Stage Right™
Memphis Blue Classic Dynamic Microphone
P/N 600035
User's Manual
SAFETY WARNINGS AND GUIDELINES
•Do not expose this microphone to water or moisture of any kind. If it does get wet, immediately cease use and
disconnect it from the mic cable, then wipe all moisture off and allow it to fully dry before using it again or storing it
in a confined space.
•Do not expose this microphone to excessively high temperatures. Do not place it in, on, or near heat sources, such as
a fireplace, stove, radiator, etc. Do not leave it in direct sunlight for long periods of time.
•Do not subject the microphone to extreme force, shock, or fluctuations in temperature or humidity. Do not drop.
Store in a padded case to protect it during transport.
•This device has no user serviceable parts. Do not attempt to open, service, or modify this device.
INTRODUCTION
The Memphis Blue Classic Dynamic Microphone is a dynamic microphone with modern performance characteristics and a look
straight out of the 40s and 50s. It features a high-quality moving coil pick-up, a high sensitivity, wide frequency range, and a
super-cardioid polar pattern. Designed for voice use, it has a transparent sound and a slight presence peak, which enhances
voice reproduction. It is perfect for both the studio and stage.
FEATURES
•Classic styling combined with modern performance characteristics
•High-quality zinc die-cast housing
•High output dynamic cartridge for big, powerful sound
•Super-cardioid polar pattern for reduced feedback during live performances
•Pop-free locking on/off switch
2
USAGE NOTES
•The XLR cable will hang straight down the mic stand for clean stage look. Users may have to remove the star washer
from threaded mic stands to accommodate the XLR cable.
•When using boom-style mic stands be sure to properly brace the stand to prevent toppling.
•Not recommended for use with clutch-style mic stands.
Connect using a balanced XLR cable
(not included).
Slide the power switch to the ON
position to use.
The fixed base can be angle adjusted.
SPECIFICATIONS
Model
600035
Microphone Type
Dynamic
Polar Pattern
Super cardioid
Frequency Range
40Hz ~ 18kHz
Sensitivity
52dB ±2dB (0dB=1V/Pa 1000Hz)
Output Impedance
< 300 ohms
Equivalent Noise Level
≤ 180dB
Monoprice™, Stage Right™, the Stage Right logo, and all Monoprice logos are trademarks of Monoprice Inc.
