User Guide
T
SONOS USER GUIDE
Beam
The smart, compact soundbar for your TV—
• Play anything—music, TV, movies, podcasts, radio, audiobooks, and video games.
• Perfect size to wall-mount above or below your TV, or place on a credenza.
• Great for small to medium-sized rooms.
•Microphone on/off so you can use it hands-free.
• Quick and easy setup, with only one cable to connect to your TV.
• Expandable. Add a Sub and two Sonos speakers, like Play:1s, for 5.1 surround sound. For more
information, see Sonos home theater.
• Works with either Sonos S2 or Sonos S1 (for Android and iOS).
• See Getting started when you’re ready to add a Beam to your Sonos system.
Controls and lights
Swipe, touch, tap, or ask—with Beam you’ve got choices on how to control sound.
• Use the touch controls—touch or swipe across the controls.
• Voice control—set it up and use your voice to turn the TV on or off, adjust the volume, or play music.
• Use the app.
• Use your TV remote control.
Microphone indicator
Volume down Volume up
Status light Play/Pause
SONOS USER GUIDE
Note: If you don’t want anyone (like a child) to control playback or change the volume using the speaker
touch controls, you can disable them in the room’s settings.
Volume control Touch for small adjustments or touch and hold to
quickly change the volume:
• Volume up (right)
• Volume down (left)
Note: You can also use the Sonos app, voice control,
or your TV remote.
Play/Pause Touch to play or pause sound.
Next/Previous
(Music only)
• Swipe right across the touch controls to skip to the
next song.
• Swipe left to go to the previous song.
Note: You can’t skip forward or go back when listening
to a radio station.
Microphone
indicator
• Tap the microphone light to turn the microphone on
or off.
• When the light is on, voice control is on and you can
use voice commands.
• When the light is off, voice control is off.
Note: If the light is off, you can press and hold the
Microphone indicator to talk to your voice
service. Release the button to turn voice control
off again.
Status light Indicates the status. Learn more
If the light is distracting, you can turn it off in your room’s
settings.
SONOS USER GUIDE
Connector panel
AC power (mains) input Use only the supplied power cord (using a third-party
power cord will void your warranty).
Note: Insert the power cord firmly until it is flush with
the speaker.
Join button Press to connect during setup.
Ethernet port Use an Ethernet cable if you want to connect to a router,
computer, or network-attached storage (NAS) device
(optional).
HDMI port Use to connect the soundbar to your TV.
HDMI port
Ethernet port
AC power (mains) input
Join button
SONOS USER GUIDE
Select a location
You can mount Beam to a wall above or below your TV or place it on a credenza.
Place on a credenza
• Place horizontally on a stable and level surface at least 2" (50mm) from the TV.
• Don’t place vertically or on its side.
• Don’t block the TV’s IR sensor.
• If put on a shelf, place at the front and keep 2" (minimum) clearance on both sides for best sound quality.
• Keep 1" (25mm) space (minimum) above Beam so you can reach the touch controls.
• For best sound quality, keep both ends of Beam at least 1' (30cm) from a wall or other obstruction.
Wall mount
To put Beam on a wall, see Wall mount.
Connect the cables
Before you start
1. Disconnect existing home theater or surround sound equipment from your TV.
2. Connect any external devices, like a cable box or DVD player, directly to your TV.
Connect the power cord
1. Insert the power cord firmly into Beam’s AC (mains) power port until it is fully connected.
2. Plug the other end of the power cord into an AC (mains) power source.
Caution: Use only the supplied power cord (using a third-party power cord will void your warranty).
Connect Beam to your TV
Use the HDMI cable to connect the soundbar to your TV. You may need the optical adapter too (the app lets
you know).
1. Fully insert the HDMI cable into Beam’s HDMI port.
HDMI port
HDMI cable
SONOS USER GUIDE
2. Connect the HDMI cable to your TV. You have two choices:
•If your TV has an HDMI ARC port, connect the HDMI cable directly to the TV’s HDMI ARC port.
•If your TV doesn’t have an HDMI ARC port, attach the optical adapter to the HDMI cable and connect
it to the TV’s optical digital OUT port.
If your TV has an HDMI ARC port
HDMI ARC is a special port that looks like a standard HDMI port. Although they look the same, if you connect
to a standard HDMI port, you won’t hear sound.
1. On your TV’s audio OUT panel, look for an HDMI ARC port.
It may be on the back or side of your TV.
You’ll know it’s an ARC port if you see the word “ARC” on the label.
2. Connect the HDMI cable to the TV’s HDMI ARC port.
Note: If you can’t find the word “ARC” on the label, it isn’t the correct port. See If your TV doesn’t have an
HDMI ARC port.
TV’s HDMI ARC port
Beam’s HDMI port
SONOS USER GUIDE
3. Connect the optical adapter to the TV’s optical digital OUT port.
Note: The optical adapter’s port is “D-shaped”—make sure the connector aligns correctly into the port.
Inserting the adapter incorrectly may damage the cable.
If you don’t have the app, download it from the app store. You’ll use it to set up and control your Sonos
system. See Getting started.
Microphone on/off
Touch to turn the microphone on and off. (If you don’t have a voice service installed, the microphone is
inactive.)
When the microphone light is on, voice control is on and your voice assistant is ready to respond. When the
microphone light is off, voice control is off.
Note: If you’ve installed a voice service and the microphone is off, you can still use voice commands. Just
press and hold —no need to start with a wake word. When you release the microphone button,
voice control turns off again.
Wall mount
Guidelines
• Use the Beam wall mount kit. You can buy it on www.sonos.com. Follow the instructions in the kit.
• Keep 1" (25mm) space (minimum) above Beam so you can reach the touch controls.
• If you’re mounting above the TV, make sure you can reach the touch controls.
• For best sound quality, keep both ends of Beam at least 1' (30cm) from a wall or other obstruction.
TV’s optical digital OUT port
Beam’s HDMI port
Optical adapter attached to
HDMI cable
SONOS USER GUIDE
Mount kit contents
• Wall mount bracket
• 4 wall anchors
• 4 wall screws
•2screws
Note: Don’t discard the template. It may look like packing material.
1. Tape the cardboard template to the wall above or below your TV. Use a level. Keep 1"(25mm) space
(minimum) for access to Beam’s touch controls. (Don’t install Beam vertically.)
2. Mark the center of the mounting holes and remove the template.
