OVERVIEW

The Barricade™ Broadband Router (SMCBR21VPN) is an ideal networking solution for the SMB. This multi-

function router combines load balancing WAN ports, a DMZ port and a 10/100 LAN port. It has a built in

robust Stateful Inspection ﬁrewall to protect your network from the edge. The Barricade supports protocols

such as TCP/IP, while also providing support for VPN connections with PPTP and IPSec. SMCBR21VPN’s

Stateful Packet Inspection Firewall provides a high level of security against Denial of Service (DoS) attacks.

It also provides ﬂexible Access Control to allow greater ﬂexibility in protecting your network. Having built in

multiple WAN ports enables load balancing based on different parameters or redundant internet connections

to protect against business critical internet downtime.

The new Broadband Router has built-in Virtual Private Network (VPN) support, which is an ideal solution

for securely accessing a remote corporate network by establishing an authenticated and encrypted tunnel

over the Internet. Whether used by travelers and telecommuters to remotely log into a corporate LAN, or to

establish a secure VPN between remote ofﬁces, you can be well assured that your data is being transmitted

and exchanged in the most secure manner.

www.smc.com

SMCBR21VPN

Barricade™ Dual WAN Port Load Balancing VPN Router

10G FIBER

1G FIBER

10G COPPER

1G COPPER

10/100

PoE

WIRELESS

LEGEND

10G FIBER

1G FIBER

10G COPPER

1G COPPER

10/100

PoE

WIRELESS

LEGEND





















 





APPLICATION DIAGRAM

POWER TO CONNECT

KEY FEATURES

Dual WAN ports VPN Support

Bringing load balancing and redundancy to your mission critical

internet connections.

Allowing the conﬁguration of secure connections to the remote of-

ﬁces or workers with ease and ﬂexibilty.

DMZ Port Flexible Quality of Service

Accessibility of business critical servers and websites is essential

and using a DMZ allows these servers to be available without being

inside your secure network.

Part of any solution in todays networks is QoS. The new Barricade

router gives high performance and ﬂexibility to your network.

SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS























 































 









DUAL WAN VPN

PORTS

• 2 WAN ports

• 1 DMZ port

• 1 LAN port

INTERFACES

• 4 10/100BASE-T

SECURITY FEATURES

• Stateful Packet Inspection (SPI)

• NAT

• Denial of Service (DoS)

• IP / Port / MAC Address / URL Filtering

• Email Alerts

• Multiple Management Accounts

ROUTER FEATURES

• Port Forwarding

• Special Applications

• DDNS

• Syslog Server

• Virtual Server

MANAGEMENT FEATURES

• System Logging

• Remote Management

• Software Upgrade

• NTP

• Account Reporting

• Statistics

VPN FEATURES

• VPN Supported (15-20; depending on the upload/download bandwidth)

• PPTP and IPSEC VPN Server

• Dynamic VPN

• IP Authentication Header (AH)

• IP Encapsulating Security Payload (ESP)

• Internet Key Exchange (IKE) authentication

and Key Management with Main and Aggressive modes

• Authentication (MD5 / SHA-1)

• NULL/DES/3DES Encryption Algorithm and their use with

IPSec Internet Security

LEDs

• Power

• Status

• WAN1

• WAN2

• LAN

• DMZ

DIMENSIONS

• 21.9 x 14.8 x 3.7 cm

• 8.6 x 5.8 x 1.45 In

WEIGHT

• 0.9kg

• 1.98lbs

OPERATING

• Temperature: 0~40o C / 32~104o F

• Humidity 10%~90% non-condensing

STORAGE

• Temperature: -20~70oC / -4~158o F

• Humidity: 0~95% non-condensing

POWER REQUIREMENTS

• 100-110 VAC, 5 Volt +/- 5% / 2.5 A

STANDARDS

• IEEE 802.3 10Base-T Ethernet

• IEEE 802.3u 100Base-TX Fast Ethernet

• IEEE 802.3x Flow Control

COMPLIANCES - EMC/SAFETY

• FCC

• CE

• UL

WARRENTY

• Please check www.smc.com for the warranty terms in your

country/region

CONTACT

North America

20 Mason

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local country contact information

of SMC Networks in the United States or other countries. Other trademarks

or registered trademarks are the property of their respective owners.

4/2009

www.smc.com

TECH SPECS - SMCBR21VPN
