Sony Ericsson Z320 Manuale utente

Z320

User guide

This is the Internet version of the User's guide. © Print only for private use.

Congratulations on your purchase of the

Sony Ericsson Z320. For additional phone content,

go to www.sonyericsson.com/fun. Register now

to get free online storage and special offers at

www.sonyericsson.com/myphone. For product

support, go to www.sonyericsson.com/support.

Instruction symbols

The following instruction symbols appear in this

User guide:

> Use the navigation key to scroll and select.

Press the navigation key up.

Press the navigation key down.

Press the navigation key to the left.

Press the navigation key to the right.

Tip

Note

Warning

Indicates that a service or function is network-

or subscription-dependent. All menus or functions

may not be available in your phone. Consult

your network operator for more information.

This is the Internet version of the User's guide. © Print only for private use.

Prepare the phone

Always turn off your phone and detach the charger

before you insert or remove the SIM card.

To insert the SIM card and battery

1Remove the battery cover by sliding the battery release

latch down.

2Slide the SIM card into its holder with the contacts

facing down.

3Insert the battery with the label side up and the

connectors facing each other.

4Slide the battery cover into place and close the battery

release latch.

This is the Internet version of the User's guide. © Print only for private use.

Charge the battery

Your phone battery is partly charged when you buy it.

It takes approximately 3 hours to fully charge the battery.

To charge the battery

1Connect the charger to the phone. Press a key to view

the charging status on the screen.

2To remove the charger, tilt the plug upwards.

It may take 30 minutes for the battery icon to appear

on the screen.

You can use the phone during charging. You can

charge the battery for more or less than 3 hours.

Interrupted charging will not damage the battery.

This is the Internet version of the User's guide. © Print only for private use.

Turn the phone on

To turn on the phone

1Press and hold down .

2Enter your PIN if

requested. To correct

mistakes, press .

3Select OK.

4Select a language.

5At first start-up, select Yes to use the setup wizard

to make a phone setup. Select No to use the setup

wizard later.

To turn off the phone

•Press and hold down .

To use the setup wizard

•From standby select Menu > Settings > General

>Setup wizard > Basic setup.

After you have turned the phone on and entered

your PIN, the name of your operator appears on

the screen. This view or screen is called standby.

You can now make and receive calls.

This is the Internet version of the User's guide. © Print only for private use.

SIM card

The SIM (Subscriber Identity Module) card,

which you get from your network operator,

contains information about your subscription.

Always turn off your phone and detach the

charger before you insert or remove the SIM card.

PIN code (SIM card lock)

The PIN (Personal Identification Number) code is a SIM

card lock that protects your subscription, but not the

phone itself. If the card is locked, you have to enter the

PIN code when you turn on your phone. Each PIN digit

appears as *, unless it starts with emergency number

digits, for example, 112 or 911. You can call an emergency

number without entering a PIN.

You can save contacts on the SIM card before

removing if from your phone. Contacts may also

be saved in the phone memory. See Contacts on

page 17.

If you enter the wrong PIN three times in a row,

the following message appears: PIN blocked. To

unblock, enter your PUK code provided by your

network operator. To unblock your SIM card, see

Locks on page 34.

This is the Internet version of the User's guide. © Print only for private use.

Menu overview

Calls Internet Games

Camera Messaging File manager

Write new

Inbox

Drafts

Outbox

Sent messages

Saved messages

Call voicemail

Templates

Settings

Camera album

Pictures

Ringtones

Themes

Bookmarks

Games

Applications

Other

Organizer Contacts Settings

Online services

Alarms

Applications

Calendar

Tasks

Notes

Calculator

Timer

Stopwatch

Options

New contact

General

Sounds & alerts

Display

Calls

Connectivity

Some menus and icons described in this document may vary

depending on operator, network or subscription. Some options

may vary when the default settings are changed.

This is the Internet version of the User's guide. © Print only for private use.

Phone overview

Camera key

Back key

Internet key Navigation key

Volume

buttons

C key (Clear)

On/off key

Infrared port

Microphone

Right

selection key

Left selection

key

Charging

(USB

connector)

Network

coverage

Battery status

Function for

right selection

key

Function for

left selection

key

Calls Menu

This is the Internet version of the User's guide. © Print only for private use.

Network coverage

The network bars show the strength of the GSM network.

Move to another location if you have network problems.

No netw. coverage means you are out of range.

Battery status

The outside

= Good network coverage

= Average network coverage

= The phone battery is fully charged

= The phone battery is empty

Icon display

Camera lens

This is the Internet version of the User's guide. © Print only for private use.

Icons

These icons may appear in your phone.

Icon Description

Battery charging, appears with battery icon.

You have missed a call. See Calling on page 15.

The phone is set to silent.

You have received a new text message.

You have received a new picture message.

Ongoing call.

Divert calls is activated.

An alarm is activated.

The loudspeaker is on.

The infrared port is activated.

The stopwatch is activated.

This is the Internet version of the User's guide. © Print only for private use.
