Sony Cyber-shot DSC-S5000 Manuale utente

4-417-244-81(2)

DSC-S5000

Digital Still Camera / Instruction Manual GB

Kamera Digital / Panduan Pengguna ID

The number in parentheses indicates the number of pieces.

• Camera (1)

• LR6 (size AA) alkaline batteries (2)

• Dedicated USB cable (1) (Sony Corporation 1-834-311-)

• Wrist strap (1)

• Instruction Manual (this manual) (1)

English

Learning more about the camera (“Cyber-shot

User Guide”)

“Cyber-shot User Guide” is an on-line manual. Refer to it for

in-depth instructions on the many functions of the camera.

1Access the Sony support page.

http://www.sony.net/SonyInfo/Support/

2Select your country or region.

3Search for the model name of your camera within the

support page.

• Check the model name on the bottom of your camera.

Checking the supplied items

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial number in the

space provided below. Refer to these numbers whenever you call your Sony dealer

regarding this product.

Model No. DSC-S5000

Serial No. _____________________________

To reduce fire or shock hazard, do not expose the unit to rain or

moisture.

If you have any questions about this product, you may call:

Sony Customer Information Center

1-800-222-SONY (7669).

The number below is for the FCC related matters only.

[Regulatory Information

[CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual

could void your authority to operate this equipment.

WARNING

For Customers in the U.S.A.

Declaration of Conformity

Trade Name: SONY

Model No.: DSC-S5000

Responsible Party: Sony Electronics Inc.

Address: 16530 Via Esprillo,

San Diego, CA 92127 U.S.A.

Telephone No.: 858-942-2230

This device complies with Part15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may cause

undesired operation.

[Note:

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

The supplied interface cable must be used with the equipment in order to comply with the

limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

[Notice for the customers in the countries applying EU Directives

The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo,

108-0075 Japan. The Authorized Representative for EMC and product safety is Sony

Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or

guarantee matters please refer to the addresses given in separate service or guarantee

documents.

This product has been tested and found compliant with the limits set out in the EMC

Directive for using connection cables shorter than 3 meters (9.8 feet).

[Attention

The electromagnetic fields at the specific frequencies may influence the picture and sound

of this unit.

[Notice

If static electricity or electromagnetism causes data transfer to discontinue midway (fail),

restart the application or disconnect and connect the communication cable (USB, etc.)

again.

[Disposal of Old Electrical & Electronic Equipment (Applicable in

the European Union and other European countries with separate

collection systems)

This symbol on the product or on its packaging indicates that this product

shall not be treated as household waste. Instead it shall be handed over to

the applicable collection point for the recycling of electrical and electronic

equipment. By ensuring this product is disposed of correctly, you will help

prevent potential negative consequences for the environment and human

health, which could otherwise be caused by inappropriate waste handling

of this product. The recycling of materials will help to conserve natural

resources. For more detailed information about recycling of this product,

please contact your local Civic Office, your household waste disposal service or the shop

where you purchased the product.

For Customers in Europe

[Disposal of waste batteries (applicable in the European Union

and other European countries with separate collection systems)

This symbol on the battery or on the packaging indicates that the battery

provided with this product shall not be treated as household waste.

On certain batteries this symbol might be used in combination with a

chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are

added if the battery contains more than 0.0005% mercury or 0.004% lead.

By ensuring these batteries are disposed of correctly, you will help prevent

potentially negative consequences for the environment and human health which could

otherwise be caused by inappropriate waste handling of the battery. The recycling of the

materials will help to conserve natural resources.

In case of products that for safety, performance or data integrity reasons require a

permanent connection with an incorporated battery, this battery should be replaced by

qualified service staff only. To ensure that the battery will be treated properly, hand over

the product at end-of-life to the applicable collection point for the recycling of electrical

and electronic equipment.

For all other batteries, please view the section on how to remove the battery from the

product safely.

Hand the battery over to the applicable collection point for the recycling of waste batteries.

For more detailed information about recycling of this product or battery, please contact

your local Civic Office, your household waste disposal service or the shop where you

purchased the product.

AON/OFF (Power) button

BShutter button

CON/OFF (Power) lamp

DSelf-timer lamp/Smile Shutter

lamp

ELens

FSpeaker

GFlash

HLCD screen

I(Playback) button

JControl button

MENU on: v/V/b/B/z

MENU off: DISP/ / / /

Tracking focus

KMENU button

LAccess lamp

M/ (In-Camera Guide/Delete)

button

NUSB / A/V OUT jack

OHook for wrist strap

PMode switch: (Still image)/

(Sweep Panorama)/

(Movie)

QFor shooting: W/T (Zoom)

button

For viewing: (Playback

zoom) button/ (Index) button

RBattery/memory card cover

STripod receptacle

• Use a tripod with a screw less

than 5.5 mm (7/32 inches) long.

Otherwise, you cannot firmly

secure the camera, and damage to

the camera may occur.

TMicrophone

UBattery insertion slot

VMemory card slot

Identifying parts

Memory cards that you can use

Inserting the batteries/a memory card (sold

separately)

1Open the cover.

