Sony VPL-FE110U Manuale utente
US/CND
AEP/E
PROTOCOL MANUAL
MODEL ..........
VPL-FE110U
VPL-FE110M
LCD DATAPROJECTOR
.............. DEST.
VERSION 1.0
Projector Firmware ARC32
COPYRIGHT NOTICE
Copyright © by Sony Corporation.
All rights reserved. The copyright on all matters
described in this manual belongs to Sony Corporation,
and the contents are intended for use by purchasers of
subject equipment.
Furthermore, Sony Corporation reserves the right to
revise this publication and to make changes from time to
time in the content hereof without obligation of Sony
Corporation to notify any person or organization of such
revision or changes.
1
VPL-FE110U/FE110M
TABLE OF CONTENTS
1. INTRODUCTION ..........................................................................1
2. COMMUNICATION SPECIFICATIONS .......................................2
2-1. RS-232C COMMUNICATION SIGNAL......................................................... 2
2-2. RS-422A COMMUNICATION SIGNAL ........................................................ 2
2-3. PJ COM COMMUNICATION SIGNAL.......................................................... 2
3. COMMAND BLOCK FORMAT ...................................................3
4. DATA OF CODE .........................................................................4
5. BASIC OPERATIONS.................................................................6
5-1. COMMON OPERATIONS OF RS-232C/422A............................................... 6
5-2. PJ COM OPERATIONS ................................................................................... 6
5-3. BASIC OPERATIONS ..................................................................................... 6
6. CONNECTION.............................................................................7
6-1. RS-232C CONNECTION ................................................................................. 7
6-2. RS-422A CONNECTION ................................................................................. 7
6-3. PJ COM CONNECTION .................................................................................. 8
6-4. CONNECTION EXAMPLE ............................................................................. 8
7. COMMUNICATION PROCEDURE .............................................9
8. COMMUNICATION RULES ......................................................10
9. APPROXIMATE RETURN WAITING TIMES............................11
10. COMMANDS .............................................................................13
1
VPL-FE110U/FE110M
1. INTRODUCTION
This protocol manual describes the basic configuration and basic operations of various commands used
for projector. Projector can be controlled using the commands in the List of Commands provided in
Section 10 “COMMANDS”. Using an external CONTROLLER or SWITCHER, etc., inputs can be
switched and the power can also be turned on and off. In the following paragraphs, “CONTROLLER”
means an external device such as a PC which controls projector using these commands.
2VPL-FE110U/FE110M
2. COMMUNICATION SPECIFICATIONS
2-1. RS-232C COMMUNICATION SIGNAL
.Full duplex communication channels (Flow control not performed.)
.Start-stop synchronism system
.Baud rate: 38.4 k (bits per second) fixed.
.The bit configuration is defined as follows.
.RS-422A and PJ COM have the same bit configuration.
1 START Bit +8 DATA Bits +1 PARITY Bit +1 STOP Bit
D4 D5 D6 D7
(MSB)(LSB) (EVEN) BIT
PARITY STOP
BIT
START D3D2D1D0
EVEN Parity.....Total number of “1”s from D0 to D7 is an even number.
2-2. RS-422A COMMUNICATION SIGNAL
.Full duplex (4-wire) communication channels
.Start-stop synchronism system bit serial word serial digital signal
.Baud rate: 38.4 k bps (bits per second) fixed.
.Refer to “2-1. RS-232C Communication Signal”for details on the bit configuration.
2-3. PJ COM COMMUNICATION SIGNAL
.Half duplex (4-wire) PROJECTOR dedicated communication channels
.Start/stop system bit serial word serial digital signal
.Baud rate: 38.4 k, 19.2k, 9600 bps (bits per second).
.Refer to “2-1. RS-232C Communication Signal”for details on the bit configuration.
3
VPL-FE110U/FE110M
3. COMMAND BLOCK FORMAT
The code from B0 to B (m +2) as described below is/are transmitted.
1
B0
Start Code
2
RECEIVER (To) Index
9
B (m +1)
Check SUM
0
B (m +2)
End Code
B1
Peripheral Index B2 B3 B4 B5
3
SENDER (From) Index
B6
Peripheral Index B7 B8 B9 B10
67
Data Length
Total Data Length
B15 *128 +B16
Data Length 2
(B15 *128) Data Length 3
(00 — 7 Fh)
4
COMMAND
B11
Cmd1 B12
Cmd2 B13
Cmd3
B15 B16
8
Data
Bn
Data (n) Bm
Data (n +1,2,3,4...) Bn = B (16 +1)
Bm = B (16 +Total Data Length)
5
Check Data Length
Data Length 1
(B16 +2)
(02 — 81 h)
B14
Group Index Device Index
Group Index Device Index
4VPL-FE110U/FE110M
4. DATA OF CODE
1Start Condition
2INDEX Header
/*–RECEIVER INDEX –*/
/*–SENDER INDEX –*/
/*–Command –*/
Note : CMD1 and CMD2 are assigned with different commands for each unit. Consequently,
there is no compatibility of commands between units. For details of the commands,
refer to the respective list of commands for the units.
