StarTech.com INFOSAFE IDE2510U2 Manuale utente

Manual Revision: 02/27/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IDE2510U2

SAT2510U2

SAT2510BU2

USB 2.0 External Hard Drive Enclosure

*actual product may vary from photo

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use ofTrademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual i

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Hardware Installation .............................................................................................................................. 2

How to Use ..............................................................................................3

Connecting the Hard Drive.................................................................................................................... 3

Powering the Drive Enclosure .............................................................................................................. 3

Disconnecting the Hard Drive.............................................................................................................. 4

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual 1

Introduction

This USB 2.0 to 2.5 in. External Hard Drive Enclosure lets you transform virtually any

9.5mm thick 2.5in IDE (IDE2510U2) or SATA (SAT2510U2/SAT2510BU2) notebook hard

drive into the perfect portable storage solution.

Ideal for storing digital multimedia and other demanding applications, the hard drive

enclosure allows you to get the most out of your hard drive, connecting to a host

computer using USB 2.0 (also backward compatible with USB 1.1), for maximum data

transfer rates of up to 480Mbps.

A truly portable solution, the enclosure features lightweight yet durable aluminum

construction, as well as a small form factor design that ts perfectly into your pocket or

notebook bag when not in use. To eliminate the hassle of having to nd a power outlet

when you’re ready to back up your data or load your stored les, the enclosure requires

no external power supply, as it’s powered through USB connection to the host computer.

Packaging Contents

• 1 x 2.5in Aluminum Enclosure

• 1 x USB 2.0 Y-Cable

• 1 x Screw Kit

• 1 x Protective Case

• 1 x Instruction Manual

System Requirements

• USB enabled computer system with an available USB port

• Microsoft® Windows® XP/2003 Server/Vista/Server 2008 R2/7 (32/64-bit), or Apple®

Mac OS® 9/10

Instruction Manual 2

Installation

Hardware Installation

CAUTION: Use caution when installing a hard drive in the enclosure. Excessive shock

or force could damage the drive and/or the enclosure, resulting in data loss.

Always ensure that you are properly grounded when handling a hard drive or the enclosure

tray, since electronic components can be damaged by static electricity. If an anti-static mat

or similar product is not available, ground yourself by touching a computer case or other

metal surface for several seconds before handling any components.

1. For IDE hard drives, set the hard drive to function in Master mode by adjusting the

necessary jumpers, according to the drive manufacturer’s instruction.

2. Using the included screwdriver, remove the two screws fastening the end cap with

the USB connector to the enclosure.

3. Attach the 2.5”hard drive to the interface connector (located on the inside of of

the end cap), ensuring a snug connection. Do not use excessive force, to avoid

damaging the drive and the enclosure.

4. Insert the end cap with attached hard drive into the enclosure housing.

Instruction Manual 3

5. Re-fasten the screws that were removed in step 2.

How to Use

Connecting the Hard Drive

Once the enclosure has been attached to a computer, and the necessary software has

been installed, the drive will be accessible as though it were installed within the system.

Prior to using the drive, it will need to be formatted according to your operating

system requirements. To format your newly attached hard drive, or create partitions,

please consult the documentation that accompanied your operating system at the

time of purchase.

Powering the Drive Enclosure

The hard drive enclosure requires no external power supply,

as it is capable of receiving enough power (5V/500mA) from

the USB Bus to which it is connected.

NOTE: Only the Primary connector is required to be plugged

into the computer system. The Secondary connector may be

required if the hard drive cannot draw enough power from a

single USB port.

LED Indicator

The hard drive enclosure oers an LED indicator, to enable you to monitor drive

activity. When the enclosure is powered, the LED will illuminate and remain green.

While the hard drive is being accessed, however, the LED will change from green to

red. Do not remove the enclosure from the host computer while the LED is red, as it

could damage the drive or the enclosure, resulting in data loss.

Instruction Manual 4

Disconnecting the Hard Drive

Windows XP

1. Right click on the removable storage icon, located in the task bar.

2. When the Safely Remove Hardware message appears, click on it with the left

mouse button.

3. You will be asked to select the device you wish to disconnect. Please highlight the

drive listing, and click on OK.

4. On the screen that follows, click on Stop.

5. Wait for the message indicating that it is now safe to remove the device. Please

note: Removing the connected drive prior to receiving notication that it is safe to

do so, could result in losing or corrupting data stored on the drive. Once the Safe

to Remove Hardware message appears, please disconnect the enclosure from the

computer by removing the USB connection.

