SMC Networks HP1D-USB - annexe 1 Manuale utente

Verify you have the following items included in the EZ Connect™ Powerline to USB

Desktop Adapter package.

• 1 SMCHP1D-USB EZ Connect™ 14 Mbps Powerline to USB Desktop Adapter.

• 3 Power Adapters (US/UK/EU).

• 1 USB Cable.

• Quick Installation Guide.

• 1 EZ Installation CD including.

- EZ Install Wizard

- USB Drivers

- EZ Configuration Utility 1.0

- User Guide

Immediately inform your dealer in the event of any incorrect, missing or damaged

parts. If possible, please retain the carton and original packing materials in case there

is a need to return the product.

Please register this product and upgrade the product warranty at SMC's Web site:

www.smc.com or www.smc.europe.com.

Package contents

Hardware Description

The EZ ConnectTM 14 Mbps Powerline to USB Desktop Adapter (SMCHP1D-USB)

is equipped with:

• 1 USB 1.1 connection.

• 1 Powerline connection.

There are two LED indicators to display status, connectivity, and data traffic:

The EZ Connect™ 14 Mbps Powerline to USB Desktop Adapter (SMCHP1D-USB) is the

easiest way to create or extend a home network. The Powerline to USB Desktop Adapter is

compatible with Windows 98, Me, 2000, XP, and is ideal for connecting a desktop or

laptop in another room of the house without having to run expensive CAT-5 cabling.

Combine the EZ ConnectTM Powerline to USB Adapter with the EZ ConnectTM Powerline to

Ethernet Desktop Adapter (SMCHP1D-ETH) for a complete Powerline solution from your

Router to your PC.

LED (Label)

Power

(PWR)

Powerline

(HP)

Color

Green

Activity

Solid LED indicates that the unit is powered on.

No LED light indicates the unit is powered off.

Solid LED indicates that a Powerline signal is detected.

Blinking LED indicates traffic is being transmitted.

No LED light indicates no Powerline signal is detected.

Thank you for choosing the SMC EZ Connect™

14 Mbps Powerline to USB Desktop Adapter.

This EZ Quick Installation Guide will guide

you through a simple process for getting

your new SMC product installed.

Put the EZ Installation CD into your

CD-ROM drive.

EZ Connect

Powerline

to USB Desktop Adapter

Quick Installation Guide

EZ Installation CD

Connection Information

When the EZ Installation Wizard launches;

click on the [Install USB Drivers] option.

Note: If the EZ 3-Click Installation Wizard

does not start automaticallythen you

can manually launch the program by

viewing the contents of the CD ROM

and double-clicking on the Powerline

adapter Icon.

To complete the utility installation you will

need to reboot your PC.

After the USB Drivers are installed, click on

the [Install EZ Configuration Utility] option.

Install Utility

SMCHP1D-USB

Reboot PC

Connect Hardware

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable.

However, no responsibility is assumed by SMC for its use, nor for any infringements of

patents or other rights of third parties, which may result from its use. No license is

granted by implication or otherwise under any patent or patent rights of SMC.

SMC reserves the right to change specifications at any time without notice.

SMC is a registered trademark; and EZ ConnectTM is a trademark of SMC Networks, Inc.

Other product and company names are trademarks or registered trademarks of their

respective holders.

FOR TECHNICAL SUPPORT, CALL:

From U.S.A. and Canada

(24 hours a day, 7 days a week)

(800) SMC-4-YOU;

Phn: (949) 679-8000;

Fax: (949) 679-1481

From Europe: Contact details can be found

on www.smc-europe.com or www.smc.com.

INTERNET

E-mail addresses:

[email protected]

european.techsupport@smc-europe.com

World Wide Web:

http://www.smc.com/

http://www.smc-europe.com/

If you are looking for further contact

information, please visit www.smc.com

or www.smc-europe.com.

Model Number: SMCHP1D-USB

Driver updates:

http://www.smc.com/index.cfm?action=tech_support_drivers_downloads

While your PC is rebooting, connect the

Powerline to USB Adapter to the USB Port on

your PC and then connect the powerline cord

to a power outlet. The USB device will be

found and installed on your Windows PC,

please follow the steps to complete the

driver installation. When completed, the

adapter installation will be complete.

Note: For more information on how to use

the utilities advanced features, please

refer to the user guide on the CD.
