TigerSwitch™ 1000

SMC8608SX

8 Port Gigabit Switch

Features Benefits

SMC’s newTigerSwitch™ 1000 is a Gigabit Ethernet backbone switch that provides 8

full-duplex 1000BASE-SX ports.With 16 Gbps of bandwidth, this switch dramatically

improves the performance of congested networks.A host of advanced features and

comprehensive management capabilities make this device a potent solution for the

network core.

The TigerSwitch™ 1000 provides high bandwidth, high-performance connectivity

within and between workgroups,and increased capacity for server farms,giving users

faster access to network-wide resources.Moreover,the 1000BASE-SX fiber optic ports

support connections up to 550 meters (1800 feet) in length.

The TigerSwitch™ 1000 comes fully-loaded with advanced performance-enhancing

features. IGMP maintains available bandwidth by limiting multicast transmissions to

subscribers only. Broadcast Storm Suppression prevents broadcast traffic storms from

engulfing the network. QoS priority queueing ensures the minimum delay for real-

time multimedia data across the network.Flow Control eliminates the loss of packets

due to bottlenecks caused by port saturation.Port-based and tagged VLANs are also

included to provide traffic security and efficient use of network bandwidth.

Outstanding Performance

• 8 full-duplex 1000BASE-SX ports

• 16 Gbps of aggregate bandwidth

• QoS support with two levels of priority and Weighted Fair Queueing

• IGMP filtering and snooping provides complete control of multicastpacets

• Broadcast storm suppression prevents broadcast traffic storms from engulfing the network

• Address table of up to 12K MAC addresses

• Full-duplex flow control eliminates lost packets due to port saturation

Flexible

• Up to 16 IEEE 802.1QVLANs provides maximum security and bandwidth efficiency

• Port mirroring allows detailed analysis of traffic crossing any port in real time

• Rack-mountable (standard 19”rack)

• Supports a redundant power supply for fail-safe operation

Manageable

• In-band viaTelnet,or any SNMP-based management application

• Out-of-band via RS-232 console port

•Web management agent for switch configuration access anytime,anywhere

• 4-group RMON (groups 1,2,3,9)

• SpanningTree Protocol allows the creation of redundant data paths

Compatible

• IEEE 802.3z,802.3x,802.1d,802.1Q,and 802.1p

Reliability

•Three-year warranty

•Toll-free technical support

• SMC Customer Satisfaction Guarantee

10010101010011101010001101001010100100101

00101010101100010101110010110101011011010

10110101010011101010001101001010100100101

01101010101100010101110010110101011011010

10011101010011101010001101001010100100101

6 Hughes

Irvine, CA 92618

949.707.2400

949.707.2460 fax

1-800-SMC-4-YOU

www.smc.com

Specifications

TigerSwitch™ 1000

SMC is a registered trademark of SMC Networks, Inc. All other brand and product names are trademarks of their respective holders.

Network Interface

SC connector (multimode fiber cable;

62.5/125 or 50/125 microns)

Buffer Architecture

2 Mbytes per port

Forwarding Mode

Store-and-forward

AddressTable

12K MAC address entries

In-Band Management

Telnet,SNMP and Web-based

Out-of-Band Management

RS-232 console port

VLAN Support

Up to 16 groups;802.1Q tagging and port based

Multicast Filtering

IGMP with snooping for automatic registration

Broadcast Storm Suppression

Discards broadcasts at a critical threshold

Traffic Priority

2 priority queues with Weighted Fair Queuing

Size

17.37 x 11.22 x 2.53 in (44.0 x 28.5 x 6.4 cm)

Weight

10.14 lbs (4.6 kg)

Temperature

Operating:32 to 122°F (0 to 50°C)

Storage:-40 to 158°F (-40 to 70°C)

Humidity

5% to 95% (non-condensing)

Power Supply

Universal AC input;100 to 240VAC,50 to 60 Hz

Power Consumption

70Watts maximum

Heat Dissipation

239 BTU/hr maximum

Maximum Current

0.5A @ 110VAC

0.7A @ 240VAC

Standards

IEEE 802.3z Gigabit Ethernet

IEEE 802.3x Full-Duplex Flow Control

IEEE 802.1d SpanningTree

IEEE 802.1QVLAN Tagging

IEEE 802.1p PriorityTagging

SNMP (RFC 1157)

RMON (RFC 1757 groups 1,2,3 and 9)

IGMP (RFC 1112)

MIB II (RFC 1213)

Ethernet-Like MIB (RFC 1643)

Bridge MIB (RFC 1493)

EMC/Safety Compliances

CE Mark

Emissions

FCC Class B

Industry Canada Class B

EN55022 (CISPR 22) Class B

VCCI Class B

C-Tick - AS/NZS 3548 (1995) Class B

Immunity

IEC 1000-4-2/3/4/6

Safety

CSA/NRTL (CSA 22.2.950 & UL 1950)

TUV/GS EN60950

Warranty

Three years

Product OrderNumber Description

TigerSwitch™ 1000 SMC8608SX 8-port Gigabit Ethernet switch

SC-ST Converter 99-012034-091 SC to ST-type port converter for 62.5/125 micron fiber cable

RPU SMCRPU150W Redundant power supply unit
