Snapper 7800849 Manuale utente

Not for

Reproduction

Parts Manual fo

22" STEEL DECK WALK BEHIND

SERIES 20

COMMERCIAL MOWER

Revision: - 9/30/2013

Briggs & Stratton Yard Power Products Group

Manual No. 7106167

535 Macon Road

McDonough, GA, 30253 U.S.A.

800-935-2967

Descri

tionModel No.

7800849 CP215520HV

Not for

Reproduction

Not for

Reproduction

Table Of Content

TP 400-5566---CW-N

22" STEEL DECK WALK BEHIND

SERIES 20 3

Manual No. 7106167

PAGE GROUP

4Handle Group

8Wheels, Brackets & Latches

10 Deck, Engine & Blade Group

12 Drive System, Self Propelled

16 Transmission - Differential Group

18 Grass Bag & Adapter Group

20 Decal Group

Not for

Reproduction

Manual No. 7106167 22" STEEL DECK WALK BEHIND

SERIES 20

Handle Group

Not for

Reproduction

Footnotes:

Manual No. 710616722" STEEL DECK WALK BEHIND

SERIES 20 5

Handle Group

Part No Descri

tionItem Qty

1 7074411AYP 1 HANDLE, Upper

2 7023810YP 1 FOAM GRIP, 18.75

3 7074418AYP 1 BAIL, OPC Control (16.6” Wide)

4 7034872YP 1 CLIP, Zone Control

5 7074156AYP 1 HANDLE, Middle

6 7033985AYP 1 HANDLE, Lower, ADJ, LH

7 7033986AYP 1 HANDLE, Lower, ADJ, RH

8 7074140YP 1 PANEL, Control, No Electric Switch

9 703961 4 SCREW, 1/4-20 X .550, Self-Tapping, Zinc/Clear (Was 7900067 or 80005286)

10 7074473AYP 1 HANDLE, Clutch

11 7028407YP 1 GRIP, International Symbol, 4.6” Black

12 704031 1 PIN, 1/4 X 1.5”, Clevis, ZC/CL (Was 7011886, 7023792 or 80005708)

13 7014343YP 2 BUSHING, Flanged, .27 ID, Nylon, Black

14 704005 1 NUT, 1/4”, Push, Zinc/Clear (Was 7091020 or 80005599)

15 703234 1 SCREW, 1/4-20 X 1.5, Hex Head Cap, GR5, ZC/CL (Was 7090909, 7079577 or 80002713)

16 7102235YP 1 CABLE, Zone Control (60.3 Long)

17 703462 3 WASHER, 1/4 Internal Tooth Lock, YZ (Was 7090053 or 80004414)

18 703127 3 NUT, 1/4-20, G5 Zinc/Clear (Was 7090063, 7091576 or 80003586)

19 7023813SM 3 CLIP, Wiring Harness

20 7078026YP 1 CONTROL, Throttle, Honda, 50.81” L

21 7075308YP 1 KNOB, Throttle, Red

22 703163 2 SCREW, 1/4-20 X 2.0, Hex Head Cap, GR5, Zinc/Clear (Was 1921963, 90505 or 80003674)

23 7028488MA 1 GUIDE, 1/4-20, Rope, CL/ZC

24 15X145MA 1 NUT, 1/4-20, Nylock, GR A, Zinc/Clear (Was 703232, 7076978 or 80002730)

25 7034604YP 1 CABLE, Clutch Control, 41.25” L

26 7012121YP 1 COVER, Vinyl

27 7012122YP 1 SPRING, Clutch

28 7026219YP 1 CLAMP, 7/8” Double Cable

29 704063 6 BOLT, 5/16-18 X 1.50, Carriage Head, Short Neck, ZC/CL (Was 7091190 or 80005975)

31 7090391SM 6 WASHER, 5/16, Internal Lock, Zinc/Clear (Was 703587 or 80003683)

32 703465 6 NUT, 5/16-18, Hex, GR5, Zinc/Clear (Was 7091069, 7091511 or 80002725)

33 7074003YP 1 BRACKET, Shift

34 703589 1 SCREW, 3/8-16 x 2, Hex Head Cap, GR5, Zinc/Clear (Was 1923701, 7091305 or 80003522)

35 703964 2 WASHER, 7/16” ID, 1” OD, .060 Thk, Flat, ZC/CL (Was 7031961 or 80005597)

36 704004 2 WASHER, .406 ID X 1.0 OD X .063 Thk, Flat Nylon (Was 7028465 or 80005596)

37 7074113BMYP 1 LEVER, Shift

38 7075182YP 1 KNOB, Shift, Red

39 703351 1 SCREW, #8-32 X 0.50, Machine Fillister Head, Zinc/Clear (Was 7091167 or 80004404)

40 703460 1 NUT, #8-32, Hex, Zinc/Clear (Was 7091018 or 80004411)

41 704006 1 WASHER, 3/8” ID x 3/4” OD, Belleville, Zinc/Clear (Was 7028568 or 80005600)

42 703347 1 NUT, 3/8-16, Hex Center-Lock, GR B, Zinc/Clear (Was 7091585 or 80004408)

43 7074133YP 1 ROD, Speed Control (1/4-28 thread)

44 703350 1 WASHER, 5/16, Flat SAE, Zinc/Clear (Was 80004405)

