4-265-856-22(1)

DSC-WX7/WX9

Digital Still Camera / Instruction Manual GB

Cámara fotografía digital / Manual de instrucciones ES

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial number in the

space provided below. Refer to these numbers whenever you call your Sony dealer

regarding this product.

Model No. DSC-TX100/TX100V

Serial No. ______________________________

Model No. AC-UB10/UB10B

Serial No. ______________________________

To reduce fire or shock hazard, do not expose the unit to rain or

moisture.

IMPORTANT SAFETY INSTRUCTIONS

-SAVE THESE INSTRUCTIONS

DANGER

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, CAREFULLY FOLLOW THESE

INSTRUCTIONS

If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the

proper configuration for the power outlet.

[Battery pack

If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical

burns. Observe the following cautions.

• Do not disassemble.

• Do not crush and do not expose the battery pack to any shock or force such as

hammering, dropping or stepping on it.

• Do not short circuit and do not allow metal objects to come into contact with the battery

terminals.

• Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a

car parked in the sun.

• Do not incinerate or dispose of in fire.

English

WARNING

CAUTION

• Do not handle damaged or leaking lithium ion batteries.

• Be sure to charge the battery pack using a genuine Sony battery charger or a device that

can charge the battery pack.

• Keep the battery pack out of the reach of small children.

• Keep the battery pack dry.

• Replace only with the same or equivalent type recommended by Sony.

• Dispose of used battery packs promptly as described in the instructions.

[AC Adaptor

Connect the AC Adaptor to the nearest wall outlet (wall socket).

If some trouble occurs while using the AC Adaptor, immediately shut off the power by

disconnecting the plug from the wall outlet (wall socket).

The power cord (mains lead), if supplied, is designed specifically for use with this camera

only, and should not be used with other electrical equipment.

[RECYCLING LITHIUM-ION BATTERIES

Lithium-Ion batteries are recyclable.

You can help preserve our environment by returning your used

rechargeable batteries to the collection and recycling location nearest

you.

For more information regarding recycling of rechargeable batteries,

call toll free

1-800-822-8837, or visit http://www.rbrc.org/

Caution: Do not handle damaged or leaking Lithium-Ion batteries.

[Battery pack

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This Class B digital apparatus complies with Canadian ICES-003.

UL is an internationally recognized safety organization.

The UL Mark on the product means it has been UL Listed.

If you have any questions about this product, you may call:

Sony Customer Information Center

1-800-222-SONY (7669).

The number below is for the FCC related matters only.

For Customers in the U.S.A. and Canada

For Customers in the U.S.A.

[Regulatory Information

[CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual

could void your authority to operate this equipment.

[Note:

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

The supplied interface cable must be used with the equipment in order to comply with the

limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

Declaration of Conformity

Trade Name: SONY

Model No.: DSC-TX100V

Responsible Party: Sony Electronics Inc.

Address: 16530 Via Esprillo,

San Diego, CA 92127 U.S.A.

Telephone No.: 858-942-2230

This device complies with Part15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may cause

undesired operation.

Hereby, Sony Corporation, declares that this DSC-TX100V Digital Still Camera is in

compliance with the essential requirements and other relevant provisions of the Directive

1999/5/EC. For details, please access the following URL:

http://www.compliance.sony.de/

[Notice for the customers in the countries applying EU Directives

The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo,

108-0075 Japan. The Authorized Representative for EMC and product safety is Sony

Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or

guarantee matters please refer to the addresses given in separate service or guarantee

documents.

This product has been tested and found compliant with the limits set out in the EMC

regulation for using connection cables shorter than 3 meters (9.8 feet).

[Attention

The electromagnetic fields at the specific frequencies may influence the picture and sound

of this unit.

[Notice

If static electricity or electromagnetism causes data transfer to discontinue midway (fail),

restart the application or disconnect and connect the communication cable (USB, etc.)

again.

[Disposal of Old Electrical & Electronic Equipment (Applicable in

the European Union and other European countries with separate

collection systems)

This symbol on the product or on its packaging indicates that this product

shall not be treated as household waste. Instead it shall be handed over to

the applicable collection point for the recycling of electrical and electronic

equipment. By ensuring this product is disposed of correctly, you will help

prevent potential negative consequences for the environment and human

health, which could otherwise be caused by inappropriate waste handling

of this product. The recycling of materials will help to conserve natural

resources. For more detailed information about recycling of this product,

please contact your local Civic Office, your household waste disposal service or the shop

where you purchased the product.

For Customers in Europe

[Disposal of waste batteries (applicable in the European Union

and other European countries with separate collection systems)

This symbol on the battery or on the packaging indicates that the battery

provided with this product shall not be treated as household waste.

On certain batteries this symbol might be used in combination with a

chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are

added if the battery contains more than 0.0005% mercury or 0.004% lead.

By ensuring these batteries are disposed of correctly, you will help prevent

potentially negative consequences for the environment and human health which could

otherwise be caused by inappropriate waste handling of the battery. The recycling of the

materials will help to conserve natural resources.

In case of products that for safety, performance or data integrity reasons require a

permanent connection with an incorporated battery, this battery should be replaced by

qualified service staff only. To ensure that the battery will be treated properly, hand over

the product at end-of-life to the applicable collection point for the recycling of electrical

and electronic equipment.

For all other batteries, please view the section on how to remove the battery from the

product safely.

Hand the battery over to the applicable collection point for the recycling of waste batteries.

For more detailed information about recycling of this product or battery, please contact

your local Civic Office, your household waste disposal service or the shop where you

purchased the product.

A moulded plug complying with BS 1363 is fitted to this equipment for your safety and

convenience.

