Spirit SP-POS588 Manuale utente

SP－POS588 Thermal

Printer

User’s Manual

（VER1.01）

Beijing Spirit Technology Development Co, Ltd.

www.sprt-printer.com

SPRT

Content

Content........................................................................................................................................................１

Introduction.................................................................................................................................................１

Chapter 1 Characteristic and Specification.......................................................................................... ２

1.1 Printing specification.......................................................................................................................... ２

1.2 Printing Paper......................................................................................................................................２

1.3 Printing Font........................................................................................................................................ ２

1.4 Interface............................................................................................................................................... ２

1.5 Printing Control Command................................................................................................................３

1.6 Power Supply...................................................................................................................................... ３

1.7 Operation Environment......................................................................................................................３

1.8 Outline Dimension.............................................................................................................................. ３

Chapter 2 Installation and Operation.....................................................................................................４

2.1 Printer Appearance.............................................................................................................................４

2.2 Paper Installation................................................................................................................................５

2.3 Model.................................................................................................................................................... ６

2.4 Interface Connection..........................................................................................................................６

2.4.1 USB Interface Connection............................................................................................................. ６

2.4.2 Bluetooth Interface Connection.................................................................................................... ６

2.4.3 Wifi Interface Connection...............................................................................................................７

2.4.4Power Connection............................................................................................................................８

2.5 Buttons and Indicators.......................................................................................................................８

2.5.1 Power switch....................................................................................................................................８

2.5.2 Feed Button......................................................................................................................................８

2.5.3 Opening Upper Cover Button........................................................................................................８

2.5.4 Power indicator light (green)......................................................................................................... ８

2.5.5 Error indicator light (red)................................................................................................................ ８

2.5.6 Connection indicator light (blue)...................................................................................................９

2.5.7 Speaker.............................................................................................................................................９

2.6 Self-test................................................................................................................................................ ９

2.7 Hexadecimal Dump............................................................................................................................９

2.8 Upgrade Mode................................................................................................................................ １０

Chapter 3 Printing Driver Installation.................................................................................................１０

Appendix 1 Performance Index.......................................................................................................... １１

SPRT

１

Introduction

SP- POS588 printer is a new type line thermal printer, it features in fast

speed print, low print noise, high reliability, perfect print quality and ribbon

needless avoiding the vexation of regular maintenance.

SP-POS588 printer: small in outline dimension, simple operation, and

extensive application, especially suitable for commercial cash register,

PC-POS, bank POS and all kinds of receipts print.

SPRT

２

Chapter 1 Characteristic and Specification

1.1 Printing specification

●Printing method: direct thermal

●Printing paper width: 57.5±0.5mm

●Printing density: 8 dots/mm, 384 dots/line

●Printing speed: approx. 80mm/s (max) ( 25% printing density)

●Reliability:

Printing head life: 50km

Using condition:

＊Print 12 × 24 ASCII characters, print 50 lines each time, intermittent

print repeatedly

＊Each dot-line printing at the same time should not exceed 25%, each

character-line and one dot vertically printing repeatedly should

not exceed 11 times

＊Use specified thermal paper

●Valid printing width: 48mm

1.2 Printing Paper

● Paper Type: thermal paper 57.5xΦ80 mm（MAX）

● Paper Thickness －－－－－－ 0.06-0.08mm

● Paper Loading: Easy Paper Loading

● Paper Cutting: Manual Paper Cutting

1.3 Printing Font

● ANK Character set:

12×24 dots，1.5（W）×3.00（H）mm;

● GB2312-80(Chinese):

24×24 dots，3.00（W）×3.00（H）mm.

1.4 Interface

● USB interface:

Standard B type USB interface.

● Bluetooth interface

● WIFI interface

SPRT

３

1.5 Printing Control Command

● Character print command: supports double width and double height

printing of ANK characters, user-defined characters and Chinese

characters, the character line spacing is adjustable.

● Graphics print command: supports the printing of bit map graphics with

different density

● GS bar code print command:

1D barcode: supports UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF25,

CODABAR, CODE93, CODE128 barcode print.

2D barcode: supports PDF417, QRCODE, DataMatrix barcode print.

1.6 Power Supply

● DC8.5V±5％，3A(three core)

1.7 Operation Environment

● Operation environment temperature: 0～50℃

Relative humidity: 10～80％

● Storage temperature: -20～60℃

Relative humidity: 10～90%

1.8 Outline Dimension

● Dimension: 143(L) X 103 (W) X103(H) mm

● Weight: 410g (not including paper)

SPRT

４

Chapter 2 Installation and Operation

2.1 Printer Appearance

Figture 2-1-1 printer outer appereance

SPRT

５

Figture 2-1-2 printer outer appereance(back view)

2.2 Paper Installation

SP-POS588 adopts 58mm width thermal paper.

