Printing still images

with a PictBridge printer

You can easily print images shot with your camera without using a computer by using a

PictBridge-compliant printer.

Using a PictBridge-compliant printer easily prints the index print*.

* An index print function may not be provided depending on a printer.

Connecting to a PictBridge

printer............................................ 2

Printing images ............................ 3

Printing index-images.................. 5

Troubleshooting........................... 9

Warnings and messages........... 10

Connecting to a

PictBridge printer

Mode switch: / /

When the USB connection is set on the

Setup screen, you can connect the camera

mounted in the USB cradle directly to a

printer using the USB cable.

•Using the AC Adaptor is recommended to

prevent the power from turning off partway

through printing.

Preparing the camera

Set theUSB mode on the camera to connect

the camera with a printer.

Before operation

Set the menu to the Setup screen (Operating

Instructions, page 44).

aSelect (Setup 2) with V,

then select [USB Connect]

with B/v/V.

bSelect [PictBridge] with B/v,

then press z.

The USB mode is set.

Connecting the camera to

the printer

Connect the camera to the USB cradle.

Then, connect the (USB) jack on the

USB cradle and the USB jack on the printer

with the USB cable (supplied). Turn on the

camera and the printer.

The camera turns to playback mode

regardless of the mode switch position and

an image in the selected playback folder

appears on the LCD screen.

Control button

Mode switch

Setup 2

Video Out:

Clock Set:

NTSC

File Number:

USB Connect:

PictBridge

Normal

PTP

101

BACK/NEXT VOLUME

10:30AM2004 1 1101-0002

After the connection

is made, the

indicator appears on

the LCD screen.

Printer

When [USB Connect] is not set

to [PictBridge] on the Setup

screen

Even if you turn on the camera, you cannot

use the PictBridge function.

Set [USB Connect] to [PictBridge].

1Press MENU and select [USB Connect],

then press z.

2Select [PictBridge] with v, then press

Printing images

Mode switch: / /

You can select the image and print it. Set up

the camera following the procedure on page

2, and connect the printer.

•You cannot print movies.

•When you print an E-mail image, only the

JPEG image that was recorded at the same time

is printed.

•When an error notification is received from the

connected printer, the indicator flashes for

approximately 5 seconds. Check the connected

printer.

In single-image mode

aDisplay the image you want to

print with b/B.

bPress MENU.

The menu appears.

cSelect (Print) with b/B, then

press z.

dSelect [This image] with v/V,

then press z.

The print setting screen appears.

•Items that the printer does not support are

not displayed.

eSelect [Quantity] with v/V,

select the number of sheets

with b/B.

You can select the number up to 20.

PTP

Normal

PictBridge

USB Connect

Mode switch

Control button

101 2/9

Exit OK

Off

Index

Date

Quantity

fSelect [OK] with V/B, then

press z.

The image is printed.

Do not disconnect the USB cable

while the (USB cable

disconnected prohibited) indicator

appears on the LCD screen.

To cancel printing

Select[Cancel]in step 4or select [Exit] in

step 6.

To print other images

Select the image after step 6, then select

[Print] with v.

To print all the images with the

print (DPOF) mark

Select [DPOF image] in step 4. All the

imageswiththe markareprintedby the

specified number regardless of the

displayed image.

To insert the date and time on

images

Select[Date] instep 5, thenselect the date

format with b/B. You can select from

[Day&Time] or [Date]. When you chose

[Date], the date will be inserted in the order

setin“Settingthedateandtime”(Operating

Instructions, page 17).

This function may not be provided

depending on a printer.

In index (nine-image/

sixteen-image) mode

aPress (Index) to display the

index (nine-image) screen.

Press (Index) twice to display a

sixteen-image index screen.

bPress MENU.

The menu appears.

cSelect (Print) with B, then

press z.

dSelect [Select] with b/B, then

press z.

eSelect the image you want to

print with v/V/b/B, then press

The mark appears on the selected

image.

fRepeat step 5to print other

images.

101 2/9

Exit

Printing

2/3

TONEXT

SELECT

gPress MENU.

The print setting screen appears.

•Items that the printer does not support are

not displayed.

hSelect [Quantity] with v/V,

select the number of sheets

with b/B.

You can select the number up to 20.

The specified quantity of all the

selected images are printed.

iSelect [OK] with V/B, then

press z.

The images are printed.

Do not disconnect the USB cable

while the indicator appears on

the LCD screen.

To cancel printing

Select[Cancel]in step 4or select [Exit] in

step 9.

