Unmanaged Switch SMC-EZ108FDT / SMC-EZ1024FDT

EZ SwitchTM 8 and 24-Port 10/100Mbps Standalone Unmanaged Layer 2 Switches

www.smc.com

The EZ Switch ™ 10/100 provides 8/24 10/100 switching

ports and a slot for an optional fiber uplink. A range of

100Mbps connectors is available, including SC, MTRJ, and

VF-45. It is most ideal for workgroups looking for distance

connection up to 20Km, suitable for environment such as

schools, university campus, and between buildings.

For SMC-EZ108FDT, it also includes a sliding switch in the

rear for VLAN configurations. When turned on, all ports will

automatically be segregated into an individual VLAN. The

uplink will be belong to every VLAN. This is the perfect

solution for workgroups that requires security but at the

same time, still have access to distance servers or back-

bone connection.

FEATURES

Distance connection up to 20Km away with optional

uplink connection

A range of fiber modules to choose from with

SC/ST/VF-45/MT-RJ connectors

High port count for expanding network—max. of 9/17/25 ports

Auto-MDIX ports—no crossover cables required

Rackmountable

No crossover cable required, simply plug and play

Simple VLAN application on the EZ108FDT for easy management

BENEFITS

OVERVIEW

TECHNICAL SPECIFICATIONS SMC-EZ108FDT / SMC-EZ1024FDT

PORTS

• SMC-EZ108FDT:

8 10BASE-T/100BASE-TX RJ-45 ports,

and 1 slot for expansion module with

VLANs

• SMC-EZ1024FDT:

24 Auto-MDIX 10BASE-T/100BASE-TX

RJ-45 ports, 1 slot for expansion module

NETWORK INTERFACE

• 10BASE-T: RJ-45 UTP CAT. 3,4,5

• 100BASE-TX: RJ-45 UTP Cat. 5

• 100BASE-FX: SC/ST connector

• Multimode fiber cable; 62.5/125

or 50/125 microns

• Singlemode fiber cable: 9/125 micron

LEDs

• Power – one

• Speed – one per port

• Link/Activity – one per port

AC INPUT

• 100 to 240V, 50 to 60 Hz

POWER SUPPLY

• Internal, auto-ranging transformer:

100 to 240VAC, 50 to 60 Hz

QUEUE BUFFER

• SMC-EZ108FDT: 1Mb

• SMC-EZ1024FDT: 768K

ADDRESS TABLE

• SMC-EZ108FDT: 2K MAC

address entries

• SMC-EZ1024FDT: 8K

MAC address entries

TEMPERATURE

• Operating: 0 °C to 65 °C

(32 °F to 122 °F)

• Relative humidity: 15 to 95%

@ 40 °C (104 °F), noncondensing

• Storage: : -40 °C to 70 °C

(-40 °F to 158 °F)

• Relative humidity: 90% @ 65 °C

(149 °F), noncondensing

WARRANTY

• Limited Lifetime

DIMENSIONS

• SMC-EZ108FDT

9.81 x 4.55 x 1.44 in / 24.9 x 11.6 x 3.7 cm

• SMC-EZ1024FDT

17.3 x 6.9 x 1.8 in / 44 x 17.5 x 5.6 cm

WEIGHT

• SMC-EZ108FDT 1.89 lbs / .86 kg

• SMC-EZ1024FDT 5.3 lbs / 2.4 kg

HUMIDITY

• Operating: 5% to 95%

POWER CONSUMPTION

• EZ108FDT -13W

• EZ1024FDT – 40W

HEAT DISSIPATION

• EZ108FDT - 137 BTU/hr

• EZ1024FDT - 137 BTU/hr

MAXIMUM CURRENT

• 0.5ARMS max. @110V,

0.20ARMS max. @240V

STANDARDS

• IEEE802.3u Fast Ethernet

COMPLIANCES

• CE Mark

EMISSIONS

EZ108FDT

• FCC Class B

• Industry Canada Class B

• EN55022 (CISPR 22) Class B

• IEC 1000- 4- 2/3/4/6

EZ1024FDT

• FCC Class A

• Industry Canada Class A

• EN55022 (CISPR 22) Class A

• IEC 1000- 4- 2/3/4/6

SAFETY

• CSA/NRTL (CSA22.2.2.950

&UL 1950) En60950 (TUV/GS)

SLIDE-IN MODULES

• 100Base-FX Extender Module

MODEL

• SMC-EZ108FMSC

• SMC-EZ108FMMT

• SMCEZ108FMST

PORTS

• 1- 100Base-FX

NETWORK INTERFACE

• SC/MTRJ/ST connector, 50/125 or

62.5/125 micron multimode fiber cable

LENGTH

• Up to 2Km (1.24 miles)

MODEL

• SMC-EZ108FSMT

• SMC-EZ108FSSC

NETWORK INTERFACE

• MTRJ/SC connector, 9/125 micron

single mode fiber cable

LENGTH

• Up to 20km / 12.43 miles

STANDARDS

• 802.3u Fast Ethernet

North America

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information
