Smeg UK282PXNF Manuale utente
Freezer / User ManualEN
UK282PXNF
EN - 2
Thank you for choosing this product.
This user manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this user manual before using your appliance and keep this
book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of re / ammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly
EN - 3
CONTENTS
1 SAFETY INSTRUCTIONS ................................................................................. 4
1.1 General Safety Warnings ...............................................................................................4
1.2 Installation warnings.......................................................................................................7
1.3 Electrical information (For UK type plug)........................................................................7
1.4 During Usage..................................................................................................................8
2 DESCRIPTION OF THE APPLIANCE ............................................................... 9
3 USING THE APPLIANCE ................................................................................ 10
3.1 Information on No-Frost technology .............................................................................10
3.2 Display and Control Panel............................................................................................11
3.3 Operating your Freezer ................................................................................................11
3.3.1 Freezer Temperature Set Button ...............................................................................11
3.3.2 Super Freezer Mode..................................................................................................11
3.3.3 Freezer Temperature Settings ...................................................................................11
3.3.4 Door Open Alarm Function........................................................................................11
3.4 Temperature Adjustment Warnings...............................................................................12
3.5 Accessories ..................................................................................................................12
3.5.1 Ice Tray (In some models) .......................................................................................12
3.5.2 The Icematic (In some models) ...............................................................................12
4 FOOD STORAGE ............................................................................................ 13
5 CLEANING AND MAINTENANCE .................................................................. 16
5.1 Defrosting .....................................................................................................................16
6 SHIPMENT AND REPOSITIONING................................................................. 17
6.1 Transportation and Changing Positioning.....................................................................17
6.2 Repositioning the Door.................................................................................................17
7 BEFORE CALLING AFTER-SALES SERVICE............................................... 18
8 TIPS FOR SAVING ENERGY .......................................................................... 19
EN - 4
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the following instructions:
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
EN - 5
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
–staff kitchen areas in shops, ofces and other
working environments.
–farm houses and by clients in hotels, motels and
other residential type environments.
–bed and breakfast type environments;
–catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected
to the power cable of your refrigerator. This plug
should be used with a specially grounded socket
of 16 amperes. If there is no such socket in your
house, please have one installed by an authorised
electrician.
EN - 6
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.
EN - 7
1.2 Installation warnings
Before using your freezer for the rst time,
please pay attention to the following points:
• The operating voltage for your freezer
is 220-240 V at 50Hz.
• The plug must be accessible after
installation.
• Your freezer may have an odour when
it is operated for the rst time. This is
normal and the odour will fade when
your freezer starts to cool.
• Before connecting your freezer,
ensure that the information on the
data plate (voltage and connected
load) matches that of the mains
electricity supply. If in doubt, consult a
qualied electrician.
• Insert the plug into a socket with an
efcient ground connection. If the
socket has no ground contact or the
plug does not match, we recommend
you consult a qualied electrician for
assistance.
• The appliance must be connected
with a properly installed fused socket.
The power supply (AC) and voltage at
the operating point must match with
the details on the name plate of the
appliance (the name plate is located
on the inside left of the appliance).
• We do not accept responsibility for
any damages that occur due to
ungrounded usage.
• Place your freezer where it will not be
exposed to direct sunlight.
• Your freezer must never be used
outdoors or exposed to rain.
• Your appliance must be at least 50
cm away from stoves, gas ovens and
heater cores, and at least 5 cm away
from electrical ovens.
• If your freezer is placed next to a deep
freezer, there must be at least 2 cm
between them to prevent humidity
forming on the outer surface.
• Do not cover the body or top of
freezer with lace. This will affect the
performance of your freezer.
• Clearance of at least 150 mm is
required at the top of your appliance.
Do not place anything on top of your
appliance.
• Do not place heavy items on the
appliance.
• Clean the appliance thoroughly before
use (see Cleaning and Maintenance).
• Before using your freezer, wipe
all parts with a solution of warm
water and a teaspoon of sodium
bicarbonate. Then, rinse with clean
water and dry. Return all parts to the
freezer after cleaning.
• Use the adjustable front legs to make
sure your appliance is level and
stable. You can adjust the legs by
turning them in either direction. This
must be done before placing food in
the appliance.
• Install the two plastic distance guides
(the parts on the black
vanes -condenser- at
the rear) by turning it
90° (as shown in the
gure) to prevent the
condenser from
touching the wall.
• The distance between the appliance
and back wall must be a maximum of
75 mm.
1.3 Electrical information (For UK type
plug)
Warning! This appliance must be
earthed.
The mains lead of this appliance has been
tted with a specially earthed plug.
Important: Do not use the
appliance without the fuse cover in position.
Should the fuse need to be replaced, it
must be replaced with a 13A fuse, ASTA
approved to BS1362.
EN - 8
The plug must be used with a specially
earthed socket of 13 amperes. If there is
no such socket in your house, please have
one installed by an authorised electrician.
The mains lead of this appliance has been
tted with a BS 1363A 13A fused plug. To
change a fuse in this type of plug, follow
the steps below:
1 Remove the fuse cover and fuse.
2 Fit replacement 13A fuse, ASTA approved
to BS 1362 type, into the fuse cover.
