Sound Sation GN230 Manuale utente

GN230 I N S TA L L G O O S E N E C K M I C R O P H O N E

www.soundsationmusic.com

SOUNDSATION GN230 - installation condenser

microphone features：

Back-electred capsule with hyper-cardioid directivity for

max isolation of source voice from ambience.

High sensitivity

Double gooseneck construction for flexible positioning

Application: conference, broadcasting, public address,

communication, home recording.

Specifications:

Transducer Principle: Electrostatic Condenser

Directivity Characteristic: Hypercardioid

Frequency Response: 50Hz-16 kHz

Sensitivity: -45dB±3dB (0dB=1V/Pa at 1 kHz)

Output Impedance: 200Ω±30% (at 1 kHz)

Power Requirements: 9-52V DC Phantom Power

Length: 505mm

Frequency Response Graph:

HOW TO BEST USE THE MICROPHONE

1. Connect the microphone directly with the XLR Cable:

swivel the cable’s XLR and make sure it rightly fits

XLR connector of the microphone, then press the

cable’s XLR into the microphone. If the microphone

works with the base, please plug the microphone into

the base first, and then connect the base with the XLR

Cable.

2. Please put on the assorted windscreen while using the

microphone, for it can help protect both the microphone

and capsule from damage and reduce the wind noise

and sound feedback effectively. Keep the windscreen

free from dust, which may influence the frequency

response of the microphone. Please wash the

windscreen timely, and make sure it is completely dry

before use.

3. If the head of the microphone is covered by hand or

brought close to the speaker, a howling sound may be

generated. To prevent this, first decrease the volume,

then replace the microphone so that it is not pointed to

the speaker and make sure there is a sufficient

distance between the microphone and speaker.

4. Due to the high sensitivity of the cartridge, do not drop

it from high or apply strong shock to it.

5. To maintain the sensitivity and quality of sound

reproducing, avoid exposing it to moisture and extreme

temperatures.

MADE IN CHINA
