StarTech.com ET91000LC Manuale del sistema

1000 Mbps Gigabit Ethernet Multi Mode Fiber Media Converter LC 550m

StarTech ID: ET91000LC

The ET91000LC 1000 Mbps Gigabit Ethernet Multi Mode Fiber Media Converter LC 550m creates a simple, cost-

effective Gigabit Ethernet-fiber link – transparently converting to/from 1000Base-T Ethernet, and 1000Base-SX

optical signals to extend an Ethernet network connection over LC terminated multimode fiber at distances up to 550

meters (0.3 miles).

Easy to set up and install in a matter of seconds, this compact fiber media converter can be wall-mounted for out-of-

the-way installations. The durable all steel chassis and heavy-duty power supply can withstand challenging industrial

environments, and 6 integrated LED indicators make monitoring the Ethernet/fiber link easy.

This versatile GbE Ethernet to Fiber converter is compatible with most 3COM™, Cisco™, Lucent™ and Nortel™

networks and complies with applicable IEEE 802.3 standards.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Creates an economical Ethernet-fiber/copper-fiber link for connecting remote sub-networks to larger fiber

optic networks/backbones

Provides connectivity to a user or network segment that is in an isolated area of a large complex or in another

building altogether

LAN-to-LAN connectivity between remote offices

Extend network connectivity to remote areas of stadiums, auditoriums or other venues

Connecting network servers and power users to Gigabit backbone

Connects distant network or devices up to 550m in an existing multimode network

intrl.startech.com

Features

Easy installation and setup in seconds

Compatible with most 3Com™, Cisco™, Lucent™, and Nortel™ networks

Supports IEEE 802.3ab 1000BaseT and IEEE 802.3z 1000BaseSX industry standards

Standard RJ-45 connectors for connecting to UTP media, and LC connector for connecting to fiber media

Supports Half-Duplex and Full-Duplex operating modes up to 2 Gigabits/sec

LED indicators continuously shows operating status of the converter

Compact design and weight makes it portable and unobtrusive to carry

Supports a maximum multimode fiber optic cable distance of 550 meters

Plug and Play installation allows the converters to be connected to a PC, hub or a switch using an auto-

sensing MDI/MDIX port

intrl.startech.com

Technical Specifications

Warranty 2 Years

PoE No

WDM No

Regulatory Approvals FCC Class A & CE Mark C-Tick

Industry Standards IEEE 802.3ab 1000BaseT, IEEE 802.3z 1000BaseSX

Local Unit Connectors 1 - Fiber Optic LC Female

Local Unit Connectors 1 - RJ-45 Female

Maximum Data Transfer Rate 1000Mbps (1Gbps)

Max Transfer Distance 550 m (1804 ft)

Fiber Type Multi Mode

Wavelength 850nm

Fiber Operating Mode Half/Full-Duplex

Auto MDIX Yes

Color Beige

Enclosure Type Steel

Product Length 4.8 in [123 mm]

Product Width 3.4 in [86 mm]

Product Height 0.8 in [20 mm]

Product Weight 24.4 oz [690 g]

LED Indicators 1 - Ethernet Link

LED Indicators 1 - Fiber Duplex Mode

LED Indicators 1 - Fiber Link

LED Indicators 1 - Link Loss Forwarding Mode

LED Indicators 1 - Loopback Testing Mode

LED Indicators 1 - Power

Power Adapter Included Yes

Input Voltage 110 ~ 240 AC

Input Current 0.4A

Output Voltage 12 DC

Output Current 1A

Center Tip Polarity Positive

Operating Temperature 0°C to 50°C (32°F to 122°F)

Storage Temperature -10°C to 70°C (14°F to 158°F)

Humidity 10~90% RH

intrl.startech.com

Shipping (Package) Weight 1.6 lb [0.7 kg]

Included in Package 1 - Ethernet/Fiber Media Converter

Included in Package 2 - Mounting Bracket w/ Screws

Included in Package 1 - Power Adapter

Included in Package 1 - Instruction Manual

Certifications, Reports and Compatibility
