Socket CompactFlash Scan Card Series 5 Manuale utente
CompactFlash Scan CardP
™
P
Series 5
User’s Guide
2
7/2012 Document # 6410-00166 Y
Copyright Notice
Copyright © 2001-2012 Socket Mobile, Inc. All rights reserved.
Socket, the Socket logo, Mobility Friendly, CompactFlash Scan Card, SocketScan, SoMo, SocketCare and
Business Mobility Now! are registered trademarks or trademarks of Socket Mobile, Inc. All other brand and
product names are trademarks of their respective holders.
Reproduction of the contents of this manual without the permission of Socket Mobile is expressly prohibited.
Please be aware that the products described in this manual may change without notice.
The CompactFlash Scan Card includes technology licensed under United States Patent No. 5,902,991 and
7,003,627
Feel free to contact Socket Mobile at:
Socket Mobile, Inc.
39700 Eureka Drive
Newark, CA 94560-4808
USA
+1 510-933-3067
Other than the above, Socket Mobile can assume no responsibility for anything resulting from the application of
information contained in this manual.
Please refrain from any applications of the CompactFlash Scan Card that are not described in this manual.
Please refrain from disassembling the CompactFlash Scan Card. Disassembly of this device will void the
product warranty.
You can track new product releases, software updates and technical bulletins by visiting the Socket website at:
HTUhttp://www.socketmobile.com
3
Table of Contents
COPYRIGHT NOTICE 2
1 | INTRODUCTION 4
ABOUT THE SOFTWARE 4
SYSTEM COMPATIBILITY 4
PACKAGE CONTENTS 5
ACCESSORIES 5
SOCKETCARE™SERVICE PROGRAM 5
PRODUCT REGISTRATION 5
2 | SETUP FOR THE SOMO 6
STEP 1: ASSIGN A TRIGGER BUTTON 7
STEP 2: START SOCKETSCAN 10
STEP 3: INSERT THE CARD 11
STEP 4: OPEN YOUR APPLICATION 11
STEP 5: SCAN DATA INTO YOUR APPLICATION 11
3 | SOCKETSCAN 13
SYMBOLOGY SELECTOR 14
SCANNER SETTINGS 15
SCAN DEMO 16
SOCKETSCAN TRIGGER 17
APPENDIX A PRODUCT SPECIFICATIONS 19
APPENDIX B BARCODE LABEL SPECIFICATIONS 26
APPENDIX C USAGE AND MAINTENANCE TIPS 27
SCANNING TIPS 27
CLEANING THE CF SCAN CARD 5XRX28
APPENDIX D SETUP FOR NON-SOMO PDAS 29
STEP 1: UNINSTALL OTHER SCANNING SOFTWARE 29
STEP 2: INSTALL SOCKETSCAN SOFTWARE 29
STEP 3: ASSIGN A TRIGGER BUTTON 30
STEP 4: START SOCKETSCAN 30
STEP 5: INSERT THE CF SCAN CARD 30
STEP 6: OPEN YOUR APPLICATION 31
STEP 7: SCAN DATA INTO YOUR APPLICATION 31
APPENDIX E RETAINING BRACKET INSTALLATION 32
APPENDIX F TROUBLESHOOTING 35
APPENDIX G TECHNICAL SUPPORT 36
LIMITED WARRANTY 37
REGULATORY COMPLIANCE 39
4
1 | INTRODUCTION
Thank you for purchasing the
CompactFlash Scan Card (CF Scan
Card) Series 5 or Series 5 Rx. This
barcode scanner plugs into the Socket
SoMo®650/655 handheld computer
and provides high-quality laser or
CMOS imaging barcode scanning
technology.
The CF Scan Card comes in five versions:
Version
Performance Level
Scanner Type
Types of Barcodes
Read
5C
Entry-Level
CMOS Imager
1D
5E2
Entry-Level
Class 1 Laser
1D
5P
Performance
Class 2 Laser
1D
5X
Xtreme Performance
CMOS Imager
1D and 2D
5XRx
Xtreme Performance, Antimicrobial
CMOS Imager
1D and 2D
ABOUT THE SOFTWARE
SocketScan™ keyboard wedge software enters scanned data into any
Windows application, as if the data were manually typed. No custom
programming is required to use the CF Scan Card.
SocketScan Trigger places a floating software trigger on your screen that you
can move to anywhere on your screen and tap/click to trigger the scanner.
