Sony Alpha DSLR-A100KS Manuale utente

Sony DSLR-A100KS

The Sony á (alpha) DSLR-A100 Series camera is an instant classic:

the top-quality 10 MP DSLR system camera that builds on a

two-decade legacy of Minolta photographic leadership, accepts 20

years of A-mount lenses sold worldwide - and introduces Sony

imaging innovations like high-sensitivity shooting with Super

SteadyShot in-camera image stabilization, Dynamic Range

Optimizer to automatically increase detail in bright and dark picture

areas, Anti-Dust technology to keep the CCD imager clean for better

pictures, and Eye-Start Autofocus system for faster camera

response.

www.dooyoo.co.uk :: Photography :: Digital Camera :: Sony DSLR-A100KS

General

Product Type Digital camera - SLR

Width 13.3 cm

Depth 7.1 cm

Height 9.5 cm

Weight 545 g

Enclosure Colour Silver

Main Features

Resolution 10.2 Megapixel

Colour Support Colour

Optical Sensor Type CCD

Total Pixels 10,800,000 pixels

Effective Sensor Resolution 10,200,000 pixels

Optical Sensor Size 15.8 x 23.6mm

Field of View Crop Factor 1.5

Sensor Dust Reduction Yes

Sensor Features Anti-Dust technology

Light Sensitivity ISO 100, ISO 800, ISO 400, ISO 200, ISO 1600, ISO auto

Shooting Modes Landscape, portrait mode, night portrait, sunset

Special Effects Black & White, Neutral, Vivid

Image Stabiliser Optical (Super Steady Shot, CCD-shift mechanism)

Max Shutter Speed 1/4000 sec

Min Shutter Speed 30 sec

X-sync Speed 1/160 sec

Exposure Metering Multi-segment, centre-weighted, spot

Exposure Modes Programme, bulb, automatic, manual, aperture-priority,

shutter-priority

Exposure Range EV 1-20 ( ISO 100 )

Exposure Compensation ±2 EV range, in 1/3 EV steps

Auto Exposure Bracketing 3 steps in 1/3 EV step

Exposure Metering Zones 40

White Balance Custom, automatic, presets

White Balance Presets Fluorescent, cloudy, tungsten light, Flash, daylight, shad

Still Image Format JPEG, RAW, RAW + JPEG

Continuous Shooting Speed 3 frames per second

Remote Control Optional

Memory / Storage

Supported Flash Memory CompactFlash, Microdrive

Image Storage 3872 x 2592 ¦ 2896 x 1936 ¦ 1920 x 1280

Camera Flash

Camera Flash Pop-up flash

Guide Number (m / ISO 100) 12

Flash Modes Fill-in mode, rear curtain sync, auto mode, flash OFF

mode, red-eye reduction

Red Eye Reduction Built-in

Features AF illuminator, flash +/- compensation, wireless off-camer

a control

Lens System

Type Zoom lens - 18 mm - 70 mm - f/3.5-5.6 DT

Focal Length 18 mm - 70 mm

Focal Length Equivalent to 35mm Camera 27 - 105mm

Focus Adjustment Automatic, manual

Auto Focus TTL phase detection

Auto Focus Points (Zones) 9

Min Focus Range 38 cm

Lens Aperture F/3.5-5.6

Optical Zoom 3.9 x

Zoom Adjustment Manual

Lens Construction 9 group(s) / 11 element(s)

Filter Size 55 mm

Lens System Mounting Minolta A-type

Features ED glass, aspherical lens

Additional Features

Self Timer Yes

Self Timer Delay 10 sec, 2sec

Flash Terminal Hot shoe

Additional Features Direct print, USB 2.0 compatibility, RGB primary colour

filter, digital noise reduction, DPOF support,

depth-of-field preview button, sharpness control, PRINT

Image Matching, PictBridge support, histogram display, AE

lock, AF lock, contrast control, Dynamic Range Optimizer

Viewfinder

Viewfinder Type Optical - eye-level roof prism

Field Coverage 95%

Magnification 0.83x

Dioptric Correction Range -2.5 to +1

Viewfinder Frames Autofocus frame

LCD Display Information Shutter speed, exposure compensation, AE lock,

AF-in-focus, flash charge completion, aperture,

anti-shake scale, shake warning

Display

Type LCD display - TFT active matrix - 2.5" - colour

Display Form Factor Built-in

Display Format 230,000 pixels

Connections

Connector Type 1 x USB ¦ 1 x composite video output ¦ 1 x DC power input

¦ 1 x remote control

Expansion Slot(s) 1 x CompactFlash Card - type I/II

Software

Software Drivers & Utilities, Sony Picture Motion Browser, Sony

Image Data Converter SR

System Requirements for PC Connection

Operating System Support MS Windows XP, MS Windows 2000, MS Windows ME, Apple

MacOS X 10.3 or later

Miscellaneous

Included Accessories Lens hood, dust cap, body cap, lens cap, shoulder strap,

shoe cap

Cables Included USB cable ¦ Video cable

Power

Power Device Battery charger - external

Battery

Supported Battery Sony NP-FM55

Supported Battery Details 1 x Li-ion rechargeable battery - 1600 mAh ( included )

Manufacturer Warranty

Service & Support 1 year warranty

Service & Support Details Limited warranty - 1 year

Environmental Parameters

Min Operating Temperature 0 °C

Max Operating Temperature 40 °C