Mac OS 9/10

To safely disconnect the attached drive from the host computer, close any windows

listing the contents of the removable drive. Once all windows are closed, click on the

USB storage icon on the desktop, and drag it to the Trash Can icon on the desktop.

Allow 5 seconds before physically removing the enclosure/drive from the computer.

Instruction Manual 5

Specications

IDE2510U2 SAT2510U2/ SAT2510BU2

Host Interface USB 2.0

Chipset ID Initio INIC1511 Sunplus SPIF225A

External Connectors 1 x USB mini-B female

LED Indicators 1 x Power/Activity

Compatible Hard Drives 2.5in IDE ATA-100

up to 9.5mm

height

2.5in SATA 1/2/3 up to

9.5mm height

Maximum Data Transfer Rate 480 Mbps (USB 2.0)

Material Aluminum/ Plastic

Color Silver Silver / Black

Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)

Storage Temperature -20°C ~ 70°C (-4°F ~ 158°F)

Humidity 0% ~ 90% RH

Dimensions 120 x 75 x 10 mm (4.72 x 2.95 x 0.39”)

Weight 62.1g (2.19 oz.)

Compatible Operating Systems Windows XP/Server 2003/Vista/Server 2008

R2/7 (32/64-bit), Mac OS 9/10

Instruction Manual 6

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.

Altri manuali per INFOSAFE IDE2510U2

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali StarTech.com Allegato

StarTech.com

StarTech.com SAT3520U3SR Manuale del sistema

StarTech.com

StarTech.com SAT2510U2F Manuale utente

StarTech.com

StarTech.com DRW110SAT Manuale utente

StarTech.com

StarTech.com IDECASE525U2 Manuale utente

StarTech.com

StarTech.com SAT3540ER2 Manuale utente

StarTech.com

StarTech.com INFOSAFE IDE2510U2 Manuale utente

StarTech.com

StarTech.com HSB320SATBK Manuale utente

StarTech.com

StarTech.com UNI2510U2V Manuale utente

StarTech.com

StarTech.com M2E1BRU31C Manuale utente

StarTech.com

StarTech.com S352U2RER Manuale utente

StarTech.com

StarTech.com S3540BU33E Manuale utente

StarTech.com

StarTech.com MADE EASY HSB110SATBK Manuale utente

StarTech.com

StarTech.com 4POSTRACK25 Manuale utente

StarTech.com

StarTech.com IDECASE35U2B Manuale utente

StarTech.com

StarTech.com SM21BMU31C3 Manuale utente

StarTech.com

StarTech.com S251BPU313 Manuale utente

StarTech.com

StarTech.com SM21BMU31CI3 Manuale utente

StarTech.com

StarTech.com DRW115SAT Manuale utente

StarTech.com

StarTech.com S252BU33R Manuale utente

StarTech.com

StarTech.com 2636CABINET Manuale utente

StarTech.com

StarTech.com ATXFULL635V Manuale

StarTech.com

StarTech.com InfoSafe SAT3510U2B Manuale utente

StarTech.com

StarTech.com 25SATSAS35HD Manuale utente

StarTech.com

StarTech.com SAT2510BU32 Manuale utente

Manuali Allegato popolari di altre marche

SilentiumPC

SilentiumPC Armis AR5 Manuale

Pulsar

Pulsar 17/TRP80/DSPR Manuale utente

Thermaltake

Thermaltake V150 TG Manuale utente

MSI

MSI MPG SEKIRA 500X Manuale utente

Antec

Antec Dark fleet DF-10 Manuale utente

Nexans

Nexans WTC05 Manuale utente

Peavey

Peavey DS 1502 Manuale utente

D-Link

D-Link ShareCenter Pro DNS-1550-04 Manuale utente

Rosewill

Rosewill RX82-U(JBOD) Manuale utente

QNAP

QNAP SAS JBOD CLI 1.0 Manuale utente

GAMDIAS

GAMDIAS Talos P1 Manuale utente

Auvs

Auvs KR615 Manuale utente

Digitus

Digitus DA-71114 Manuale utente

CommScope

CommScope FDH 3000 Manuale utente

FS FHD-FWME4 Manuale utente

JBL

JBL CS1215T Manuale utente

Pulsar

Pulsar ARAD-S4 Manuale utente

Pulsar

Pulsar AWO454 Manuale utente