To print all the images with the

print (DPOF) mark

Select [DPOF image] in step 4. All the

imageswiththe markareprintedby the

specified number regardless of the

displayed image.

To print all the images in the

folder

Select [All In This Folder] in step 4, then

press z.

To insert the date and time on

images

Select[Date] instep 8, thenselect the date

format with b/B. You can select from

[Day&Time] or [Date]. When you chose

[Date], the date will be inserted in the order

setin“Settingthedateandtime”(Operating

Instructions, page 17).

This function may not be provided

depending on a printer.

Printing index-images

Mode switch: / /

You can print some images side-by-side.

We refer to this function as an index print*.

You can also arrange the specified quantity

of the same image side-by-side and print

them as an index image (see “In single-

image mode”), or arrange a set of different

images side-by-side as an index image and

print the specified number of sets (see “In

index mode”).

Set up the camera following the procedure

on page 2, and connect the printer.

* An index print function may not be provided

depending on a printer.

Exit OK

Off

Index

Date

Quantity

Exit

Printing

2/3

Control button

•You cannot print movies.

•When you print an E-mail image, only the

JPEG image that was recorded at the same time

is printed.

•When an error notification is received from the

connected printer, the indicator flashes for

approximately 5 seconds. Check the connected

printer.

In single-image mode

aDisplay the image you want to

print with b/B.

bPress MENU.

The menu appears.

cSelect (Print) with b/B, then

press z.

dSelect [This image] with v/V,

then press z.

The print setting screen appears.

•Items that the printer does not support are

not displayed.

eSelect [Index] with v, then

select [On] with b/B.

fSelect [Quantity] with v/V,

select the number of sheets

laid side-by-side with b/B.

You can select the number up to 20.

You can arrange the specified quantity

of an image side-by-side.

gSelect [OK] with V/B, then

press z.

The image is printed.

Do not disconnect the USB cable

while the (USB cable

disconnected prohibited) indicator

appears on the LCD screen.

To cancel printing

Select [Cancel] in step 4or select [Exit] in

step 7.

To print other images

Select the image after step 7. Select

[Print] with v, then repeat from step 4.

To print all the images with the

print (DPOF) mark

Select [DPOF image] in step 4. All the

imageswiththe mark are printed by the

specified number regardless of the

displayed image.

101 2/9

Exit OK

Off

Index

Date

Quantity

Exit

Printing Index

1/1

To insert the date and time on

images

Select [Date] in step 6, then select the date

format with b/B. You can select from

[Day&Time] or [Date]. When you chose

[Date], the date will be inserted in the order

set in “Setting the date and time” (Operating

Instructions, page 17).

This function may not be provided

depending on a printer.

•The designated number of images may not all

fit onto a single sheet depending on the quantity

of images.

In index (nine-image/

sixteen-image) mode

aPress (Index) to display the

index (nine-image) screen.

Press (Index) twice to display a

sixteen-image index screen.

bPress MENU.

The menu appears.

cSelect (Print) with B, then

press z.

dSelect [Select] with b/B, then

press z.

eSelect the desired image with

v/V/b/B, then press z.

The mark appears on the selected

image.

fRepeat step 5to print other

images.

gPress MENU.

hSelect [Index] with v, then

select [On] with b/B.

iSelect [Quantity] with v/V,

select the number of sets you

want to print with b/B.

You can select the number up to 20.

jSelect [OK] with V/B, then

press z.

The image is printed.

Do not disconnect the USB cable

while the indicator appears on

the LCD screen.

To cancel printing

Select [Cancel] in step 4or select [Exit] in

step 0.

To print all the images with the

print (DPOF) mark

Select [DPOF image] in step 4. All the

imageswiththe mark are printed by the

specified number regardless of the

displayed image.

•TONEXTSELECT

Exit

Printing Index

1/1

To print all the images in the

folder

Select [All In This Folder] in step 4, then

press z.

To insert the date and time on

images

Select [Date] in step 9, then select the date

format with b/B. You can select from

[Day&Time] or [Date]. When you chose

[Date], the date will be inserted in the order

set in “Setting the date and time” (Operating

Instructions, page 17).

This function may not be provided

depending on a printer.

Troubleshooting

Symptom Cause Solution

You cannot connect with

the printer. • The printer does not conform to the PictBridge

standard.

• The printer condition does not allow connection.

• [USB Connect] is not set to [PictBridge] on the

Setup screen.