Download software updates free: http://www.socketmobile.com/support/downloads
SYSTEM COMPATIBILITY
The CF Scan Card works with computers that meet these requirements:
Any of the following operating systems:
-Windows Embedded Handheld 6.5
-Windows Mobile 6 Classic/Professional
-Windows Mobile 2003, 2003SE or 5.0 for Pocket PC
-Windows Vista, XP
Available CompactFlash (CF) or PC Card slot
(Use in a PC Card slot requires a Type II CF-to-PC Card adapter, available from third
party)
CHAPTER 1: INTRODUCTION 5
Software installation for Windows Mobile requires a host PC with Microsoft
synchronization software (free from the Microsoft website). Alternatively, advanced
users can use a CAB file to install the application. Please refer to the Readme file on
the installation CD for instructions.
PACKAGE CONTENTS
CF Scan Card
Retaining bracket for use with the Socket SoMo
SocketScan Installation CD
Booklets with copyright, warranty, and regulatory compliance
ACCESSORIES
http://www.socketmobile.com/products/plug-in-data-capture/#Accessories
Description
SKU
FlexGuard silicone cover
–protects both scanner
and device
For SoMo 650 –HC1670-1202
For SoMo 650Rx –HC1661-1188
SOCKETCARE™SERVICE PROGRAM
Lower your Total Cost of Ownership with the SocketCare service program, which provides
faster repair and replacement, quicker technical support, and the option for full
comprehensive coverage (SKU# IS5046-1379).
http://www.socketmobile.com/support/socketcare
PRODUCT REGISTRATION
Socket highly recommends that all customers register their products. Registered users
receive access to technical support and can choose to get product updates and special
offers. Register online at: http://support.socketmobile.com
6
2|SETUP FOR THE SOMO
This chapter shows how to install,
configure, and use the
CompactFlash Scan Card (CF Scan
Card) with any version of the Socket
SoMo handheld computer.
SETUP SUMMARY
STEP 1: Assign a trigger button.
STEP 2: Start SocketScan
STEP 3: Insert the CF Scan Card.
STEP 4: Open your application.
STEP 5: Scan data into your application!
Note: SocketScan software comes pre-loaded on the SoMo,
thus installation is not required. However, if you wish to
install a more recent version of SocketScan, you can download it free from:
http://www.socketmobile.com/support/downloads/data-collection/series5/
CHAPTER 2: SETUP FOR THE SOMO7
STEP 1: ASSIGN A TRIGGER BUTTON
Note: Alternatively, you can use the SocketScan Trigger software to set up a soft trigger
on the SoMo screen. See Chapter 4.
Note: If SocketScan is not running yet, you can press the trigger button to quickly launch
SocketScan. Pressing the trigger button will activate the scanner only when SocketScan
is open.
Windows Mobile 6 Service Pack 4 or later
1. In the Today screen, tap Getting Started.
2. In the list, tap Set up Data Capture Triggers.
8
3. In the next screen, tap LEFT or RIGHT in the ”Barcode to…” line to assign the button
on the left or right side of the SoMo as the barcode scanner trigger.
Note: The “RFID to…” options do not apply to the CompactFlash Scan Card..
4. The SoMo will configure the trigger button and send a confirmation message to your
inbox.
CHAPTER 2: SETUP FOR THE SOMO9
Windows Mobile 5 or 6 (prior to Windows Mobile 6 Service Pack 4)
1. Tap Start | Settings | Buttons.
2. Select a button to trigger the CF Scan Card. In the drop-down menu, select
SocketScan. When done, tap ok.
IMPORTANT! Be sure to select SocketScan. Do not select the programs Socket Read RFID,
Socket Read Barcode or Socket Trigger Select, which are not for the CF Scan Card.
10
STEP 2: START SOCKETSCAN
1. Press the trigger button that you just assigned. This is a quick way of starting
SocketScan.
Alternatively, tap Start | Programs | SocketScan folder | SocketScan.
2. When SocketScan is running, a SocketScan icon will appear at the bottom of the
Today screen.
Icon
Scanner
Version
Meaning
Any
No scanner detected. The scanner is missing, damaged,
or improperly inserted.
5C/5E2/5P
SocketScan detects the scanner and is ready to scan.
5X/5XRx
SocketScan detects the scanner and is ready to scan.
