Set-up Procedure Technical Specification
Make sure to turn off your computer or audio equipment. Turn down
all volume controls before you start set-up procedure.
1. Connect the wire of the left satellite unit into the jack on the back
panel of the subwoofer marked L. (Refer to figure 2)
2. Connect the wire of the right satellite unit into the jack on the back
panel of the subwoofer marked R. (Refer to figure 2)
3. Connect the to the LINE OUT terminal of the PC or other
audio equipment (or the headphone jack if a LINE OUT is
unavailable), plug the other end of the cable to the corresponding
input jack on the back panel of the subwoofer. (Refer to figure 2)
4. Connect the AC power cord to an electrical outlet. Press the power
switch to turn on the speaker system, and turn your PC on, then play
music with the audio equipment. Adjust the volume control, balance
control, treble control, bass control of the speaker system, along with
the controls of your PC or stereo system to your liking. You could now
be enjoying your new Multimedia speaker system.
signal line
Trouble shooting
Output Power: Subwoofer:8W
Satellite:3W*2
Speaker unit: Subwoofer: 4"
Satellite: 2.5”*2
Impedance: 4Ω
Frequency Response: Subwoofer: 80Hz-250Hz
Satellite:180Hz-18KHz
Power source: AC220V, 50Hz
Signal-to-noise ratio: ≥75DB
Dissociation: ≥40DB
Control:Volume,and Power on/off
Dimension:
Subwoofer:150*200*215mm(WxDxH)
Satellite: 85*82*146mm(WxDxH)
Packing size: 235*205*332mm(WxDxH)
Gross werght: 2.43KG
Warnings and Precautions
