StarTech.com VGA2VID Manuale utente

High Resolution VGA to Composite (RCA) or S-Video Converter - PC to TV

StarTech ID: VGA2VID

This High Resolution VGA to Composite or S-Video Converter is a simple hardware solution that allows you to

convert a VGA/PC video signal into a Composite or S-Video signal for use with a CRT or flat panel display.

The ideal solution for synchronizing monitors with television displays etc., the VGA to Composite/S-Video Converter

offers selectable NTSC or PAL format operating modes to ensure compatibility with virtually any configuration.

Applications

An inexpensive way to increase the size of a computer display

Displays computer screen images on your TV

Great for boardroom meetings, tradeshows, lectures, and CRT digital signage solutions

Use your TV to display computer presentations, surfing the Internet, playing video games and more

Features

High resolution inputs from your PC up to 1600x1200

Provides output in both composite and S-Video formats

Supports NTSC and PAL compatible displays

Image underscan and overscan selectable switch

intrl.startech.com

Technical Specifications

Warranty 2 Years

Converter Type Format Converter

Audio No

Connector A 1 - VGA (15 pin; High Density D-Sub) Female

Connector B 1 - Composite Video (1 x RCA) Female

Connector B 1 - S-Video (4 pin; Mini-DIN) Female

Supported Resolutions PC Input - Up to 1600x1200 @ 60Hz Output -

640x480

MTBF 10,000 Hours

Color Black

Product Length 3.9 in [100 mm]

Product Width 2.5 in [64 mm]

Product Height 0.7 in [18.5 mm]

Product Weight 3.5 oz [100 g]

Input Voltage 5 DC

Center Tip Polarity Positive

Operating Temperature 0°C to 70°C (32°F to 158°F)

Shipping (Package) Weight 0.8 lb [0.4 kg]

Included in Package 1 - VGA to Composite/S-Video Converter

Included in Package 1 - Universal Power Adapter (US/UK/EU/AUS)

Included in Package 1 - User Manual

Certifications, Reports and Compatibility

intrl.startech.com
