PCI1S550

PCI1S550_LP

PCI2S550

PCI2S550_LP

1/2 Port High-Speed RS-232 PCI Serial Card

1/2 Port Low Prole High-Speed RS-232 PCI Serial Card

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................1

System Requirements .............................................................................................................................. 1

Package Contents ..................................................................................................................................... 1

Installation ..............................................................................................2

Installing the Card ..................................................................................................................................... 2

Installing the Drivers ................................................................................................................................ 2

Verifying Your Installation ...................................................................................................................... 4

Specications ..........................................................................................5

Technical Support ..................................................................................6

Warranty Information ............................................................................6

Instruction Manual

Introduction

Thank you for purchasing a high speed PCI RS-232 serial card from StarTech.com. This

product adds one (PCI1S550, PCI1S550_LP) or two (PCI2S550, PCI2S550_LP) serial ports

to your computer. This product is the perfect way to protect your investment in serial

technology, and works with virtually any peripheral with a serial interface, including

printers, modems, PDAs, and more.

Features

• Adds high speed RS-232 serial ports to your computer

• Complies with the PCI 2.1 specication

• Compatible with most major OS platforms

• Provides transfer rates of up to 115.2 KBits/sec

• Fully Plug and Play compliant for easy setup and conguration

System Requirements

• A computer running DOS, Windows 95/ 98SE/ 2000/ XP(32/64bit)/ Server

2003(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/ Server 2008 R2, Linux, and Mac OS

10.4.x and up Windows XP Embedded/ POS Ready 2009/ Embedded System 2009

OS/ CE 5.0/ CE 6.0

• An available PCI slot (models ending in “_LP” require a low prole PCI slot)

• A CD-ROM or other optical drive (for driver software installation)

Package Contents

• 1 x PCI serial card

• 1 x Installation CD

• 1 x Instruction Manual

WARNING! PCI cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer

case or touching your PCI card. StarTech.com recommends that you wear an anti-static

strap when installing any computer component. If an anti-static strap is unavailable,

discharge yourself of any static electricity build-up by touching a large grounded metal

surface (such as the computer case) for several seconds. Also be careful to handle the

PCI card by its edges and not the gold connectors.

Instruction Manual

Installation

This section will guide you through the installation of your PCI card and the related

software. Please read through the instructions carefully and complete each step in the

order listed.

Installing the Card

1. Make sure that your system is unplugged and you are grounded.

2. Remove the cover of your system (see your computer’s user manual for details, if

necessary) and gently turn your computer onto its side.

3. Locate an empty PCI slot (usually white in color) and remove the metal plate that

covers the rear bracket. You may need a Phillips screwdriver to perform this step.

Retain this screw! You will need it to secure the card later.

4. Gently insert the card into the empty slot, making sure it is rmly seated.

5. Secure the card in place using the screw you removed in Step 3.

6. Connect the port dongle provided to the port on the back of the card.

7. Put your computer case back on.

Installing the Drivers

If you lose your driver disk, these drivers are available as a free download from our

website. Visit www.startech.com and click on the Downloads link for more information.

Windows 95/98/ME

1. Windows will detect that new hardware is installed and launch the Add New

Hardware Wizard. Click Next and choose the Search for the best driver for your

device (Recommended) option. Click Next.

2. On the next screen select only Specify a location. Choose Browse.

3. In the le selection box, double click the win9x folder under CD-ROM Drive (X:).

Click OK. The folder you choose will depend on which Windows version you are

using; the drive letter and name of the drive where the CD is located may depend

on your system conguration.

4. The le location box under Specify a location will now contain the path to the les.

Click Next.

5. The Wizard will inform you that “Windows is now ready to install the best driver

for this device...” Click Next. The Wizard will complete the installation. Click Finish.

Instruction Manual

Windows 2000/XP

1. Windows will launch the Add New Hardware Wizard. Click Next.

2. Choose the Search for a suitable driver... option and click Next.

3. Check only the CD-ROM drives option. Ensure the installation disk is inserted in the

oppy drive. Click Next..

4. Windows will display a message stating that “Windows has found a driver for this

device”. Click Next. Choose Yes or Continue Anyway if you are warned that the driver

le has not been digitally signed.

5. WIndows will display a message that states “Windows has nished installing

software for this device”. Click Finish.

