SCX-TX550
point to multi-point transmitter up to 5 displays
also available:
SCX-TX600 transmitter for up to 6 displays
user guide
Edition 2, September 2008
Copyright 2008 Smart-e (UK) Ltd.
Notice
The information contained in this document is subject to change without
notice. Smart-e makes no warranty of any kind with regard to this
material, including but not limited to, implied warranties of
merchantability and fitness for particular purpose.
Smart-e will not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance
or use of this material.
No part of this document may be photocopied, reproduced, or
translated into another language without prior written consent from
Smart-e (UK) Ltd.
Introducing SmartCast
What ‘s in the box ..........................................................................................1
What is SmartCast.........................................................................................2
Why is SmartCast necessary....................................................................2
How does SmartCast work.........................................................................2
Installation and Operation
Transmitter.........................................................................................................3
Receiver Options ..............................................................................................11-34
Appendix
Specifications.....................................................................................................35
Troubleshooting................................................................................................40
Limited warranty statement.......................................................................41
Partial Product List............................................................................................ Back
Table of Contents
Introducing SmartCast AV Distributor
What‘s in the box?
Thank you for buying the Smart-e SmartCast Cat5 AV Transmitter. Depending
on the configuration of your system various quantities of the parts below may
be included in your shipment, also functionality will vary depending on the
receivers that you ordered.
If any of the transmitter parts listed below are missing please contact the
Smart-e dealer you purchased products from or contact Smart-e customer
support at:
+44 (0) 1306 628264
SmartCast Cat5 Transmitter Parts List:
SmartLynx Receivers Functionality:
-1-
Item Inputs SCX-TX550
Transmitter Unit Cat5 One Input to Five
Output Transmitter unit Yes
24V Earthed PSU DC24V 20W Power Supply Yes
Mains Cable Standard PSU Mains Cable Yes
Function SLX-RX100 SLX-RX111 SLX-RX211 SLX-RX212 SLX-RX212D
Short Range
Receiver No Yes No No No
Long Range
Receiver Yes No Yes Yes Yes
Multiple Discrete
Connectors No Yes Yes Yes Yes
Dual Screen
Output No No No Yes Yes
Cascadable Units No No No No Yes
IR and RS232
Pass-through No Yes Yes Yes Yes
Introducing SmartCast AV Distributor
-2-
What is SmartCast?
The SmartCast is a combination of transmitter and receiver devices
designed to transmit high resolution computer video and/or audio signal
over Cat 5 wire. AV stands for Audio Visual and includes such signal
formats as High-Definition and Standard Definition Video, Broadcast Video
(TV video signal), Computer Video (VGA, SVGA, SXGA and etc. signals) and
various formats of Audio signals.
Why is SmartCast necessary?
Sometimes AV signals need to be transmitted over distances greater than
commonly specified product limitations of 5m. In this case several choices
are available, but most are expensive and bulky, which is in some cases
simply not practical, due to space limitations in the conduits.
The SmartCast allows the transmission of AV signals over a standard Cat 5
UTP cable over distances of up to 300m. The actual distance is a function
of the signal resolution and cable quality. The following is a rough guide to
distance and resolution:
How does SmartCast work?
The Smart-e SmartCast is designed to transmit desktop computer video
and stereo audio signals over (UTP) unshielded twisted pair category 5 (Cat
5) cabling. They are supplied with a UK power supply and consists of a
transmitter with one input and five outputs (Cascade able up to 20
outputs).
The transmitted signals depends on the model but supported signals are
CVBS, YUV, Y/C, RGsB, RGBS analogue format and Stereo Audio. The
basic concept behind this product is the ability to encode and decode
analogue signal combined with precise line equalization and compensation.
Cat5 Cable Length Maximum Recommended Resolution
200m UXGA (1600x1200)
200m 1080p (1920x1080)
300m SXGA (1280x1024)
1. Preparing for installation
Start installation process by ensuring that all video displays and audio
devices are compatible with the computers being used.
This is accomplished by connecting the devices directly to the computer
and checking that the devices operate as desired without the SmartLynx
system.
Install CAT-5 wiring between desired locations. In order to minimize system
operation difficulties, avoid routing the system cables near fluorescent
lights, air conditioners, or machines that may create electrical noise.
Installation and Operation
-3-
2. Connecting Video to the transmitter
2.1 Connect the video output of the source device to the input of
the transmitter using a standard HD15 VGA cable, or the
relevant interface cable if using another video format.
2.2 If using RGBS please ensure that the transmitter is configured
correctly - see page 9.
2.3 For all video types other than RGBS the transmitter is already
configured correctly.
Installation and Operation
-4-
Installation and Operation
-5-
3. Connecting Audio and Infra-red to the transmitter
3.1 Connect the audio output of the source device to the ‘audio in’ mini
jack connectors on the SCX-TX550, using a stereo minijack cable or
interface cable if appropriate.
3.2 If using Infra-Red connect the SM-LED or SM-EYE to the relevant
minijack connectors shown in the diagram below.
4. Connecting RS232/422 to the transmitter
4.1 Using the RS232-RS422 converter (AL-300) and adaptor cable
(CAB-R19-1M) provided, connect to an available serial port on the
control system/computer.
(If not using the supplied cable please contact your nearest Smart-e
distributor or call +44 1306 628264 for pin out information)
4.2 Connect the RJ45 on the adaptor cable to the left RJ45 socket on
the transmitter, this is labelled “RS232 IN” on the diagram below.
4.3 You may connect the unit to additional cascaded units using a
standard (NOT cross-over) patch cable to connect the Right RJ45
socket (RS232 OUT)’ to the left RJ45 socket (RS232 IN) on the
following unit.
4.4 In order to cascade the serial control, each transmitter must have a
unique address allocated - this is set by adjusting the rotary hex
switch. There are 16 positions (0-F) allowing up to 16 units to be
cascaded
Installation and Operation
-6-
5. Connecting the looping output or local monitor.
5.1 For Video connect the HD15 marked on the diagram ‘Video OUT’ to:
If using the cascading feature - the HD15 marked on the diagram as
’Video IN’, on the second unit.
If using a local monitor - the HD15 PC In on the monitor.
For both situations use a standard VGA cable.
5.2 For Audio connect the minijack marked on the diagram as ‘Audio
OUT’ to:
If using the cascading feature - the minijack marked on the diagram
as ’AUDIO IN’, on the second unit.
If using a local monitor/speakers - the minijack audio IN on the
monitor/speakers.
For both situations use a standard stereo minijack cable.
Installation and Operation
-7-
