Star Choice IRC 551 Manuale utente

Star Choice IRC 551 IR Remote Control

and

Star Choice URC 551 IR/UHF Remote Control

Télécommande IRC 551 IR de Star Choice

Télécommande URC 551 IR/UHF de Star Choice

Users Guide

Guide d'utilisation

Starchoice.com

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 1 Friday, May 26, 2006 12:27 PM

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Key Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Device Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Installing Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

If You Have More Than One Satellite Receiver. . . . . . . . . . . . . . . . . 10

Programming Device Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Programming TV/VCR Combo Control . . . . . . . . . . . . . . . . . . . . . . . 13

Searching for Your Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Checking the Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Programming Channel Control Lock . . . . . . . . . . . . . . . . . . . . . . . . 15

Unlocking Channel Control. . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Locking Channel Control to SAT . . . . . . . . . . . . . . . . . . . . . . .16

Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Unlocking Volume Control for a Single Device (Individual

Volume Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Unlocking All Volume Control (Global Volume Unlock) . . . . . 17

Locking Volume Control To One Mode (Global Volume Lock) 17

Using the Master Power Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Programming the Master Power Key . . . . . . . . . . . . . . . . . . . 18

Using the Master Power Key. . . . . . . . . . . . . . . . . . . . . . . . . . 19

Clearing the Master Power Key . . . . . . . . . . . . . . . . . . . . . . . 19

Re-Assigning Device Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Disabling DVD and AUX Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Disabling DVD and AUX Modes . . . . . . . . . . . . . . . . . . . . . . . . 20

Enabling DVD and AUX Modes. . . . . . . . . . . . . . . . . . . . . . . . .21

Clearing Custom Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Removing Volume Lock and Channel Lock Programming . . . 21

Removing All Custom Programming. . . . . . . . . . . . . . . . . . . . 21

FCC Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Table Des Matières . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Manufacturer’s Codes (Codes des fabricants) . . . . . . . . . . . . . . . .50

Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Setup Codes for Audio Amplifiers. . . . . . . . . . . . . . . . . . . . . . 58

Setup Codes for Audio Amp/Tuners . . . . . . . . . . . . . . . . . . . . 59

Setup Codes for Miscellaneous Audio . . . . . . . . . . . . . . . . . . 63

Setup Codes for Cable Boxes/Converters . . . . . . . . . . . . . . .64

Setup Codes for DVD Players . . . . . . . . . . . . . . . . . . . . . . . . . 65

Setup Codes for DVRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Setup Codes for Satellite Receivers . . . . . . . . . . . . . . . . . . . 72

Setup Codes for TV/DVD Combos . . . . . . . . . . . . . . . . . . . . . .74

Setup Codes for TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . .75

Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 2 Friday, May 26, 2006 12:27 PM

INTRODUCTION

The Star Choice IRC 551 IR and Star Choice URC 551 IR/

UHF Remote Controls by Universal Electronics are our

latest generation universal remote controls. Their

sophisticated technology allows you to consolidate up to

five of your original home entertainment remote

controls into one easy-to-use product. Moreover, they’re

packed with advanced features such as:

• Preprogrammed control to operate the satellite

receiver supplied by your satellite service provider

• Dedicated keys to control popular functions on your

DVR (Digital Video Recorder)

• Programmable Master Power key for master on/off

control ofyour home entertainment equipment with

a single keystroke

• An Instant Tune-In key for assignment to your

favorite channels

• Channel Lock to lock channel selection only to the

satellite receiver

• Volume Lock to lock volume controls to one mode or

individual modes

• Device Key Re-Assignment to remotely control a

second (duplicate) device

• Code Search to help program control of older or

discontinued components

• Color-coded keys to quickly locate popular

functions

• Code library for popular video and audio devices

Before using the product, you need to install the

enclosed batteries and also perform some programming

to operate the specific home entertainment devices you

wish to control.

