0 Type-A receptacle. You can also

use the capture board’s standard 500 mA USB 2.0 Type-A receptacle to charge

your smart phone.

Dry erase markers and eraser

Your capture board comes with three dry erase markers and an eraser that are specially designed

to work with the captureboard.

CHAPTER 1

WELCOME

3 smarttech.com/kb/170769

The capture board includes holders for one marker and the eraser as well as a storage area (on the

back of the capture board) for the other two markers.

Mounting bracket and hardware

You can mount your capture board on a wall using the supplied mounting bracket and hardware.

Alternatively, you can mount the capture board using a standard VESA® 400 mm × 400 mm

mounting bracket.

SMARTkapp app

The SMARTkapp app enables you to connect your Apple or Android mobile device to your

capture board and then do the following:

lView notes you write on your capture board on your mobile device

lShare your notes with others

lSave your notes

About your SMARTkapp 84" capture board

The SMARTkapp 84" capture board enables you to collaborate with others in a simple but

powerful way. Write and draw on the capture board like you would a regular dry erase board. Two

people can draw at the same time. You can then connect a Bluetooth-enabled mobile device to

the capture board by scanning a QuickResponse (QR) code or by tapping the NearField

Communication (NFC) tag. When you first connect your mobile device, you’re directed to the

AppleAppStore or GooglePlaystore to download the SMARTkapp app. After you download and

install the app, you can use it to connect to your capture board and share content with others.

The SMARTkapp 84" capture board product consists of the following components:

lCapture board

lDry erase markers and eraser

CHAPTER 1

WELCOME

4 smarttech.com/kb/170769

lMounting bracket and hardware

lSMARTkapp app

Capture board

The capture board features SMART’s proprietary DViT

technology on a 84" (213cm) writing surface. DViT technology

captures the notes you make on the capture board using the dry

erase markers and eraser. The capture board’s Bluetooth 4.0

wireless technology (for Apple mobile devices) or Bluetooth 2.1

+ EDR wireless technology (for Android mobile devices) then

transfers your notes as a digital image to a connected mobile

device. Alternatively, you can save your notes to a

FAT-formatted USB drive by connecting it to the capture board’s

USB 2.0 Type-A receptacle. You can also use the capture

board’s standard 500 mA USB 2.0 Type-A receptacle to charge your smart phone.

Dry erase markers and eraser

Your capture board comes with six dry erase markers and an eraser that are specially designed to

work with the captureboard.

Mounting bracket and hardware

You can mount your capture board on a wall using the supplied mounting bracket and hardware.

Alternatively, you can mount the capture board using a standard VESA 600 mm × 400 mm

mounting bracket.

SMARTkapp app

The SMARTkapp app enables you to connect your Apple or Android mobile device to your

capture board and then do the following:

lView notes you write on your capture board on your mobile device

lShare your notes with others

lSave your notes