45 704030 1 PIN, 5/16 X 1.044, Self-Locking Cotter, Zinc/Clear (Was 7034162 or 80005707)

Not for

Reproduction

Manual No. 7106167 22" STEEL DECK WALK BEHIND

SERIES 20

Handle Group

Not for

Reproduction

Footnotes:

Manual No. 710616722" STEEL DECK WALK BEHIND

SERIES 20 7

Handle Group

Part No Descri

tionItem Qty

46 703798 2 BOLT, 5/16-18 X .50, Carriage, Zinc/Clear (Was 7090731, 725993, 908156MA or 80004563)

47 690272MA 3 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)

48 7046707BMYP 2 BRACE, Handle

49 703301 1 SCREW, 5/16-24 x 1 Hex Head Cap, GR 5, BZ (Was MT910828MA or 80003532)

50 9357MA 3 SCREW, 5/16-18 X .750, Flanged Whiz-Lock, GR5 (Was 1930591, 1960738, 7090595 or

80003531)

51 703118 2 WASHER, 7/8, Flat, GR5, Zinc/Clear (Was 7091130, 7900022 or 80003517)

52 703947 1 NUT, 5/16-18 X .625, Weld, ZC/CL (Was 7090733, 7090895 or 80005534)

53 7012114SM 1 BUSHING, Differential

54 7034179BMYP 1 LINK, Differential, Commercial

55 703896 1 NUT, 5/16-24, Hex Center Lock, GR B, Zinc/Clear (Was 7091606, 7090174, 7090222 or

80004848)

56 7073913YP 1 BELL CRANK, Black Zinc

57 7015753YP 2 BALL JOINT, 1/4-28

58 703461 3 NUT, 1/4-28 Hex, GR5, Zinc/Clear (Was 7090095 or 80004412)

59 703408 1 SCREW, 5/16-18 x 7/8 Hex Head Cap, GR 5, Zinc/Clear (Was 80004421)

60 7073822BMYP 1 BRACKET, Bell Crank

61 690272MA 5 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)

62 703970 1 SPACER, .623 OD x .328 ID x .151 L (Was 7013849 or 80005375)

63 703167 1 SCREW, 5/16-18 x 1-1/4 Hex Washer Head Self-Tap (Was 1931202, 7091151, 7091524 or

80003681)

Not for

Reproduction

Manual No. 7106167 22" STEEL DECK WALK BEHIND

SERIES 20

Wheels, Brackets & Latches

Not for

Reproduction

Footnotes:

Manual No. 710616722" STEEL DECK WALK BEHIND

SERIES 20 9

Wheels, Brackets & Latches

Part No Descri

tionItem Qty

0010 703964 6 WASHER, 7/16” ID, 1” OD, .060 Thk, Flat, ZC/CL (Was 7031961 or 80005597)

0020 7600180YP 1 KIT, Front Wheel Arm Assembly, RH (Was 7051886)

0020-20 7012325YP 2 LATCH, Height

0020-30 703839 2 BOLT, 5/16-18 X .750, Hex Washer Head Shoulder, Zinc/Clear (Was 7015761 or 80004422)

0020-50 7031017YP 1 WHEEL ARM, Front, Round Hole, RH, Clear

0030 7054246YP 1 ASSEMBLY, Wheel Arm, Long, RR (Was 7054230YP)

0030-10 703840 2 BOLT, 5/16-18 X 1.0, Hex Washer Head .435 Dia. Shoulder, ZC/CL (Was 7011078 or

80004423)

0030-20 703297 4 RETAINER, 5/16 X .625, Push Nut, GR 5, Zinc/Clear (Was 1921982, 3031796 or 80003523)

0030-30 7012312YP 2 BEARING, 9/16” ID

0030-50 7032722YP 1 ARM, Wheel, Right Rear, Zinc/Clear

0030-60 7035717YP 2 LATCH, Height Adjusting, (long)

0030-70 703967 6 SCREW, #10-32 x 3/8, Torx Hex Washer Head Self-Tap, ZC/CL (Was 7091012 or 80005604)

0030-90 7103793YP 4 GRIP, Height Latch, Black (Was 7100633)

0040 7054247YP 1 ASSEMBLY, Wheel Arm, Left Rear, Long (Was 7054231YP)

0040-50 7032723YP 1 ARM, Wheel, Left Rear, Zinc/Clear

0050 703348 4 NUT, 7/16-20, Hex Jam Center Lock, GR B, Zinc/Clear (Was 7090377 or 80004407)

0060 690272MA 4 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)

0070 7021119YP 1 AXLE, V21

0080 7031960YP 2 HUBCAP, Rear

0090 7031121YP 4 HUBCAP, Front

0100 7600179YP 1 ASSEMBLY, Front Wheel Arm, LH (Was 7051885)

0100-50 7031016YP 1 WHEEL ARM, L.H. Front (Square Hole)

0110 7035727YP 2 WHEEL, 8 x 1.75 - Steel - D - Gray

---- 7011125YP 4 BEARING, 7/16” ID, Ball, Front Wheel (Not Shown)

0120 7035726YP 2 WHEEL, 10 x 1.75, Steel-D, (Self Propelled) - Gray

Not for

Reproduction

Manual No. 7106167 22" STEEL DECK WALK BEHIND

SERIES 20

Deck, Engine & Blade Group