Please follow the instructions detailed in this manual to

set up the unit and then start enjoying your new remote

control and satellite service.

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 3 Friday, May 26, 2006 12:27 PM

FEATURES AND FUNCTIONS

Use the illustrations below to locate features on the Star

Choice IRC 551 IR and Star Choice URC 551 IR/UHF

Remote Controls and then study the Key Charts (on the

next three pages) to learn how they function.

To find out what type of devices can be controlled by

each device key after programming, see “Device Table”

on page 8.

Star Choice URC 551 IR/UHF Remote Control

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 4 Friday, May 26, 2006 12:27 PM

Star Choice IRC 551 IR Remote Control

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 5 Friday, May 26, 2006 12:27 PM

Key Charts

Key Function

Press POWER once to turn on or off a

home entertainment device. For

MASTER POWER control, see “Using the

Master Power Key” on page 18.

Press AUDIO, AUX, DVD, SAT, or TV once

to select a home entertainment device

to control. Also see “Device Table” on

page 8.

Each device key has an embedded LED

(red light) that blinks upon selection

and indicates the remote control is

working and (after programming) is

sending signals.

Use GUIDE to display the program

guide.

Press INTERACTIVE once to display the

Interactive menu. (For future

interactive applications)

Use INFO to display the current channel

and program information.

Use the cursor keys to move the cursor

in the program guide and menu screens

and to navigate within the interactive

service.

Use ENTER/OK to choose options, PPV

events, and to tune programs from the

program guide.

Use EXIT to exit out of your satellite

receiver’s menu and guide.

Use A, B, C or Dto access additional

satellite features. (For future interactive

applications).

Use VOL+ (or VOL-) to raise (or lower)

the audio volume.

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 6 Friday, May 26, 2006 12:27 PM

In GUIDE mode, use FAVOURITES to

cycle through your favourite-channels

listings. The default is All Channels.

While watching TV, use FAVOURITES to

step through the pre-set favourite

channels listing you selected in Guide

mode.

Use CH+ (or CH-) to select the next

higher (or lower) channel.

For DVD players, use these keys to skip

forward (or reverse) through chapters.

For amplifiers/receivers, use these keys

to select the next higher (or lower)

preset station.

Press MUTE once to turn the sound off

or on.

Press LAST Ch once to recall the last

channel.

Press INTERESTS to display the Interests

menu.

Press PPV to access Pay Per View

services.

Use BROWSE to display the current

program title at the bottom of the

screen.

BROWSE also activates the navigator

buttons S, T, W, Xto preview the

program titles on other channels or at a

later time.

Press LOCKS to display the Parental

Controls menu.

Press OPTIONS to access the Options

menu of your satellite receiver.

Use to command your recording to

Skip Back in steps of 10 second-

(default) intervals.

Not available on the Star Choice IRC

551 IR Remote Control.

Key Function

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 7 Friday, May 26, 2006 12:27 PM

Device Table

NOTE: Please refer to the table below when

performing the instructions in

“Programming Device Control” on page 11 or

“Programming TV/VCR Combo Control” on

page 13.

Use to command your recording to

Skip Forward in steps of 30-second

(default) intervals.

Note: In GUIDE mode, pressing Skip

Forward advances the guide by 24-hour

increments.

Not available on the Star Choice IRC

551 IR Remote Control.

Press DVR LIST once to display a list of

recorded shows on your DVR.

Not available on the Star Choice IRC

551 IR Remote Control.

Press GO BACK to return to watching TV

or the previous menu.

Use REC, REW, PLAY, FFWD, STOP, and

PAUSE to control a VCR, DVD player, or

a DVR (after selecting a desired device).

Note: In GUIDE mode, pressing FFWD

advances the guide by 6-hour

increments.

Use the keypad numbers (1-9, and 0) to

directly tune channels (e.g., 09).

