StarTech.com SPDIFCOAXTOS Manuale utente

SPDIFCOAXTOS

Two-Way Digital Audio

Converter / Repeater

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital de-

vice, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com. Where

they occur these references are for illustrative purposes only and do not represent an endorse-

ment of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. Regardless of any direct acknowl-

edgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols

contained in this manual and related documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction ................................................................................... 1

Features ......................................................................................1

Package Contents .......................................................................1

Operating Controls and Functions .............................................. 2

Input Panel ..................................................................................2

Switcher Panel.............................................................................3

Connection and Installation ......................................................... 3

Speciﬁcations ................................................................................ 4

Technical Support ......................................................................... 4

Warranty Information .................................................................... 4

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com Two-Way Digital Audio Con-

verter / Repeater. This innovative device allows you to convert and/or

extend your Toslink or Digital Coaxial audio input, without sacriﬁcing any

signal quality, and offers simpliﬁed switching between the Toslink or Digi-

tal Coax signal inputs using a built-on mini-switch - ensuring a convenient

and top quality audio experience.

Features

Supports two way audio conversion: Toslink to digital coaxial or vice•

versa

Supports ampliﬁcation of S/PDIF audio signals and extends their•

transferring distance, through coaxial and/or Toslink cables.

Input 2 to 5.1 channel audio. Output channels will always be the same•

as audio input channels

Compact design saves space•

Easy installation•

Package Contents

1 x User manual•

1 x SPDIFCOAXTOS Audio Converter•

1 x Power Adapter•

Instruction Manual

Operating Controls and Functions

Input Panel

1. Coaxial Input

Connect to the output port of your

S/PDIF audio source (e.g. DVD

player, ampliﬁer) using Coaxial

cable.

2. Toslink Input

Connect to the output port of your

S/PDIF audio source, (e.g. DVD

player, ampliﬁer) using Toslink cable

Output Panel

1. Toslink Output:

Connect to the input port of your S/

PDIF audio equipment such as an

ampliﬁer, using Toslink (optical ﬁber)

cable.

2. Coaxial Output:

Connect to the output port of your

S/PDIF audio equipment such as an

ampliﬁer, using Coaxial cable.

1 2

Instruction Manual

Switcher Panel

1. Input Selection

Use this switch to select

which input to use -

Toslink or Coaxial.

2. Power

Connect the power sup-

ply to the SPDIFCOAX-

TOS unit and connect the

adapter to an electrical

outlet.

Connection and Installation

SPDIFCOAXTOS

Ampliﬁer /

A/V Receiver

DVD Player

Ampliﬁer /

A/V Receiver

Ampliﬁer /

A/V Receiver

Instruction Manual

Specications

Input 1 x Coaxial RCA port, 1x Toslink (optical ﬁber) port

Output 1x Coaxial RCA port, 1x Toslink (optical ﬁber) port

Power DC 5V

Dimension 42(W) x 40.5(D) x 22(H) mm

Weight 25g (adapter not included)

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-

ment to provide industry-leading solutions. If you ever need help with your

product, visit www.startech.com/support and access our comprehensive

selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a one year warranty. In addition, StarTech.

com warrants its products against defects in materials and workman-

ship for the periods noted, following the initial date of purchase. During

this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor

costs only. StarTech.com does not warrant its products from defects or

damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or

exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government, education

and industrial facilities to name just a few. We offer an unmatched

selection of computer parts, cables, A/V products, KVM and Serv-

er Management solutions, serving a worldwide market through our

locations in the United States, Canada, the United Kingdom and

Taiwan.

Visit www.startech.com today for complete information about all

our products and to access exclusive interactive tools such as the

Cable Finder, Parts Finder and the KVM Reference Guide.
