Manual Revision: 10/08/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

WIFI2HDMC / WIFI2HDMCGE

Wireless Display Adapter for

Mobile Devices

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

Preparing Your Site ................................................................................3

Hardware Installation .............................................................................................................................. 3

Software Operation / Installation........................................................................................................ 4

Technical Support ..................................................................................8

Warranty Information............................................................................8

Instruction Manual

Introduction

Packaging Contents

• 1x Wireless Display Adapter

• 1x Universal Power Adapter (NA/UK/EU)

• 1x USB Cable to Power Adapter Port (optional for USB Power source)

• 1x Software Installation Disc

• 1x Quick Installation Guide

System Requirements

• HDMI enabled display device (i.e. television, projector)

• 802.11n/g Wireless enabled video source device (i.e. Smartphone, computer)

• HDMI cable

• Available AC electrical outlet or USB power source

Instruction Manual

Preparing Your Site

1. Determine where the display will be located and place/ mount the

display appropriately.

NOTE: The maximum distance of the display adapter is limited to the distance of your

802.11n/g Wireless network device. If the wireless signal is obstructed by walls, or other

interference the signal quality and maximum distance will likely be reduced.

Ensure the Receiver Unit is situated near an available AC electrical outlet.

Hardware Installation

1. Connect an HDMI video cable from the HDMI out port on the Wireless Video

Adapter to the HDMI in port on the HDMI enabled display device.

2. Connect the power adapter from an available AC outlet to the power adapter port

on the Wireless Video Adapter.

Connect the USB to power cable from an available USB power source to the power

adapter port on the Wireless Video Adapter.

3. Press the Power button to the in position to turn on the device, the Power LED will

be activated.

Instruction Manual

Software Operation / Installation

Initial Software Operation

1. Once Installation has completed, and the device has been turned on, the menu

below will appear on your HDMI enabled display device, with an IP address listed at

the bottom. By default the IP address will be:

http://192.168.59.254/remote

2. Using a WIFI enabled device with web browser, such as a computer or SmartPhone.

Connect to the Wireless Video Adapter by browsing for available networks and

connecting to the WIFI2HDMC.

NOTE: By default the SSID for the device is WIFI2HDMC and there is no security

key. Please review the manual for WIFI enabled device for specic details regarding

connecting to a wireless network.

3. Once you have connected to the device, open your web browser visit the Setup IP

address listed on the display.

NOTE: By default the Setup IP address is: http://192.168.59.254/remote

Instruction Manual

4. This will display the virtual remote control. Using the remote control you can

operate the user interface displayed on your display.

The virtual Remote control allows for advanced device operation. Download the full

product Manual at StarTech.com for advanced operation.

Connect a Miracast Enabled Mobile Device

NOTE: Exact steps regarding Miracast setup will vary from device to device. Please

review the documentation included with your SmartPhone or tablet for steps specic

instructions.

1. Press the Mode button on the Wireless Video Adapter repeatedly until you see the

Wi-Fi Miracast screen shown on your display.

Instruction Manual

2. Open your mobile settings page.

3. On the Settings browse to Display->Wireless Display, or Media Output, or All Share

Cast depending on your device.

NOTE: Other terminology may be used depending on your device.

4. By default the Wireless Video device will be listed as the MAC address shown on the

HDMI display. Tap this device to connect.

5. The video from your Miracast enabled mobile device will now be shown on your

video display.

Intel® WiDi Operation Wirelessly Share Your PC Screen

1. Press the Mode button on the Wireless Video Adapter repeatedly until you see the

Wi-Fi Miracast mode shown on your display.

Instruction Manual

2. Open the WiDi software included with your Wi-Di enabled computer system.

3. The adapter will be listed under detected adapters.

4. Select the adapter and click connect.

5. Your computer screen will now be shared wirelessly on the display.

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.
