EZ Connect™ g

SMC2870W

2.4GHz 54 Mbps Wireless Ethernet Bridge

Suitable for home and/or office, the EZ Connect™ g 2.4GHz 54Mbps Wireless

Ethernet Bridge (SMC2870W) instantly converts any Ethernet device, such

as a gaming console, printer, set-top box, point-of-sale terminal, desktop or

laptop computer into a wireless network device. In addition, this new product

can be configured to operate as an Access Point and has built-in Repeater

functionality via support for Wireless Distribution System (WDS). Thus

allowing you to connect your 802.11b and/or 802.11g clients to the wireless

network or extend the coverage of your WLAN in your home or office by

simply placing additional SMC2870Ws in the desired locations. The Repeater

capability of SMC2870W forwards wireless signal between a wireless client

and another SMC2870W that is connected to the wired network. It extends

the range of your existing wireless network while overcoming obstacles

that block wireless signals such as walls and doors. The new SMC2870W is

the ultimate convenient way to expand your wireless local area network. To

ensure secure transmissions across your wireless network, users can enable

64/128-bit Wired Equivalent Privacy (WEP), Wi-Fi Protected Access (WPA),

disable SSID broadcast, and MAC address filtering.

The SMC2870W is the Industry’s First Wireless-to-Ethernet Bridge to support

WPA. In addition, the EZ Connect™ g 2.4GHz 54Mbps Wireless Ethernet Bridge

offers an autofallback feature that provides scalable connectivity under

noisy environments and enables a larger wireless operating range. The new

SMC2870W 2.4GHz 54Mbps Wireless Ethernet Bridge is easy and simple to

install. It is Plug-and-Play™ and platform independent. The new product does

not require installing any drivers. Simply plug it into your Ethernet device

and your Ethernet device will become wireless! It is able to communicate

in Ad-Hoc mode (Peer-to-Peer) with another 802.11b wireless client or in

Infrastructure mode, which requires an Access Point for communication

to the wired network. This means you now have the freedom to place your

printer anywhere in the home or office or to play games with multiple players

over a wireless connection without the constraint of messy cabling.

Features and Beneﬁts

High Performance & Functionality

• EZ Installation Wizard

• Plug-and-Play, no drivers needed

• Converts any Ethernet-equipped device to wireless

• Extends the range of your wireless network

• Supports Repeating (via Wireless Distribution System WDS) and Access Point modes

• IEEE 802.11b, and 802.11g-Compliant

• High Data Rates at up to 54 Mbps

• Adhoc or Infrastructure mode

• 2.4GHz frequency band

• Uses Orthogonal Frequency Division Multiplexing (OFDM) technology

• Robust security features include 64-bit/128-bit WEP encryption, 802.1x authentication, Wi-Fi

Protected Access (WPA), disable SSID broadcast and MAC address ﬁltering

• Simple Creation or Extension of a Wireless Network

Compatibility

• IEEE 802.3, 802.3u

• IEEE 802.11b

• IEEE 802.11g

• Platform independent

• Windows 98SE/Me/2000/XP

Product Model No Description

SMC2870W 2.4GHz 54 Mbps Wireless Ethernet Bridge

EZ Connect™ g

Data Sheet

Specifications

Standards:

• 802.3, 802.3u

• 802.11b

• 802.11g

Modulation Type:

• BPSK, QPSK, DBPSK, DQPSK, CCK,

• 16QAM, 64QAM

Operating Channels:

• 11 channels (US, Canada)

• 13 channels (ETSI)

• 14 channels (Japan)

Radio Technology:

• Direct Sequence Spread Spectrum

• Orthogonal Frequency Division

Multiplexing

Security:

• 64-bit/128-bit Wired Equivalent Privacy

(WEP)

• Wi-Fi Protected Access (WPA)

• 802.1x authentication

• Disable SSID Broadcast

• MAC Address Filtering

Data Rates:

• 802.11b: 1/2/5.5/11 Mbps

• 802.11g: 6/9/12/18/24/36/48/54 Mbps

Output Power:

• 17±1dBm

Receive Sensitivity:

802.11b

• 1Mbps: -91dBm

• 2Mbps: -88dBm

• 5.5Mbps: -85dBm

• 11Mbps: -83dBm

802.11g

• 6Mbps: -88dBm

• 9Mbps: -87dBm

• 12Mbps: -84dBm

• 18Mbps: -82dBm

• 24Mbps: -79dBm

• 36Mbps: -75dBm

• 48Mbps: -69dBm

• 54Mbps: -68dBm

Interface:

• 10/100 Mbps RJ-45 port

Antennas:

• Two external dipole antennas

LEDs:

• Power

• Transmit / Receive (Wireless)

• Transmit / Receive (Wired)

AC Input:

• 100-240V 1A

DC Output:

• 5V 2A

Operating Temperature:

• -20C° to 40C° (-4C° to 104C°)

Storage Temperature:

• -25C° to 70C° (-13C° to 158C°)

Humidity:

• 5% to 95% (non-condensing)

Compliance:

• FCC part 15 subpart C (15.247)

and Class B

• ETSI 300-328/301-489-17 (General EMC

requirement for RF equipment)

• Industry Canada

• IDA for Singapore

• CE mark

Dimensions:

• 161mm x 30mm x 119mm

Weight:

• 195g (6.87oz)

EZ Connect™ g

SMC2870W

2.4GHz 54 Mbps Wireless

Ethernet Bridge
