Sper scientific 800108 Manuale utente

IR/Thermistor Pen

800108

Instruction Manual

- 2 -

IR/Thermistor Pen 800108

Printed in the USA

7720 E. Redfield Rd. Suite #7,

Scottsdale, AZ 85260

Tel: (480) 948-4448 Fax: (480) 967-8736

Web: www.sperscientific.com

The contents of this manual may not be

reproduced or transmitted in any form or

by any means electronic, mechanical, or

other means that do not yet exist or may

be developed, including photocopying,

recording, or any information storage

and retrieval system without the express

permission from Sper Scientific.

- 3 -

TABLE OF CONTENTS

INTRODUCTION. . . . . . . . .

FEATURES . . . . . . . . . . . . .

METER COMPONENTS . . .

MEASUREMENT

PROCEDURES. . . . . . . . . .

BATTERY REPLACEMENT .

SPECIFICATIONS . . . . . . . .

WARRANTY . . . . . . . . . . . . .

- 4 -

The Sper Scientific IR/

Thermistor Pen (Model 800108)

functions as a thermistor

thermometer and a non-contact

IR (Infrared) thermometer.

The IR thermometer takes non-

contact readings of surfaces and

the thermistor probe is used to

penetrate and measure solids

and liquids.

IR thermometers are used to

safely measure the temperature

in inaccessible, hot or

hazardous objects in electrical,

hazmat, HVAC, and other fields.

IR thermometers are also used

in moving machinery in

factories, automobiles and

elsewhere. Other uses include

electrical troubleshooting HVAC

energy audits and avoiding

contamination in the food,

beverage and pharmaceutical

industries.

INTRODUCTION

- 5 -

 Dual function as thermistor

and IR thermometer

 5.3” rotatable probe

 Maximum and minimum

Memory

 Hold function

 Auto-power-off

 Backlight

FEATURES

- 6 -

Rotating Probe

The thermistor thermometer

includes a built-in 5.3” rotating

probe. To rotate the probe:

1. Hold the probe tip and swing

it away from the meter until

the probe locks at a 90°

angle from the meter.

2. From the 90° postion, pull

upward until the probe locks

at 180° angle from the meter

(the probe is now fully

extended).

3. While pressing the release

button on the swivel knob,

hold the probe tip and push

the probe back toward the

meter.

METER COMPONENTS

- 7 -

MEASUREMENT

PROCEDURES

The Sper Scientific IR/Thermistor

Pen (Model 800108) functions as

two thermometers with

independent displays and battery

power. The following

measurement procedures are

divided into two sections:

Thermistor Thermometer and IR

Thermometer.

THERMISTOR THERMOMETER

Turning the Unit On/Off

1. Press ON/OFF for 1 second.

The meter will turn on and

begin taking readings.

2. Press ON/OFF for 3 seconds

to turn the meter off.

Backlight

Press for 1 second. The LCD

backlight will activate for 10

seconds.

- 8 -

MEASUREMENT

PROCEDURES

Hold/Maximum/Minimum

1. Press HOLD/MAX/MIN

button for 1 second to enter

HOLD display function. The

current reading will freeze on

the display.

2. Press HOLD/MAX/MIN

button again to view the

maximum value of the

readings taken since the

thermometer was turned on.

If a new maximum is reached

while viewing, the new

maximum value will display

on the LCD.

3. Press HOLD/MAX/MIN

button again to view the

minimum value of the

readings taken since the

thermometer was turned on.

If a new minimum is reached

while viewing, the new

minimum value will display

on the LCD.

- 9 -

4. The meter cycles from Hold

→Max →Min →Hold.

Press HOLD briefly to return

to Hold Mode.

Note…

The minimum, maximum and

hold values will not be saved

when the meter returns to

Normal Mode or when the meter

is turned off.

Clear Memory

1. Press CLEAR for 3 seconds

to delete all memory. “- - - -”

will appear on the LCD.

2. Wait 3 seconds and the

meter will automatically

return to Normal Mode.

MEASUREMENT

PROCEDURES

- 10 -

MEASUREMENT

PROCEDURES

Temperature Units

To select either Celsius or

Fahrenheit temperature scale gently

insert the end of a paperclip into the

pick hole on the back.

Auto Power Off

To save battery life, the meter will

automatically turn off after 10

minutes of inactivity when the auto

power off function is enabled.

1. The clock symbol appears

on the LCD to indicate that auto

power off is enabled.

2. Press HOLD and ON/OFF

buttons simultaneously to

enable/disable the auto power

off function.

IR THERMOMETER

1. Aim thermometer at the target.

2. Press the IR Button to view the

surface temperature. The

measurement is constantly
