StarTech.com DK30C2DPEP Manuale utente

Manual Revision: 01/31/2019

User Manual

For the latest information and specications visit

www.startech.com/DK30C2DPEP

Dual-4K Universal Docking Station - USB-C /

USB 3.0 - DisplayPort & HDMI - 100W PD 3.0

Actual product may vary from photos

SKU#: DK30C2DPEP, DK30C2DPEPUE

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Product installation and/or mounting should be completed by a certied

professional as per the local safety and building code guidelines.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de Sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• L’installation et/ou le montage du produit doit être réalisé par un

professionnel certié et dans le respect des normes locales et du code de

construction local.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

Misure di Sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un

tecnico professionale certicato che conosca le linee guida locali sulle norme

edilizie e sulla sicurezza.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Installation och/eller montering får endast göras av behöriga yrkespersoner

och enligt gällande lokala förordningar för säkerhet och byggnormer.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

iii

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に

従い、有資格の専門業者が行うようにしてください。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Warning Statements

• Make sure to assemble this product according to the instructions. Failure to

do so might result in personal injury or property damage.

Avertissements

• Assemblez ce produit conformément aux instructions. Si vous ne respectez

pas ces instructions, vous risquez de vous blesser ou d’endommager

l’équipement.

Varningsmeddelanden

• Se till att du monterar produkten i enlighet med instruktionerna. Om du inte

gör det kan skada på person eller egendom uppstå.

Warnhinweise

• Montieren Sie dieses Produkt gemäß den Anweisungen. Anderenfalls kann

dies zu Verletzungen von Personen oder Schäden an Eigentum führen.

Dichiarazioni di Avvertenza

• Assemblare il prodotto rispettando le istruzioni. Il mancato rispetto delle

istruzioni potrebbe causare danni a persone o proprietà.

Mensagens de Aviso

• Certique-se de que monta este produto de acordo com as instruções. O

incumprimento pode resultar em ferimentos pessoais ou danos de

propriedade.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Advertencias de Uso

• Asegúrese de ensamblar este producto según las instrucciones. De lo

contrario, pueden producirse lesiones personales o daños de propiedad.

Waarschuwingen

• Zorg dat dit product volgens de instructies in elkaar wordt gezet. Indien dit

niet goed gebeurt kan lichamelijk letsel of materiële schade ontstaan.

注意

• 必ず取扱説明書に従って本製品の組み立てを行って下さい。取り扱いを誤

った場合に、傷害を負う恐れや物的損害が発生する恐れがあります。

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements................................................................................... i

Safety Statements .............................................................................................. ii

Warning Statements.......................................................................................... iii

Product Diagram ................................................................................................ 1

Product Information.......................................................................................... 2

Package Contents ..................................................................................................................................... 2

Requirements ............................................................................................................................................. 3

Installation............................................................................................................ 4

Front Ports ................................................................................................................................................... 4

Rear Ports..................................................................................................................................................... 5

Side Port ....................................................................................................................................................... 6

Powering the Docking Station ............................................................................................................. 6

(Optional) Mounting................................................................................................................................ 6

Operation.............................................................................................................. 7

Power Button.............................................................................................................................................. 7

Congure Displays.................................................................................................................................... 7

Supported Video Resolutions............................................................................................................... 8

Product Diagram

Front View

1. USB-A Port

2. USB-C™ Port

3. Audio Input/Output Port

4. Power Button

Rear View

5. DC Power Input Port

6. USB-C Host Port

7. Video 1 DisplayPort™ Port

8. Video 1 HDMI® Port

9. Video 2 DisplayPort Port

10. Video 2 HDMI Port

11. Ethernet Port

12. USB-A Peripheral Ports

1 2 3 4

5 6 7 8 9 10 11 12

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Side View

13. Lock Slot

Bottom View

14. Mounting Holes

Product Information

Package Contents

• Docking Station x 1

• USB-C Cable (with Attached USB-C to USB-A Adapter) x 1

1414

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

• (DK30C2DPEP) Universal Power Adapter (NA/JP, ANZ) x 1

• (DK30C2DPEPUE) Universal Power Adapter (UK, EU) x 1

• Quick-Start Guide x 1

Requirements

Requirements are subject to change. For the latest

requirements, please visit:

www.startech.com/DK30C2DPEP.

Power:

• AC Electrical Outlet

Laptop:

• Host Laptop with an available USB-A or USB-C Port x 1

Note: A USB-C 3.1 Gen 1 Port with Power Delivery is required

for full functionality.

Displays:

• DisplayPort Enabled Display x 1 or 2*

• DisplayPort Cable x 1 or 2*

• HDMI Enabled Display x 1-2*

• HDMI Cable x 1-2*

* Note: Display type is congurable and allows for two

DisplayPort Equipped Displays, two HDMI Equipped Displays,

or one DisplayPort and one HDMI Equipped Display.

Ethernet:

• CAT 5e/CAT 6 Cable x 1

• Network Device (e.g. Router, Switch, Modem, etc.) x 1

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

USB Peripherals:

• (Optional) Keyboard, Mouse, Flash Drive, Printer, Webcam,

Drive Enclosure, Display Adapter, Mobile Phone, or Tablet, etc.

x 2

• (Optional) USB-A to USB-B Cable x 2

• (Optional) USB-C to USB-C Cable x 2

Audio:

• Speakers or Headset x 1

• 3.5 mm Audio Cable x 1

Operating Systems:

• Windows® 7 (32-bit or 64-bit)

• Windows 8 (32-bit or 64-bit)

• Windows 8.1 (32-bit or 64-bit)

• Windows® 10 (32-bit or 64-bit)

• macOS 10.11

• macOS 10.12

• macOS 10.14

• Chrome OS™

Installation

Front Ports

1. Connect a USB Cable to your USB Device. Connect the

other end of the USB Cable to the USB-A Port on the

Docking Station.

2. Connect a USB Cable to your USB-C Enabled Mobile

Device. Connect the other end of the USB-C Cable to the

USB-C Port on the Docking Station.