• Depending on the circumstances, the connection

may not be established.

pContact the manufacturer regarding whether the printer

conforms to the PictBridge standard.

pTurn on the printer and check that it is in a condition that allows

connection.

pSet it to [PictBridge].

pDisconnect and connect the USB cable again. If an error

message is indicated on the printer, refer to the operating

instructions supplied with the printer.

You cannot print. • The printer is not connected.

• The printer is not turned on.

• If you select [Exit] during printing, you may not

print again depending on your printer.

• You cannot print movies.

• You may be unable to print some still images

recorded using a model other than this camera or

images that have been processed by a computer.

pCheck that the camera and the printer are connected correctly

using a USB cable.

pTurn on the printer. See the operating instructions of the printer

for details.

pDisconnect and connect the USB cable again. If you cannot

print still, disconnect the USB cable, turn off and on the printer,

then connect the USB cable again.

—

Printing stops partway. • You disconnected the USB cable before the

indicator disappeared. —

Date/time insertion and

index print are not

possible.

• The printer does not support date/time insertion

and index print.

• Some printers cannot insert the date/time with

index print.

pContact the manufacturer regarding whether the printer

supports date/time insertion and index print.

pContact the printer manufacturer.

“---- -- --” is printed in the

date/time portion. • The image file does not contain printable

recording date/time data.

pYou cannot perform date/time printing for image files that do

not contain printable recording date/time data. Set [Date] to

[Off] and then print the image.

Warnings and

messages

The following messages may appear on the LCD screen.

Message Meaning/Corrective Action

Connect to device • You attempted to print before connecting a printer. Connect the PictBridge compliant printer.

Enable printer to connect • The camera is set to [PictBridge], but it is connected to a device that does not support PictBridge. Check the

connected device.

• Depending on the circumstances, the connection may not be established. Disconnect and connect the USB cable

again. If an error message is indicated on the printer, refer to the operating instructions supplied with the printer.

Printer busy • The connected printer is currently printing or otherwise cannot accept print requests. Check the connected printer.

Paper error • The connected printer is out of paper, the paper has jammed, or some other paper error has occurred. Check the

connected printer.

Ink error • The connected printer has some ink error. Check the connected printer.

Printer error • The camera has received an error notification from the printer. Check the connected printer, or check whether the

images to be printed have been damaged.

No printable image • You attempted to execute [DPOF image] without making print marks.

• You attempted to execute [All In This Folder] for a folder that contains only movies. You cannot print movies.

• The data transmission to the printer may not be completed yet. Do not disconnect the USB cable.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Sony Macchina fotografica digitale

Sony

Sony ProMavica MVC-A7AF Manuale utente

Sony

Sony DSC-W220/L Manuale utente

Sony

Sony ILCE-1 Guida di riferimento

Sony

Sony Cyber-shot DSC-U50 Manuale utente

Sony

Sony Cyber-shot DSC-RX100 Manuale utente

Sony

Sony a7 III Manuale utente

Sony

Sony DSC-TX7 - Cyber-shot Digital Still Camera Manuale utente

Sony

Sony SLT-A57 &alpha Manuale utente

Sony

Sony DSC-TX66 Manuale utente

Sony

Sony DSLR-A200 - alpha; Digital Single Lens Reflex... Manuale d'uso e manutenzione

Sony

Sony Cyber-Shot DSC-H1 Istruzioni operative

Sony

Sony Cyber-shot DSC-W80 Manuale utente

Sony

Sony Cyber-shot DSC-T5 Istruzioni operative

Sony

Sony Handycam DCR-SR32E Manuale utente

Sony

Sony DSC-T2/P Cyber-shot® Manuale utente

Sony

Sony A6100 Manuale utente

Sony

Sony Cyber-shot DSC-S600 Manuale utente

Sony

Sony Cyber-shot DSC-W100 Manuale utente

Sony

Sony MVC-CD350 - Digital Still Camera Mavica Cd... Manuale utente

Sony

Sony ILCE-3500 Manuale utente

Sony

Sony DSC-H55 - Cyber-shot Digital Still Camera Manuale utente

Sony

Sony DSC-WX200 Manuale di istruzioni per l'installazione

Sony

Sony Cyber-shot DSC-P1 Manuale utente

Sony

Sony Cyber-shot DSC-S3000 Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Canon

Canon EOS ELAN7 Manuale utente

Nikon

Nikon Coolpix 100 Manuale utente

Samsung

Samsung SCC-C4253 Manuale utente

JVC

JVC GT-HM890 Manuale utente