3 Replace fuse cover.
1.4 During Usage
• Do not connect your freezer to the
mains electricity supply using an
extension lead.
• Do not use damaged, torn or old
plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by
adults. Do not allow children to play
with the appliance or hang off the
door.
• Never touch the power cord/plug with
wet hands. This may cause a short
circuit or electric shock.
• Do not place glass bottles or cans in
your freezer as they will burst when
the contents freeze.
• Do not place explosive or ammable
material in your freezer.
• When removing ice from the ice-
making compartment, do not touch it.
Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet
hands. Do not eat ice-cream or
ice cubes immediately after they
are removed from the ice-making
compartment.
• Do not re-freeze thawed frozen food.
This may cause health issues such as
food poisoning.
When the door of the freezer is closed, a
vacuum seal will form. Wait for 1 minute
before reopening it.
This application is optional for easy opening
of the door. With this application, a little
condensation may occur around this area
and you may remove it.
Old and Out-of-order Fridges
• If your old fridge or freezer has a
lock, break or remove the lock before
discarding it, because children may
get trapped inside it and may cause
an accident.
• Old fridges and freezers contain
isolation material and refrigerant with
CFC. Therefore, take care not to harm
environment when you are discarding
your old fridges.
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements
listed in the standards referenced.
Disposal of your old appliance
The symbol on the product or on
its packaging indicates that this
product may not be treated as
household waste. Instead it shall
be handed over to the applicable
collection point for the recycling of electrical
and electronic equipment. By ensuring
this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and
EN - 9
human health, which could otherwise be
caused by inappropriate waste handling
of this product. For more detailed
information about recycling of this product,
please contact your local city ofce, your
household waste disposal service or the
shop where you purchased the product.
Packaging and the Environment
Packaging materials protect
your machine from damage that
may occur during transportation.
The packaging materials are
environmentally friendly as they are
recyclable. The use of recycled material
reduces raw material consumption and
therefore decreases waste production.
Notes:
• Please read the instruction manual
carefully before installing and
using your appliance. We are not
responsible for the damage occurred
due to misuse.
• Follow all instructions on your
appliance and instruction manual, and
keep this manual in a safe place to
resolve the problems that may occur
in the future.
• This appliance is produced to be used
in homes and it can only be used in
domestic environments and for the
specied purposes. It is not suitable
for commercial or common use. Such
use will cause the guarantee of the
appliance to be cancelled and our
company will not be responsible for
the losses to be occurred.
• This appliance is produced to be
used in houses and it is only suitable
for cooling / storing foods. It is not
suitable for commercial or common
use and/or for storing substances
except for food. Our company is
not responsible for the losses to be
occurred in the contrary case.
2 DESCRIPTION OF THE
APPLIANCE
1
2
3
4
5
6
This presentation is only for
information about the parts of the
appliance. Parts may vary according to the
appliance model.
1. Control panel
2. Freezer aps
3. Freezer drawers
4. Freezer bottom drawer
5. Freezer big drawer
6. Ice tray (In some models)
In some models there is a shelf with
icematic in the top basket
EN - 10
3 USING THE APPLIANCE
3.1 Information on No-Frost technology
No-frost freezers differ from other static
freezers in their
operating principle.
In normal freezers,
the humidity entering
the freezer due to
opening the door
and the humidity
inherent in the food
causes freezing in the
freezer compartment.
To defrost the frost
and ice in the freezer
compartment, you are
periodically required
to turn off the freezer,
place the food that
needs to be kept
frozen in a separately
cooled container
and remove the ice
gathered in the freezer
compartment.
The situation is completely different in no-
frost freezers. Dry and cold air is blown into
the freezer compartment homogeneously
and evenly from several points via a blower
fan. Cold air dispersed homogeneously
and evenly between the shelves cools all
of your food equally and uniformly, thus
preventing humidity and freezing.
Therefore your no-frost freezer allows you
ease of use, in addition to its huge capacity
and stylish appearance.
Indice
Altri manuali Smeg Congelatore
Smeg
Smeg VI205PNF Manuale utente
Smeg
Smeg CV 270 A Manuale utente
Smeg
Smeg C3170F2P1 Manuale utente
Smeg
Smeg FD70FN1HM Manuale utente
Smeg
Smeg VI205PNF1 Manuale utente
Smeg
Smeg VR145NE Manuale utente
Smeg
Smeg CV235BNF Manuale utente
Smeg
Smeg Built In Freezer VR115B Manuale utente
Smeg
Smeg CV26PXNF3 Manuale utente
Smeg
Smeg UKC7280FP1 Manuale utente
Smeg
Smeg UD7108FSEP Manuale utente
Smeg
Smeg CV210A Manuale utente
Smeg
Smeg FF18EN2HX Manuale utente
Smeg
Smeg UKC7172NP Manuale utente
Smeg
Smeg VR105AP1 Manuale utente
Smeg
Smeg UKS8F174NF Manuale utente
Smeg
Smeg CH300E Manuale utente
Smeg
Smeg VR145NE Guida utente
Smeg
Smeg Chest-type Manuale utente
Smeg
Smeg VR120B Guida rapida
