Sonova Phonak Naida B Manuale utente

User Guide

Phonak NaídaTM B

(B90/B70/B50/B30)

Wireless models

Phonak Naída B90-SP

Phonak Naída B90-UP

Phonak Naída B70-SP

Phonak Naída B70-UP

Phonak Naída B50-SP

Phonak Naída B50-UP

Phonak Naída B30-SP

Phonak Naída B30-UP

CE mark applied

2017

This user guide is valid for:

Your hearing aid details

Model

cNaída B-SP (B90/B70/B50/B30)

cNaída B-UP (B90/B70/B50/B30)

Earpiece

cClassic earmold

Battery size

675

If no box is checked and you do not know the

model of your hearing aid, please ask your hearing

care professional.

Your hearing care professional:

Contents

Your hearing aid

1. Quick guide

2. Parts of the hearing aid

Using the hearing aid

3. Left & right hearing aid markings

4. On/O

5. Batteries

6. Putting on the hearing aid

7. Removing the hearing aid

8. Push button

9. Volume control

10. Roger for conversation in noise and

over distance

11. Use of Roger receivers

Further Information

12. Join our hearing loss community!

13. A solution beyond your hearing aid

14. Care and maintenance

15. Service and warranty

16. Compliance information

17. Information and description of symbols

18. Troubleshooting

19. Important safety information

Your hearing aids have been developed by

Phonak – the world leader in hearing solutions based

in Zurich, Switzerland.

These premium products are the result of decades of

research and expertise and are designed to keep you

connected to the beauty of sound! We thank you for

making such a great choice and wish you many years of

listening pleasure.

Please read the user guide carefully to make sure that you

understand and get the best out of your hearing aids. For

more information about features and benets, simply

contact your hearing care professional.

Phonak – life is on

www.phonak.com

6 7

1. Quick guide

Left & right hearing aid markings On/O

Changing batteries Push button

Volume control

1 2

Blue marking for

left hearing aid.

Red marking for

right hearing aid.

Remove the

sticker from the

new battery and

wait two minutes.

Open the

battery door.

Place battery in

the battery door

with the “+” symbol

facing upwards.

The push button on your hearing

aid can have various functions.

To increase the volume, press the

volume control upwards. To

decrease the volume, press the

volume control downwards.

O

8 9

2. Parts of the hearing aid

The pictures below show the possible earpiece and model

described in this user guide.

Push button

Naída B-SP & B-UP

Hook / sound output

Classic earmold

(detachable)

Battery door

Volume control

Classic earmold

3. Left & right hearing aid markings

There is a red or blue marking to tell you if it is a left

or a right hearing aid.

Blue marking for left hearing aid.

Red marking for right hearing aid.

10 11

4. On/O

The battery door is also the on/o switch.

Closed battery door =

hearing aid is on

Open battery door =

hearing aid is o

When you switch on the hearing aid you may hear

a start-up melody.

5. Batteries

If it is dicult to close the battery door: Check that

the battery is inserted correctly and the “+” symbol

is facing upwards. If the battery is not inserted

correctly, the hearing aid will not work and the

battery door can be damaged.

Open the

battery door.

1 2

Place battery in

the battery door

with the “+”

symbol facing

upwards.

Remove the

sticker from the

new battery and

wait two minutes.

12 13

Replacement battery

This hearing aid requires zinc-air batteries. Identify the

correct battery size (13 or 675) by:

• Checking “Your hearing aid details” on page 3.

• Checking the marking on the inner side of the

battery door.

• Checking the following table.

Model

Phonak Naída

B-SP

B-UP

Zinc-air

battery

size

675

Color

marking on

package

orange

blue

IEC

code

PR48

PR44

ANSI

code

7000ZD

7003ZD

Low power: You will hear two beeps when the battery

is low. You will have approximately 30 minutes to

change the battery (this can vary, depending on the

hearing aid settings and battery). We recommend that

you always have a new battery on hand.

Please ensure you use the correct type of battery in

your hearing aids (zinc-air). Please also read chapter

19.2 for further information on product safety.

6. Putting on the hearing aid

Take the earmold up to your ear

and place the ear canal part into

your ear canal.

Place the hearing aid behind

your ear.

Insert the upper part of the

earmold into the upper part of

the bowl of your ear.

14 15

7. Removing the hearing aid

Lift the hearing aid above the upper

part of your ear.

Grasp the earmold with your ngers

and gently remove it.

Please try to avoid gripping the tube to remove the

hearing aid.

8. Push button

The push button on your

hearing aid can have

various functions or is

not active. This depends

on the programming of

the hearing aid which is

indicated in your

individual “Hearing aid

instructions”. Please

ask your hearing

care professional for

this printout.

16 17

9. Volume control

To increase the volume,

press the volume control

upwards. To decrease the

volume, press the volume

control downwards.

The volume control can

be disabled by the hearing

care professional.

10. Roger for conversation in noise

and over distance

Are you often in situations where the noise level is high

or the distance to the speaker/talker is more than

1.5 m (5 feet)? For instance in

• noisy restaurants, cafés and bars

• family gatherings

• business meetings, presentations and lectures featuring

one or more speakers

• one-to-one conversations

• cell phone calls

• watching TV and listening to music

• in the car

• online video calls

Combining your Phonak Naída B hearing aids with a

Roger wireless microphone enables you to hear and

understand more speech in these challenging situations.

www.phonak.com/roger

18 19

The Roger microphone transmits the speaker’s voice

directly into your ears. The system consists of three main

elements: your hearing aids, Roger receivers and the

Roger microphone.

Ask your hearing care professional for a Roger demo

and more information.

SpeakerListener

Hearing

aid with

Roger

receiver

Roger

microphone

Hearing aid

Design-integrated

receiver

Your hearing care professional has already prepared

your hearing aid for use with Roger. Please ask your

hearing care professional for further information.

11.1 Design-integrated Roger receivers

Your Phonak Naída B hearing aids can be equipped with

design-integrated Roger receivers.

With the design-integrated receiver attached, the hearing

aid oers all functionalities and usability as without the

receiver. The hearing aid with the design-integrated

receiver is water resistant, refer to chapter 14.

11. Use of Roger receivers