For amplifiers/receivers, use the keypad

numbers to select inputs 1 through 10.

ress

ASPECT

once to change the aspect

ratio of the show you are watching. (Not

available on all set-top boxes.)

Not available on the Star Choice IRC

551 IR Remote Control.

Use VIDEO SOURCE to watch TV or

video programs on a desired device.

Press HELP to access the Help menu.

Key Function

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 8 Friday, May 26, 2006 12:27 PM

After programming, the Star Choice IRC 551 IR and Star

Choice URC 551 IR/UHF Remote Controls can control

the following types of devices:

INSTALLING BATTERIES

1. On the back of the remote control, push the

tab and lift off the battery cover.

Device Key Controls these types of devices

Satellite Receiver

Audio Amplifier, Tuner, Receiver,

Satellite Receiver, Television

Television, Satellite Receiver, Audio

Amplifier, Audio Receiver

DVD Player, VCR, TV-DVD Combos,

TV-VCR Combos, Audio Amplifier,

Audio Receiver, Satellite Receiver

Te le v is io n

❶

❷

❸

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 9 Friday, May 26, 2006 12:27 PM

2. Locate the two (2) enclosed AA batteries.

Match the + and - marks with those in the

battery case, then insert them.

3. Align the cover’s keys with the case’s holes and

press the cover back into place. The tab should

click when the cover is locked.

NOTE: When batteries need replacement, the remote

control ceases to operate. Replace the

batteries and the unit is restored to its full

functionality, complete with your favorite

settings.

IF YOU HAVE MORE THAN ONE SATELLITE

RECEIVER

Your remote control address is set at the factory to 0000

to control all of the functions on your Motorola satellite

receiver. However, if you have more than one satellite

receiver, you may want to prevent the remote control in

one room from affecting the satellite receiver in another

room. To prevent this kind of interference, you must

“pair” each remote control with each receiver by

assigning a new “address” to each combination. This

“address” assignment is made using your remote control

as follows:

1. Turn on the TV.

4. Test the remote control by pressing any mode

key (e.g., TV). If the batteries are inserted

correctly, the LED (red light) blinks once.

2. Press the SAT key to select the remote control’s

SAT mode.

3. Press the Options key to display the Options

screen on your TV.

4. On the Options screen, use the S, T, W, X

keys to highlight the Change System Settings/

System Setup option, then press ENTER.

5. On the Systems Setting /Setup screen, use the

S, T, W, Xkeys to highlight the Change

Installation Settings/System Settings option,

then press ENTER. (Applies to DSR 5xx, 207,

317 receivers.)

Motorola 551 IR_IR-UHF Rev 2.3.fm Page 10 Friday, May 26, 2006 12:27 PM

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Star Choice Telecomando

Star Choice

Star Choice IRC 550 Series Manuale utente

Manuali Telecomando popolari di altre marche

Panasonic

Panasonic EUR7622KB0 Manuale utente

Bang & Olufsen

Bang & Olufsen Beo4 Manuale utente

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuale utente

Multiplex

Multiplex PROFI TX 9 Manuale utente

One Remote

One Remote RMB4 Manuale utente

FUTABA

FUTABA 9ZAP - PART2 Manuale utente

HR Matic

HR Matic HR MULTI 3 Manuale utente

Yamaha

Yamaha ACC-GNRST-30-20 Manuale utente

EisSound

EisSound KBSOUND Manuale utente

Marantz

Marantz RC101 Manuale utente

Conrad

Conrad FS20 TC6 Manuale utente

Anritsu

Anritsu MP1777A Manuale utente

Niles

Niles WVC100 Guida alla risoluzione dei problemi

RCA

RCA RCU1300 Manuale utente

Bang & Olufsen

Bang & Olufsen BEO6 Manuale utente

GE 94901 Manuale utente

Onbon

Onbon YQ1-75 Manuale utente

FUTABA

FUTABA R7108SB Istruzioni per l'installazione
