Sony SRF-DR2000 Manuale utente

FM Data Receiver

1998 by Sony Corporation

SRF-DR2000

Operating instructions see 2-GB

Mode d’emploi voir 2-FR

Bedienungsanleitung seite 2-DE

Gebruiksaanwijzing zie 2-NL

Istruzioni per l’uso vedere 2-IT

3-864-117-12 (1)

2-GB

General Information

FOR YOUR RECORDS

For your assistance in reporting this unit in case of loss or

theft, please record below the model number and serial

number which are located on the back of the unit.

Please retain this information.

Model number

Serial number

Your ID number

Date of purchase

Place of purchase

Digital DJ System E2 is a registered

trademark of Digital DJ Inc.

3-GB

Table of Contents

Before You Begin ........................................................................... 4

Features .......................................................................................... 4

Getting Started

Installing the Batteries ................................................................. 5

Selecting a Language.................................................................... 7

Operating the Radio

Manual Tuning .............................................................................. 9

Presetting Stations ...................................................................... 10

Seeing FM data

Seeing the Information on Your Receiver ............................... 12

Saving Information That You Can See..................................... 17

Deleting the Information that Has Been Saved ...................... 19

Setting the Functions.................................................................. 20

Additional Information

ID Numbers ................................................................................. 23

Using the Stand ........................................................................... 27

Specifications............................................................................... 27

Precautions .................................................................................. 28

Troubleshooting .......................................................................... 29

Index to Parts and Controls ...................................................... 30

Index ............................................................................................. 32

4-GB

Before You Begin

Thank you for choosing the Sony FM data receiver!

The FM data receiver will give you many hours of listening

pleasure and will display up-to-date information.

Before operating the FM data receiver, please read these

instructions thoroughly and retain them for future reference.

Features

•FM stereo radio

•High-speed data receiver which can receive text and

graphics.

•Five Function buttons for user-friendly operations and

intuitive information-receiving operations.

•Urgent message information is displayed automatically

during the FM multiplex broadcast mode only.

•You can set the unit to automatically turn off the power

approximately after 120 minutes, (Auto Power OFF

function).

•You can choose from 7 languages (English, French, German,

Italian, Spanish, Dutch, Swedish) for the indications in the

display only.

About FM multiplex broadcast

FM multiplex broadcast provides text and graphic data

through the open signal space in the frequency of the

normal radio broadcasts. It is transmitted by specific FM

broadcasting stations and the information cannot be

received using an ordinary radio.

5-GB

”Getting Started

Installing the Batteries

Open the battery compartment lid and insert two R6 (size AA)

batteries (not supplied) with the correct polarity.

Battery Life (Approx. hours)

Sony Alkaline LR6(SG) Sony R6(SR)

Audio only 35 14

FM multiplex reception 23 9

* For maximum performance we recommend that you use alkaline

batteries.

When to Replace the Batteries

Replace the batteries when “LOW BATTERY” is displayed.

Notes

• Insert the batteries with correct polarity.

• The dry batteries cannot be charged.

• Turn off the radio, and then replace the batteries within 20

seconds after the batteries are removed from the battery

compartment. Otherwise, the information that has been saved

and the preset stations will be erased. In this case, preset the

stations again. Be sure to take note of your important data that is

saved in the memory.

• When you are not going to use your unit for an extended period

of time, remove the batteries to prevent possible damage from

battery leakage and corrosion.

DC IN 3V

R6 (size AA) ×2

Getting Started

6-GB

Using External Power Sources

You can connect the following external power sources through

the DC IN 3 V jack located on the left side of the unit. (When

you plug a cord into the DC IN 3 V jack, the internal batteries

are automatically bypassed.)

•House current using a Sony AC-E30HG (not supplied) AC

power adaptor

•12/24 V car battery using a Sony DCC-E230 (not supplied)

car battery cord

Notes

• When operating the unit with an external power source, do not

remove the batteries in the battery compartment which serve as a

backup of the memory.

• Use only the recommended AC power adaptor or car battery cord

manufactured by Sony. The polarity of the plugs of other

manufacturers may be different.

Polarity of the plug

When the radio turns off unexpectedly

When you set the Auto Power OFF function to ON, the radio

turns off automatically approximately after 120 minutes to

prevent unnecessary wear of the batteries. To listen to the

radio continuously, press POWER.

If the radio does not turn on after pressing POWER, or if the

radio turns off unrelated to the Auto Power OFF feature, the

batteries are exhausted.

Replace both batteries with new ones.

To set this function see “To set the Auto Power OFF” (page 21)

under “Setting the Functions” (page 20).

7-GB

Selecting a Language

You can select one of the seven languages (English, French,

German, Italian, Spanish, Dutch, Swedish) for the indications

in the display. The explanation here is when the language is set

in English, and the explanation of the indications in the display

will be in English.

1While holding down ENTER press POWER to turn on

the unit. The LANGUAGE SELECT MENU appears.

2Press the corresponding Function button to ↑UP or

↓DWN to move the cursor to the language you want,

and press the Function button corresponding to ENT.

The indications in the display will switch over to the

selected language.

POWER

ENTER

Function buttons

5:Spanish

ENT

vDWN

4:Italian

3:German

2:French

1:English

LANGUAGE SELECT MENU

Getting Started

8-GB

To change the selected language

Press POWER to turn off the unit and repeat from step 1.

Notes

• The selected language does not translate the FM data. Only the

indications in the display will switch over to the selected

language, and the FM data will be displayed in the language of

that area.

• The three display windows shown below will be displayed in

English, even when you set the language other than English.

(see page 7)

(see page 13)

5:Spanish

ENT

vDWN

4:Italian

3:German

2:French

1:English

LANGUAGE SELECT MENU

PAGE:Last Page

H-PAGE

MSG

PAGE

MSG:Last Message

H-PAGE:Station Menu

Stored Data.

Retrieving

Choices for

M2:Free Programs

Downloads.

Data While Receiver

To Retrieve Stored

9-GB

1Connect the stereo headphones to the 2jack.

2Press POWER to turn on the unit.

3Press TUNE +/– to manually tune in to the desired

station.

If you press and hold TUNE +/–, the frequency is scanned

rapidly. Release the button to stop scanning.

4Adjust the volume with VOLUME.

To turn off the unit

Press POWER.

Manual Tuning

”Operating the Radio

POWER

TUNE +/–

VOLUME

NEWS•MUSIC

ENTER

Function

buttons

Operating the Radio

10-GB

Presetting Stations

The unit is initially preset with 5 FM radio stations. You can

preset up to 5 of your favorite stations.

1Press POWER to turn on the unit.

2Press TUNE +/– to manually tune in to the desired

station.

3Press ENTER.

When “PRESET” flashes in the display, press one of the

Function buttons to preset the station.

The beep sounds twice through the headphones and your

favorite station is preset to the desired Function button.

To change an existing preset station

Repeat from step 1 and press the desired Function button you

wish to change on step 3.

The existing preset station of the selected Function button will

be erased and replaced with your new favorite station.

97.5

87.5

MHz

92.0 98.0

108.0104.3

PRESET

97.5

MHz

92.0 98.0

108.0104.3

PRESET
