www.smc-europe.com www.smc.com

EZ Connect™

Wireless Ethernet Adapter

Data Sheet

SMC2670W

2.4GHz 11 Mbps Wireless Ethernet Adapter

The EZ Connect™ 2.4GHz 11 Mbps Wireless EthernetAdapter (SMC2670W)

converts any Ethernet device in your home and/or office to become a wireless

device in minutes. This product transforms any Ethernet equipped device,

such as a gaming console, printer, set-top box, point-of-sale terminal, desktop

or laptop computer into wireless network device instantaneously. Using the

standard IEEE 802.11b technology, this Wireless Ethernet Adapter supports

transfer speeds up to 11 Mbps with a maximum operating range up to 250m.

The new SMC2670W Wireless Ethernet Adapter is easy and simple to install.

It is Plug-and-Play™and does not require installing any drivers. Simply plug it

into your Ethernet device and your Ethernet device will become wireless! This

means now you can have the freedom of placing your printer anywhere in the

home or office or play games with multiple players over a wireless connection

without the constraint of messy cabling.

To ensure secure transmission across wireless network, users can use the Web-

based interface or Windows Utility program to configure the 64-bit or 128-bit

WEP encryption. In addition, the EZ Connect Wireless Ethernet Adapter offers

an auto-fallback feature that provides connectivity at 11, 5.5, 2, and 1 Mbps

under noisy environments and enables a larger wireless operating range.

Features and Beneﬁts

High Performance & Functionality

•Plug-and-Play, no drivers needed

•IEEE 802.11b Compliant

•Up to 11 Mbps wireless LAN

•2.4 GHz frequency band, Direct Sequence Spread Spectrum (DSSS)

•64-bit or 128-bit WEP encryption

•Web and Windows-based conﬁguration and management for advanced conﬁguration

Compatibility

•IEEE 802.11b

•Windows 98/ME/NT/2000/XP

Product Model No Description

SMC2670W 2.4GHz 11 Mbps Wireless Ethernet Adapter

EZ Connect

Wireless Ethernet Card

Specifications

Physical Characteristics

Standards

•IEEE 802.11b

•IEEE802.3 (10Base-TX)

Management

•Windows-Based

•Web-Based

Security

•64-bit/128-bit WEP encryption

LAN

•1 *10BaseT RJ-45 LAN port

LED

•Power

•Wireless

•Ethernet

Power Supply

•DC 5V

Operating Frequency

•America/FCC: 2.412~2.462 GHz

(11 channels)

• Europe CE/ETSI: 2.412~2.472 GHz

(13 channels)

• Japan: 2.412~2.484 GHz

(14 channels)

• France: 2.457~2.472 GHz

(4 channels)

• Spain:2.457~2.462GHz

(2 channels)

RF Power Output

•20 dBm (typical)

Data Rate

• 11Mbps / 5.5 Mbps / 2Mbps /

1 Mbps Auto Fallback

Operating Range

•Up to 250m

(distance performance may be

effected by variables such as

barrier composition and local

environment interference)

Sensitivity

•-75 dBm @11Mbps, PER<8

Power Consumption

•Transmission: 800mA

•Receiving: 350mA

Network Conﬁguration

•Infrastructure

Operating Temperature

•-10~65ºC

Storage Temperature

•-30~70ºC

Humidity (non-condensing)

•5~95%

Antenna

•External Dipole Antenna

Dimensions

•117mm*62mm*22mm

Weight

•<75g

Warranty

•Limited lifetime warranty

www.smc-europe.com www.smc.com

EZ Connect™

Wireless Ethernet Adapter

SMC2670W

SMC Networks Europe

Head Ofﬁce

Ediﬁcio Conata II

Fructuós Gelabert 6-8 20, 4a

08970 - Sant Joan Despi

Barcelona

Spain

Telephone: +34 93 477 4920

Facsimile: +34 93 477 3774

SMC Networks Central Europe

Telephone: +49 (0) 89 92861-0

Facsimile: +49 (0) 89 92861-230

SMC Networks CIS

Telephone: +7 095 789 35 73

Facsimle: +7 095 789 35 73

SMC Networks Denmark

Telephone: +45 (0) 566 62283

Facsimile: +45 (0) 566 62286

SMC Networks Eastern Europe

Telephone: +49 (0) 89 92861 142

Facsimile: +49 (0) 89 92861-230

SMC Networks Italia

Telephone : +39 (0) 33 55 70 86 02

SMC Networks Netherlands

Telephone: +31 627 075227

Facsimile: +31 334 557 330

SMC Networks Nordic

Telephone: +46 (0) 8 687 0700

Facsimile: +46 (0) 8 87 62 62

SMC Networks Northern Europe

Telephone: +44 (0)118 974 8700

Facsimile: +44 (0)118 974 8701

SMC Networks North West Africa

Telephone: +216 71 23 66 16

Facsimle:+216 71 75 14 15

SMC Networks Sub-Saharan Africa

Telephone: +27 113 14 48 73

Facsimile: +27 113 14 91 33

SMC Networks South-East Europe

Telephone: +49 (0) 89 74 08 00 80

Facsimile: +49 (0) 89 74 08 00 81

SMC Networks Southern Europe

Telephone: +33 (0) 1 41 38 32 32

Facsimile: +33 (0) 1 41 38 01 58

SMC Networks Spain and Portugal

Telephone: +34 (0) 636 2043

Facsimile: +34 (0) 636 2044

SMC Switzerland

Telephone:+41 (0) 19409971

Facsimile:+41 (0) 19409972

SMC is a registered trademark; and EtherPower, EZStart, SimulTasking, TigerSwitch and SuperDisk are trademarks of SMC Networks, Inc.

2.4GHz 11 Mbps Wireless

Ethernet Adapter