Should the fuse in the plug supplied need to be replaced, a fuse of the same rating as the

supplied one and approved by ASTA or BSI to BS 1362, (i.e., marked with an or

mark) must be used.

If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the

fuse cover after you change the fuse. Never use the plug without the fuse cover. If you

should lose the fuse cover, please contact your nearest Sony service station.

Notice for customers in the United Kingdom

For details on advanced operations, please read “Cyber-shot User Guide”

(HTML) on the CD-ROM (supplied) using a computer.

For Windows users:

1Click [User Guide] t[Install].

2Start “User Guide” from the shortcut on the desktop.

For Macintosh users:

1Select the [User Guide] folder and copy [eng] folder stored in [User Guide]

folder to your computer.

2After copying is complete, double-click “index.html” in [eng] folder.

• Camera (1)

• Rechargeable battery pack NP-BN1 (1)

• Multi-use terminal USB cable (1)

• AC Adaptor AC-UB10/UB10B (1)

• Power cord (mains lead) (not supplied in the USA and Canada) (1)

• Paint pen (1)

• Wrist strap (1)

•CD-ROM(1)

– Cyber-shot application software

– “Cyber-shot User Guide”

• Instruction Manual (this manual) (1)

Refer to “Cyber-shot User Guide” (HTML) on

supplied CD-ROM

Checking the supplied items

Insert the CD-ROM into the CD-ROM drive.

AFlash

BLens cover

CMicrophone

DGPS sensor (built-in, DSC-

TX100V only)

ELens

FSelf-timer lamp/Smile Shutter

lamp/AF illuminator

GSpeaker

H(Playback) button

IScreen/Touch panel

JON/OFF (Power) button

KShutter button

LFor shooting: W/T (Zoom) lever

MHook for wrist strap

NTripod receptacle

• Use a tripod with a screw less

than 5.5 mm (7/32 inches) long.

Otherwise, you cannot firmly

secure the camera, and damage to

the camera may occur.

OBattery eject lever

PBattery insertion slot

Q(TransferJet™) mark

RBattery/memory card cover

SMulti connector (Type3b)

TAccess lamp

UMemory card slot

VHDMI connector

WConnector cover

Identifying parts

Inserting the battery pack

1Open the cover.

2Insert the battery pack.

• While pressing the battery eject lever, insert the battery pack as

illustrated. Make sure that the battery eject lever locks after insertion.

Charging the battery pack

Eject lever

Power cord

(Mains lead)

For customers in the USA,

Canada

For customers in countries/regions

other than the USA and Canada

Power/Charge lamp

Lit: Charging

Off: Charging finished

Flash: Charging error

• When the Power/Charge lamp on the camera does not lit even if the AC Adaptor is

connected to the camera and the wall outlet (wall socket), it indicates that the

charging stops temporarily on standby. The charging stops and enters the standby

status automatically when the temperature is outside of the recommended

operating temperature. When the temperature gets back within the appropriate

range, the charging resumes. We recommend charging the battery pack in an

ambient temperature of between 10°C to 30°C (50ºF to 86ºF).

• Connect the AC Adaptor (supplied) to the nearest wall outlet (wall socket). If any

malfunctions occur while using the AC Adaptor, disconnect the plug from the wall

outlet (wall socket) immediately to disconnect the power source.

• When charging is finished, disconnect the AC Adaptor from the wall outlet (wall

socket).

• Be sure to use only genuine Sony brand battery packs, multi-use terminal USB

cable (supplied) and AC Adaptor (supplied).

1Connect the camera and the AC Adaptor (supplied),

using the multi-use terminal USB cable (supplied).

2Connect the AC Adaptor to the wall outlet (wall socket).

The Power/Charge lamp lights orange, and charging starts.

• Turn off the camera while charging the battery.

• You can charge the battery pack even when it is partially charged.

• When the Power/Charge lamp flashes and charging is not finished,

remove and re-insert the battery pack.

Notes

Altri manuali per Cyber-shot DSC-WX7

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Sony Macchina fotografica digitale

Sony

Sony Cyber-Shot DSC-HX9 Manuale utente

Sony

Sony DSC-WX5/WX5C Manuale utente

Sony

Sony DSLR-A330L Manuale di installazione e funzionamento

Sony

Sony DSC-T7 - Cyber-shot Digital Still Camera Manuale utente

Sony

Sony DSC-S85 Manuale utente

Sony

Sony a7RIV Guida di riferimento

Sony

Sony DSC-M1 Manuale utente

Sony

Sony SLT-A55V - alpha; Translucent Mirror Technology™... Manuale utente

Sony

Sony DSC-WX220 Manuale utente

Sony

Sony Handycam DCR-SX22E Manuale di istruzioni per l'installazione

Sony

Sony UMC-R10C Manuale utente

Sony

Sony ILCE-5000 Guida di riferimento

Sony

Sony Cyber-shot DSC-WX350 Manuale utente

Sony

Sony Alpha SLT-A37 Manuale utente

Sony

Sony Cyber-shot DSC-QX10 Manuale utente

Sony

Sony DSC-TX66 Manuale utente

Sony

Sony Cyber-shot DSC-WX150 Manuale utente

Sony

Sony DSC S650 - Cyber-shot Digital Camera Manuale utente

Sony

Sony MHS-FS1 Manuale utente

Sony

Sony DSC-T900 Cyber-shot® Manuale utente

Sony

Sony Alpha NEX-6 Manuale utente

Sony

Sony ILCE-6400 Guida di riferimento

Sony

Sony DSC-W120/P Manuale utente

Sony

Sony Alpha SLT-A65 Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Canon

Canon EOS ELAN7 Manuale utente

Nikon

Nikon Coolpix 100 Manuale utente

Samsung

Samsung SCC-C4253 Manuale utente

JVC

JVC GT-HM890 Manuale utente
