Soundstream Reference R1 Manuale

Woofer & Enclosure

Information

Congratulations on your new Soundstream sub-woofer purchase. We

greatly appreciate your business. This may look like is a run of the mill

cardboard box, but is actually a protective barrier over one of the finest

engineered and assembled subwoofer available.

Harmonic Indulgence… Listen and Feel

series wired R1-12L R1-15L

Fs 21.50 23.7

Qms 9.210 13.4

Vas (ft^3) 2.863 4.825

Cms (mm/N) .220 .14

Mms (g) 249.5 317.2

Rms (kg/s) 3.654 3.52

Xmax (mm) 12.70 12.7

Sd (in^2) 79.16 127.7

Qes .490 .65

Re 6.80 6.80

Z88

BL (Telsa) 21.60 22.16

RMS Power 800 900

Qts .418 .620

1w/1m SPL 84.15 86.40

Depth 7.50 8.750

Cutout Dia. 11.125 14.250

Voice Coil 3” DVC 4Ω3” DVC 4Ω

Reference R1-12 Sealed Reference R1-15 Sealed

Vol. Qtc F3 Vol. Qtc F3

Min 1 .690 43 1.5 .870 41

Opt 1.5 .610 41 2 .800 39

Max 2 .570 40 2.5 .750 37

Soundstream does not provide enclosure dimensions as there are

infinite variables when designing a box, i.e. vehicle, amplifier, music

preferences, etc… For designs tailored to your specific needs, please

contact us at tech-suppor[email protected]

All enclosures should be made of .75” (3/4”) material only. When

possible, make the baffle 1.5” (1 ½) thick and add .75” (3/4”) to the

depth of the enclosure to compensate. All volumes INCLUDE

vent/port and subwoofer displacements. DO NOT change the volume

unless you plan on adding a substantial amount of bracing. For added

performance, applying a coat of fiberglass resin to the interior walls

will greatly improve sealing the enclosure. Adding a thin layer of poly-

fill will improve response by smoothing out reflections within the

enclosure

2428(2) 4x16.552531(2) 4x17.54

Max

2732(2) 4x15.542632(2) 3x113

Opt

3034(2) 3x9.5329344x14.52

Min

F3FBPortVol.F3FBPortVol.

Reference R1-15 PortedReference R1-12 Ported