2Insert the memory card (sold separately).

• With the notched corner facing as illustrated, insert the memory card

until it clicks into place.

3Match +/– and insert the batteries.

4Close the cover.

Memory Card For still images For movies

Memory Stick PRO Duo aa

Memory Stick PRO-HG Duo aa

Memory Stick Duo a—

BMemory Stick Micro (M2) aa

CSD memory card aa(Class 2 or faster)

SDHC memory card aa(Class 2 or faster)

DmicroSD memory card aa(Class 2 or faster)

microSDHC memory card aa(Class 2 or faster)

Ensure the notched corner faces correctly.

In this manual, the products in the table are collectively referred to as

followings:

A: “Memory Stick Duo” media

B: “Memory Stick Micro” media

C: SD card

D: microSD memory card

• When using “Memory Stick Micro” media or microSD memory cards with this

camera, make sure to use with the appropriate adaptor.

To remove the memory card/batteries

Memory card: Push the memory card in once.

Batteries: Be sure not to drop the batteries.

• Never open the battery/memory card cover or remove the batteries/memory card

when the access lamp (page 7) is lit. This may cause damage to data in the

memory card/internal memory.

Batteries you can and cannot use with your camera

In the table below, aindicates the battery can be used, while — indicates the

one cannot be used.

* Operating performance cannot be ensured if voltage drops or other problems are

caused by the nature of the battery.

Note

Battery type Supplied Supported Rechargeable

LR6 (size AA) alkaline

batteries aa—

HR15/51: HR6 (size AA)

Nickel-Metal Hydride

batteries

—aa

ZR6 (size AA) Oxy Nickel

Primary batteries —a—

Lithium batteries* — — —

Manganese batteries* — — —

Ni-Cd batteries* — — —

Battery life and number of images you can record/

view

• The number of images that can be recorded is an approximate number when

shooting with new batteries. The number may be less depending on the

circumstances.

• The number of images that can be recorded is when shooting under the following

conditions:

– Using Sony “Memory Stick PRO Duo” (Mark2) media (sold separately).

– New batteries are used at an ambient temperature of 25°C (77°F).

• The number of still images that can be recorded is based on the CIPA standard,

and is for shooting under the following conditions.

(CIPA: Camera & Imaging Products Association)

– [SteadyShot] is set to [Off].

– [Panel Brightness] is set to [3].

– Shooting once every 30 seconds.

– The zoom is switched alternately between the W and T ends.

– The flash strobes once every two times.

– The power turns on and off once every ten times.

• The battery life for movies is when shooting under the following conditions:

– Recording mode: VGA

– When continuous shooting ends because of set limits (page 19), press the shutter

button down again and continue shooting. Shooting functions such as the zoom

do not operate.

• The values shown for alkaline battery are based on commercial norms, and do not

apply to all alkaline batteries in all conditions. The values may vary, depending on

the battery manufacturer/type, environmental conditions, product setting, etc.

Battery life (min.) Number of Images

Shooting still images Approx. 95 Approx. 190

Viewing still images Approx. 380 Approx. 7600

Shooting movies Approx. 162 —

Notes

Altri manuali per Cyber-shot DSC-S5000

Indice

Lingue:

Altri manuali Sony Macchina fotografica digitale

Sony

Sony Cyber-shot DSC-WX30 Manuale utente

Sony

Sony Cyber-shot DSC-W5 Istruzioni operative

Sony

Sony bloggie MHS-FS1K Manuale utente

Sony

Sony Cyber-shot DSC-HX3 Manuale utente

Sony

Sony Cyber-shot DSC-WX100 Manuale utente

Sony

Sony Cyber-Shot DSC-P73 Manuale utente

Sony

Sony Alpha 6700 Guida utente

Sony

Sony Cyber-shot DSC-W210B Manuale utente

Sony

Sony Cyber-shot H3 Manuale utente

Sony

Sony DSC-WX220 Manuale utente

Sony

Sony MHS PM1 - Webbie HD Camcorder Manuale utente

Sony

Sony Cyber-shot DSC-TX20 Manuale utente

Sony

Sony DSC-T700/R Cyber-shot® Manuale utente

Sony

Sony Cyber-shot DSC-H20 Manuale utente

Sony

Sony Cyber-shot DSC-S600 Manuale utente

Sony

Sony ILCE-5100 Manuale utente

Sony

Sony Cyber-shot DSC-T110 Manuale utente

Sony

Sony Cyber-shot DSC-HX50 Manuale utente

Sony

Sony Cyber-shot DSC-P9 Manuale utente

Sony

Sony Cyber-shot DSC-P1 Guida alla risoluzione dei problemi

Sony

Sony Alpha ILCA-77M2 Manuale utente

Sony

Sony Cyber-shot DSC-HX1 Manuale utente

Sony

Sony Cyber-shot DSC-TX100 Manuale utente

Sony

Sony Multi Functional Digital Camera Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Canon

Canon EOS ELAN7 Manuale utente

Nikon

Nikon Coolpix 100 Manuale utente

Samsung

Samsung SCC-C4253 Manuale utente

JVC

JVC GT-HM890 Manuale utente