The steps of thermal paper installation are as the following:

1. When there is no paper in the print head, pls don’t press【FEED】button

to avoid affecting the life of printing head. Press the cover-opening clasp

down to open the paper compartment cover to change the paper.

2. After paper case cover is closed, pls do not draw the paper forwards or

backwards with hands.

SPRT

６

2.3 Model

Model

Description

SP-POS588BTDMVTd

USB+Bluetooth+Voice Warning

SP-POS588WVTd

USB+WiFi+Voice Warning

2.4 Interface Connection

2.4.1 USB Interface Connection

The standard configuration of the printer is equipped with a standard USB

TO Type-C cable, which is used to connect the printer and the host device.

The printer's USB belongs to the type of slave device (DEVICE); the

appearance and pin definitions are shown in the figure below:

Fig2-4-1. Pin Order of the Type C Port

2.4.2 Bluetooth Interface Connection

The handheld terminal, notebook or other terminals with Bluetooth can

drive the printer through Bluetooth interface. POS588 printer can support

Bluetooth2.0/Bluetooth4.0 principles. Power rate is CLASS2, Valid distance

is 10m. Device name is POS58BT Printer, initial password is “1234”. Device

name and password can also be set and changed by “Setting Tool”.

Before printing, POS588 printer needs to pair with the host firstly. The

pairing process is as below:

1. Turn on the printer

2. The host searches the Bluetooth devices

SPRT

７

3. If several Bluetooth devices are found, pls choose POS58BT Printer.

4. Input password “1234”.

5. Complete pairing.

Please refer to the Bluetooth function description of the master device for

the specific pairing method.

During pairing, the printer must be on.

Note: If the device name is not changed, during pairing, pls do not turn on

several printers at the same time. Otherwise, it will be difficult to identify the

one printer paired.

2.4.3 Wifi Interface Connection

The printer supports 2.4G WiFi module communication function, and the

printer supports WeChat distribution network function, which can quickly

realize the connection between the printer WiFi and the router; the specific

operation steps through WeChat distribution network are as follows:

1. Press and hold the [Volume -] button to turn on the device. After turning

on the button, do not release the button. Press and hold for about 3

seconds. The printer will enter the intelligent network configuration mode,

and the voice prompt "Start network configuration" will be displayed, and

the blue [LINK] indicator light flashes. The network distribution operation

can be carried out at the time.

2. Make sure that the mobile phone is connected to the router and the

network is normal. Use the mobile phone WeChat to scan the QR code on

the bottom of the printer to enter the network configuration interface, and

click the "Start Network Configuration" button.

3. Enter the password of the router connected to the mobile phone, and

then click the "Connect" button. The printer will start to configure the

network. After the network is configured successfully, the printer will

automatically connect to the router and give a voice prompt "Wireless

network is connected". At the same time, it will print the IP address. Users

can send data to the printer through this IP address.

4. If the printer has completed the network configuration, the network

configuration information will be automatically saved, and the next time the

machine is turned on, it will automatically connect Wifi. After the connection

is successful, the voice prompt "wireless network is connected".

SPRT

８

2.4.4Power Connection

SP-POS588 uses external power supply as 12VDC±5 ％, 3A, three

core model, as below:

2.5 Buttons and Indicators

2.5.1 Power switch

Control on/off status of power. is off status. Press “-” is on status.

2.5.2 Feed Button

There are 1 paper feed button and 2 volume adjustment buttons on the

printer.

As shown in Figure 2-1-2, the printer has two buttons, [Volume +] and

[Volume -], which can adjust the volume of the speaker's voice. When the

printer is in normal working state, when press the button each time, the

volume increases or decreases by one level with voice prompts at the

same time.

【FEED 】is paper feed button. Print command can enable or disable

【FEED】status to be on or off. Under enable status, hold down【FEED】,

start paper feeding, release the button paper feeding stops.

2.5.3 Opening Upper Cover Button

Press down on the cover-opening clasp to open the paper compartment

cover.

2.5.4 Power indicator light (green)

[POWER] The indicator light is the power indicator. If the power is on, the

power indicator light will be on.

2.5.5 Error indicator light (red)

[ERROR] The indicator is an error status indicator, when the printer is

working normally, the red ERROR indicator is off, and the indicator flashes

as an abnormal alarm state.

The error indicator flashes: it indicates that the printer has an error.

According to the different flashing modes, it indicates the type of printer

error.