3Sub Data Size
Note : Error when 00,01 and 82 to FF hex codes are included.
4Data Size
Note : Error when 11 to FF hex codes are included.
Bn
B0 NAME
Start Code DATA
A5 NOTE
Indicates the first packet
B6
B7
B8
B9
B10
PERIPHERAL INDEX
GROUP INDEX UPPER BYTE
GROUP INDEX LOWER BYTE
DEVICE INDEX UPPER BYTE
DEVICE INDEX LOWER BYTE
01 –03
00
01 –63
00
01 –63
01 : Projector, 02 : Switcher, 03 : Controller
Group Index = 0001 –0063 hex
Device Index = 0001 –0063 hex
B14 Data Length 1 02 –81 (B16 +2 hex) Data Size
B15 Data Length 2 00 –10 (B15 *80 hex) Data Size
B1
B2
B3
B4
B5
PERIPHERAL INDEX
GROUP INDEX UPPER BYTE
GROUP INDEX LOWER BYTE
DEVICE INDEX UPPER BYTE
DEVICE INDEX LOWER BYTE
00 –03
00
00 –63
00
00 –63
01 : All, 01 : Projector, 02 : Switcher, 03 : Controller
Group Index = 0000 –0063 hex (0000 hex : All)
Device Index = 0000 –0063 hex (0000 hex : All)
Receiving Device
Peripheral INDEX = 01
Projector All
CRT Projector (10 CRT All)
LCD Projector (80 LCD All)
DMD Projector(B0 DMD All)
Receiving Device
Peripheral INDEX = 02
Switcher All
10 : PC-3000
B11
B12
B13
CMD1
CMD2
CMD3
00
10 –7F
80 –AF
B0 –FF
Refer to attached
Refer to attached
5
VPL-FE110U/FE110M
5Data Size
Bn~Bm Data XX Indicates the last packet
Note : Error when 80 to FF hex codes are included.
Calculate the actual 6Data length using the following method.
Calculate the Total Data Length using the B15 and B16 Data.
<Example>
If B15 = 02 h and B16 = 7 Fh, calculate the Total Data Size as follows.
Data Length indicated by B15.
2 *128 = 256 Byte
Data Length indicated by B16.
127 Byte
The Data Length indicated by Total is ;
(B15) 256 Byte +B (16) 127 Byte = 383 Byte.
6Data
Bn = B (16 +1)
Bm = B (16 +Total Data Length)
7Check SUM
XOR is the exclusive OR.
It is as follows when calculated by 1 bit.
Taking A XOR B = C ;
ABC
000
101
011
110
<Example of Calculation>
When 0XA5 (165) and 0XA5 (165) are calculated by XOR ;
A5 10100101 (165)
A5 10100101 (165)
Answer 00000000 (0)
When 0XA5 (165) and 0X5A (90) are calculated by XOR ;
Answer
A5 10100101 (165)
5A 01011010 (90)
Answer 11111111 (255)
8End Condition
B (m +1)
Check Sum XX Checksum of Data from 2to 6
(Calculate the XOR of the Data from 2to 6.)
B (m +2)
END Code 5A No Data in some cases
B16 Data Length 3 00 –7F Data Size of 6–(B15 * 80 hex)
6VPL-FE110U/FE110M
5. BASIC OPERATIONS
5-1. COMMON OPERATIONS OF RS-232C/422A
RS-232C and RS-422A use the same port. Transmission and reception are performed only for the TX line
and RX line in the case of softwares using the same commands (based on the software conditions).
Handshaking normally established by RS-232C is therefore not performed.
5-2. PJ COM OPERATIONS
PJ COM is a port specially developed for projector based on RS-485. It therefore has no compatibility
with the commercially available RS-485. (Special uses only)
PJ COM is a half duplex communication composed of the data line and control line. The control line is
normally called as busy line, indicating whether the PJ COM line is available for use. Transmission is
performed only when this line is free. If in use, data is transmitted to the Data line.
5-3. BASIC OPERATIONS
Transmission and reception by RS-232C/422A and PJ COM are performed using the same protocols. The
data received by RS-232C/422A is input to the unit once to confirm that there are no errors in the data,
and it is then transmitted to PJ COM again. Basic operations at PJ COM are the same. The data input to
the unit once is checked that there are no errors, and is transmitted to RS-232C/422A again. The unit
serves as a communication bridge.
