StarTech.com SAT5210U2E Manuale utente

SATA Optical Drive Enclosure

5.25” USB 2.0 eSATA to SATA

Optical Drive External Enclosure

SAT5210U2E

Instruction Manual

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Installation....................................................................... 2

Hardware Installation...................................................................2

Driver Installation.........................................................................4

How to Use ...................................................................... 4

Speciﬁcations.................................................................. 6

Technical Support........................................................... 7

Warranty Information ...................................................... 7

Introduction

Thank you for purchasing a StarTech.com InfoSafe 5.25” eSATA/USB

2.0 SATA Optical Drive External Enclosure. This versatile solution

provides a cost-effective way to turn any 3.5” SATA 1.5/3.0 Gbps hard

drive, or 5.25” optical drive into an external solution. Equipped with both

USB 2.0 and eSATA interfaces for maximum data transfer capability

and convenient connectivity to the host computer, SAT5210U2E

protects installed drives with a sturdy yet attractive aluminum casing

and a 40mm fan to help cool the drive for optimal performance.

Packaging Contents

1 x SAT5210U2E enclosure•

1 x USB A-B cable•

1 x Screw kit•

1 x Installation CD•

1 x Instruction Manual•

System Requirements

USB and/or eSATA enable computer system•

Microsoft Windows• ®98SE/ME/2000/XP/Vista, or Mac OS®X

Installation

Hardware Installation

Loosen the Retaining Screws, on the rear panel. Please note that1.

these screws do not need to be removed, rather loosened enough to

allow the Hard Drive Tray to slide out from the enclosure.

Slide the Drive Tray out from the Enclosure.2.

Connect the drive you wish to install (hard drive, optical drive) to the3.

SATA data and power cables provided by the circuit board attached

to the Drive Tray:

USB connector

eSATA connector

Power connector

Power Switch

Cooling Fan

Retaining Screws

Once the drive interface connection has been made, please fasten4.

the drive (label side up) to the Drive Tray using the screws provided:

If installing a 3.5” hard drive, please skip to step #6. If installing an5.

optical drive:

Once the SATA connections to the drive have been secured, and

the drive has been fastened to the Drive Tray, remove the plastic

cover from the Front Panel as pictured below, to allow access to an

installed optical drive.

Apply gentle pressure from left to right (with Enclosure facing you) to

loosen the plastic cover. Once loosened, gently pry the plastic cover

away from the Enclosure.

Slide the Drive Tray (with drive installed) into the Drive Enclosure,6.

and tighten the Retaining Screws (loosened in step #1) on the front

panel to secure the tray within the Enclosure. Installation is now

complete:

Driver Installation

Windows 98SE/ME

To install the necessary drivers, insert the Driver CD (included) into the

CD/DVD drive:

When the Add New Hardware Wizard appears, please click on Next.1.

Select Search for the best driver for your device (Recommended)2.

and click on Next.

You will be asked to specify the location of the Windows 98 driver.3.

Please ensure that Specify a location and CD-ROM drive are

selected (with checkmarks) and click on Browse to locate the driver

ﬁle (D:\JM20336_Win98 driver), where D: designates the CD/DVD

drive. Once the ﬁle has been located, click on Next.

Once Windows has located the necessary ﬁle, click on Next.4.

Once Windows ﬁnishes installing the software that your hardware5.

device requires, click on Finish to conclude installation.

Windows 2000/XP/Vista, Mac OS X

No driver installation is required for these operating systems, as this

enclosure is natively supported, so the drivers are already installed.

How to Use

Once the drive has been secured within the enclosure, it can be

connected to the host computer while the host computer is powered

on.

If you will be using an eSATA connection, insert one of the

connectors provided by an eSATA cable (not provided - please see

Accessory Products from StarTech.com for a solution), or the USB

type B connector provided by a USB A-B cable (provided), into the

corresponding port on the rear panel of the Drive Enclosure.

Connect the remaining end of the eSATA or USB cable to an available

eSATA or USB type A port on the host computer as necessary.

Insert the cylindrical, metal connector provided by the Power Adapter

(included) into the DC Power Port located on the rear panel of the

Enclosure. Connect the remaining end of the Power Adapter to an

available power outlet.

Move the Power Switch on the rear panel of the Enclosure to the

ON position. If the Enclosure is connected to a host computer that is

running Windows ME or above, or Mac OS 9.x or higher, the operating

system on the host computer will detect that the connection is present,

and install the necessary drivers. If the host computer is running

Windows 98SE, please follow the instructions listed in the next section,

titled Driver Installation.

If you are installing an optical drive, such as a CD/DVD drive etc., you

may be required to install software that is speciﬁc to the drive. If this

is the case, please ensure you have the ﬁles available from the drive

manufacturer. For further information on this step, please consult the

documentation that accompanied the optical drive.

Specications

Bus Interface USB 2.0

SATA 3.0Gb/s

External Connectors

1 x USB type B

1 x eSATA

1 x Power Connector

Fans 1 x 40mm

LEDs Power

Chipset ID JMicron JMB20336

Maximum Data Transfer Rate USB 2.0: 480Mb/s

eSATA: 3.0Gb/s

Power Adapter 12VDC, 2A, center positive

Dimensions 259.0mm x 166.0mm x 58.0mm

Weight 930g

Compatible Operating

Systems

Windows 98SE/ME/2000/XP/

Vista, Mac OS X

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.
