Trouble Shooting Guide, Electrical

4/000 21-2/FEA 209 544/109 E

Company Internal ©Sony Ericsson Mobile Communications AB

Trouble Shooting Guide, Electrical

Applicable for K610i, K610im, K618i, V630i

Contents

1General............................................................................................................... 2

2Repair Actions for Manual Test Failures......................................................... 2

2.1 Audio ..................................................................................................... 2

2.2 Bluetooth ............................................................................................... 2

2.3 Charging................................................................................................ 2

2.4 Charging LED........................................................................................ 2

2.5 Camera.................................................................................................. 2

2.6 Display................................................................................................... 2

2.7 Key ........................................................................................................ 2

2.8 Memory stick ......................................................................................... 3

2.9 On/Off.................................................................................................... 3

2.10 RTC ....................................................................................................... 3

2.11 SIM ........................................................................................................ 3

2.12 USB ....................................................................................................... 3

3Repair Actions for Go/No Go Test Failures .................................................... 3

4Repair Actions for Calibration Failures........................................................... 3

5Revision History................................................................................................ 4

Trouble Shooting Guide, Electrical

4/000 21-2/FEA 209 544/109 E

Company Internal ©Sony Ericsson Mobile Communications AB

2(4)

1General

The purpose of this document is to indicate the electrical level repair actions associated with

the different failure symptoms.

For symptoms that have multiple repair actions, the repair actions are listed in order of their

probability of creating a successful repair. The first action has the highest probability, and

subsequent actions have lower probabilities. The intention is for the repair technician to

implement the first repair action and then retest the phone. If the phone continues to fail the

same test, then the technician should continue to the second repair action. If the phone

continues to fail the same test after all of the repair actions are exhausted, then the phone will

be considered not reparable at this level.

This document should be used only after the actions from the Mechanical Trouble Shooting

Guide have been exhausted for the specific symptom.

Voltage, current, and resistance information is provided for some symptoms to enable faster

repairs. Perform current measurements using a dummy battery and power supply with digital

current display. The phone should be fully assembled. Perform voltage and resistance

measurements with a multimeter. Purchasing this equipment and performing these

measurements is optional but recommended.

2Repair Actions for Manual Test Failures

Failure Failure Symptom Repair Action

No microphone or low gain Replace B4101

Replace V4106

Replace N2000

No or poor audio in loudspeaker Replace V4101

2.1 Audio

Polyphonic Speaker (Alert, Speakerphone) Replace N4100

2.2 Bluetooth Replace Z1400

Replace D1400

2.3 Charging Can’t charge Replace V2202, V2203

Replace V2204

Replace N2000

2.4 Charging LED Replace V3110

Problems with the Mega pixel camera Replace X2505 if damaged

2.5 Camera

Problem with the video call camera Replace X2510 if damaged

2.6 Display Replace X2590 if damaged

Replace Z3100, Z3101 & Z3102

Keyboard problem Replace X2591 if damaged

Replace V2506, V2509 & V2510

Volume keys Replace S2512 if damaged

Replace S2513 if damaged

Replace V2506, V2509 & V2510

2.7 Key

Media player key Replace S2511 if damaged

Trouble Shooting Guide, Electrical

4/000 21-2/FEA 209 544/109 E

Company Internal ©Sony Ericsson Mobile Communications AB

3(4)

2.8 Memory stick Replace X2301 if damaged

Can’t power on Replace S2500 If damaged

Replace X2200 If damaged

Replace N2000

Current draw when powered off Replace A1300 – Approved

Centers Only

Turns off by itself Replace X2200 If damaged

2.9 On/Off

Hangs at gray display. Constant vibration.

Will not power off.

Replace B2100

2.10 RTC The clock has to be set after the battery

has been detached.

Replace C2217, B2100

2.11 SIM Replace X3202 if damaged

2.12 USB Replace N2300

Replace D2304

3Repair Actions for Go/No Go Test Failures

Failure Repair Action

Fails any part of Go/No Go testing Run the calibration routine.

Fails Go/No Go test, but passes calibration Replace the antenna.

Replace antenna connector

Rerun the phone through Go/No Go testing.

Fails Go/No Go test after passing calibration Change X1000 and re-test.

4Repair Actions for Calibration Failures

Failure Repair Action

Fails any part of the GSM calibration routine Replace A1300 – Approved Centers Only

Replace N2000

Fails any part of the UMTS calibration routine Replace A1200 – Approved Centers Only

Replace D2001

Replace A1300 – Approved Centers Only

Trouble Shooting Guide, Electrical

4/000 21-2/FEA 209 544/109 E

Company Internal ©Sony Ericsson Mobile Communications AB

4(4)

5Revision History

Rev. Date Changes / Comments

A 2006-06-20 First release

B 2006-08-28 Parts Numbers Updated

C 2006-08-31 TSG update

D 2006-12-11 TSG Update

E 2007-01-12 N4100 added to Audio
