StarTech.com ST4300U3C1 Manuale utente

Manual Revision: 06/10/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ST4300U3C1 / ST4300U3C1B

3 Port USB 3.0 Combo Charging Hub with Fast Charge

Port and Smart Phone / Tablet Stand - White/Black

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View .................................................................................................................................................... 1

Rear View...................................................................................................................................................... 1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

Installation .............................................................................................3

Operation ................................................................................................3

Smart Phone / Tablet Stand .................................................................................................................. 3

Fast Charge.................................................................................................................................................. 5

LED Information......................................................................................................................................... 5

Specications..........................................................................................6

Technical Support ..................................................................................7

Warranty Information............................................................................7

Instruction Manual

Product Diagram

Front View Open

DC Jack

USB 2.0

Data/Fast

Charge Port

Micro USB

3.0 Host Port

USB 3.0

Hub Ports

Smart Phone/Tablet Stand

Mode Button

Power LED

Fast Charging LED

Front View Collapsed

Rear View

Instruction Manual

Introduction

Packaging Contents

• 1x USB 3.0 Hub with Charge Port

• 1x USB 3.0 A - Micro B Cable

• 1x Universal Power Adapter (NA/UK/EU)

• 1x Instruction Manual

System Requirements

• USB enabled computer system with an available USB port

• Available Power Outlet

Instruction Manual

Installation

The hub is packaged in its collapsed form, with the silver stand folded under the hub. It

is recommended the stand be unfolded and raised prior to connecting the power and

your USB devices. If you intend to use the stand, please follow the section below titled

Smart Phone / Tablet Stand to unfold and raise the stand prior to connecting power.

1. Connect the included power adapter to the device, then to an AC outlet – the Power

LED should be lit green.

2. Connect the included Micro USB A-B cable into the hub’s Micro USB 3.0 Port, and

then to an available USB Port on your PC.

Note: If connected to a USB 2.0 host port, the hub will only operate at USB 2.0

speeds.

3. The operating system should detect the hub immediately and automatically

install it.

4. Connect your USB peripherals to the USB 3.0 Data Hub Ports, or to the USB 2.0 Data/

Fast Charge Port.

5. The Data/Fast Charge Port can be used as a standard USB 2.0 Data port, OR as a

Fast Charge Port for charging mobile devices. Press the Mode button on the hub to

toggle between Data or Charge operation.

Note: The Fast Charge LED will light Blue when Fast Charge mode is selected. The

hub provides up 2.1A while in charging mode, and will only provide low voltage

charging while in standard mode.

Operation

Smart Phone / Tablet Stand

The 3 Port USB 3.0 Charging Hub is equipped with a Smart Phone or Tablet cradle/

stand. The stand serves as a holder for your mobile device, conveniently allowing you

to connect, charge, and cradle your device.

1. With the hub resting on a surface, gently lift the front corners of the hub slightly.

2. While slightly elevated, simultaneously apply a small amount of pressure to the

corners of the cradle.

Instruction Manual

3. The cradle will release, continue to gently unfold the cradle from below the hub,

until it is in its upright position

4. Plug a USB cable into your Smart Phone or Tablet device.

5. Place your device into the cradle. Choose an orientation so that your device is

secure in the cradle. It is recommended to use a horizontal orientation for Tablets

or larger devices, and a vertical orientation for Smart Phones, cell phones, and

smaller devices.

6. Escort the opposite end of your USB cable through the hole located on the cradle

stand and into the USB 2.0 Data/Fast Charge port on the hub.

7. Press the Fast Charge Mode Button on the surface of the hub to switch the USB 2.0

port from standard to charging mode. Once charging mode is enabled, the status

LED will light blue.

Instruction Manual

Fast Charge

The 3 Port USB 3.0 Charging Hub is equipped with a USB 2.0 Data/Fast Charge Port

capable of outputting up to 2.1A of charging power, and supports USB Battery

Charging Specication Revision 1.2. The quantity of charging electricity provided

is dependent upon how much the connected device needs to achieve a full speed

charge.

*Supports USB Battery Charging Specication Revision 1.2 (Note: The hub will only

provide a trickle charge on the Samsung Galaxy Tab®, the Apple® iPad®, and the Apple®

iPad mini® while in Fast Charge mode.)

1. With your device connected to the USB 2.0 Data/Fast Charge Port, press the Fast

Charge Mode Button on the surface of the hub to switch the USB 2.0 Port between

standard or charging mode. Once charging mode is enabled, the status LED will

light blue.

2. If you wish to use the USB 2.0 Port as a Data Port, simply ensure the hub is

connected to a host PC, and with your device connected, press the Mode button on

the surface of the hub until the status LED is not lit.

Note: If the Fast Charging Mode is enabled, devices will not be detected for syncing/

data operation.

LED Information

Power: Green for power

Fast Charging: Blue for fast charge mode

Instruction Manual

Specications

Bus Type USB 3.0

Interface USB 3.0, USB 2.0

Industry Standards USB Battery Charging Specication Rev. 1.2

Ports 4

Connector(s)

3x USB 3.0 A (9 pin; SuperSpeed) Female

1x USB 3.0 Micro-B (10 pin; SuperSpeed)

Female

1x USB 2.0 A (4 pin) Female

Maximum Data Transfer Rate 5 Gbit/s

Type and Rate USB 3.0 - 5 Gbit/s

USB 2.0 - 480 Mbit/s

OS Compatibility OS Independent

System and Cable Requirements Available USB 3.0 Port

Color White & Silver (ST4300U3C1)

Black & Silver (ST4300U3C1B)

Enclosure Material Plastic

Dimensions (LxWxH) 127mm x 96mm x 26mm

Weight 13.63 oz [386 g]

LED Indicators 1x Power

1x Fast Charging

Power Adapter 100~240 AC

5V 4A DC

Humidity 10-90% RH

Operating Temperature 0°C to 40°C (32°F to 104°F)

Storage Temperature -10°C to 60°C (14°F to 140°F)

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.
