StarTech.com DVI2HDMIA Manuale utente

Manual Revision: 11/13/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

DVI2HDMIA

DVI to HDMI Video Converter with Audio

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Hardware Installation .............................................................................................................................. 2

Driver Installation...................................................................................................................................... 2

Supported Video Resolutions ..............................................................2

Troubleshooting.....................................................................................3

Microsoft Windows®................................................................................................................................. 3

Mac OSX® ..................................................................................................................................................... 4

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Introduction

Packaging Contents

• 1 x DVI to HDMI converter

• 1 x Power Adapter

• 1 x Instruction Manual

System Requirements

• DVI enabled video source (i.e. computer, DVR/PVR, etc.)

• HDMI enabled display device (i.e. monitor, projector, HDTV, etc.)

• Available AC electrical outlet

Instruction Manual

Side View 1

Side View 2

Installation

Hardware Installation

1. Ensure all devices are powered o, before starting.

2. Connect the included power adapter to the video adapter. The Power LED next to

the connector should light up solid.

3. Connect a standard male/male DVI cable from the video source (i.e. computer, DVR/

PVR, etc.) to the DVI input on the video converter.

4. Connect a standard male/male HDMI cable from the video converter to the display

device (i.e. monitor, projector, HDTV, etc.).

5. OPTIONAL: Connect the analog stereo audio output from the video source (or

alternate audio source) to the stereo RCA audio input on the video converter.

6. Power on the display device rst, follow by the video source.

Driver Installation

No driver or software installation is required.

Supported Video Resolutions

Interlaced 480i, 576i, 1080i (50 / 60Hz)

Progressive 480p, 576p, 720p, 1080p (50 / 60Hz)

Instruction Manual

Troubleshooting

If you are experiencing a shaky or jittery image on screen please make sure that

DVI2HDMIA is set to output at 60Hz. The instructions below detail how to setup this

unit to operate at 60Hz for Microsoft Windows®, and Mac OSX®.

Microsoft Windows®

1. Right Click your desktop and select “Screen Resolution”.

2. The Screen Resolution window will open, select “Advanced Settings”.

3. The Advanced Video Settings window will open, click the“List All Modes”button.

Instruction Manual

4. The List All Modes window will appear, change the selection from the current

(Interlaced) mode, to: 1920x1080, True Color (32bit), 60 Hertz and click the “OK”

button.

Mac OSX®

1. Open Display Settings from the system preferences menu.

2. Place a bullet in “Scaled” and select “1080p” from the drop down menu.

Instruction Manual

Specications

Video Signal Input: DVI (digital) revision 1.0

Output: HDMI 1.2

External Connectors

1 x 29-pin DVI female

2 x RCA audio female

1 x HDMI type A female

1 x DC power

LEDs 1 x Power

Maximum Video Resolution 1080p / 1920x1080 (50 / 60Hz)

Bandwidth 225 MHz / 2.25 Gbps (per channel)

Audio Support Yes

HDCP Support Yes

Power Adapter 5VDC, 2000mA, center positive

Operating Temperature 0°C ~ 70°C (32°F ~ 158°F)

Storage Temperature -10°C ~ 80°C (14°F ~ 176°F)

Humidity 10% ~ 85% RH

Dimensions (LxWxH) 88.0mm x 25.5mm x 68.0mm

Weight 120g

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