6. Windows will continue to detect and install any remaining new devices. If the Add

New Hardware Wizard is launched again, repeat steps 1 through 5 from above.

Windows Vista/7

1. When the Found New Hardware window appears on the screen, click on the “Locate

and install drivers software (recommended)” option. If prompted to search online,

select the “Don’t search online” option.

2. When prompted to insert the disc, insert the Driver CD that came with the card, into

your CD/DVD drive and Windows will automatically proceed to search the CD.

3. If a Windows Security dialog window appears, click the “Install this driver software

anyway” option to proceed.

4. Once the driver is installed, click the Close button.

Other Operating Systems

For installation of the serial card’s software under other operating systems (Windows

NTDOS/Windows 3.1, etc.) please consult the documentation contained in the text

le(s) located in the appropriate folder on the installation CD.

Instruction Manual

Verifying Your Installation

Windows 95/98/ME

1. Go to Start > Settings > Control Panel.

2. Double click System.

3. Click the Hardware tab.

4. If the card does not appear with a red x or yellow exclamation point (!) next to it,

Windows has not detected a problem with the installation and the card should

function normally.

Windows 2000/XP

1. Go to Start > Settings > Control Panel.

2. Double click System.

3. Click the Hardware tab and choose Device Manager.

4. If the card does not appear with a red x or yellow exclamation point (!) next to it,

Windows has not detected a problem with the installation and the card should

function normally.

Instruction Manual

Specications

Connector(s) DB9 male (1) PCI1S550, PCI1S550_LP

DB9 male (2) PCI2S550, PCI2S550_LP

Serial Interface RS-232

Bus Interface 32-bit PCI, ver 2.1 compliant

OS Compatibility

DOS, Windows 95/ 98SE/ 2000/ XP(32/64bit)/

Server 2003(32/64bit)/ Vista(32/64bit)/

7(32/64bit)/ Server 2008 R2, Linux, and Mac

OS 10.4.x and up Windows XP Embedded/ POS

Ready 2009/ Embedded System 2009 OS/ CE

5.0/ CE 6.0

Data Transfer Rate 115.2Kbps

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.

Altri manuali per PCI1S550

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali StarTech.com Scheda PCI

StarTech.com

StarTech.com PEX4SFF8643 Manuale utente

StarTech.com

StarTech.com PCI2S1P2 Manuale utente

StarTech.com

StarTech.com PEXUSB321C Manuale utente

StarTech.com

StarTech.com PCI1394B_3 Manuale utente

StarTech.com

StarTech.com PCISAT2IDE1 Manuale utente

StarTech.com

StarTech.com PCISOUND5LP Manuale utente

StarTech.com

StarTech.com ST1000SPEX Manuale utente

StarTech.com

StarTech.com PEXSATA22I Manuale utente

StarTech.com

StarTech.com PCI4S550N Manuale utente

StarTech.com

StarTech.com PEX2S953LP Manuale utente

StarTech.com

StarTech.com 21050-PC-SERIAL-CARD Manuale utente

StarTech.com

StarTech.com PEXMSATA3422 Manuale utente

StarTech.com

StarTech.com PCI2S485LP Manuale utente

StarTech.com

StarTech.com PCISCSI2 Manuale utente

StarTech.com

StarTech.com PCI1394_2 Manuale utente

StarTech.com

StarTech.com ST10GSPEXNB Manuale utente

StarTech.com

StarTech.com PEXSATA24E Manuale utente

StarTech.com

StarTech.com PEX1P Manuale utente

StarTech.com

StarTech.com PEX1394B3 Manuale utente

StarTech.com

StarTech.com USB32HDCAPRO Manuale utente

StarTech.com

StarTech.com 0065030887755 Manuale utente

StarTech.com

StarTech.com PEXUSB312C2 Manuale utente

StarTech.com

StarTech.com PEX1S1P950 Manuale utente

StarTech.com

StarTech.com 8STPEXUSB3S44V Manuale utente

Manuali Scheda PCI popolari di altre marche

ERMA

ERMA SSI 1417 Manuale utente

SIIG

SIIG CyberSerial Dual PCI Istruzioni per il montaggio

Moxa Technologies

Moxa Technologies CP-102E Manuale utente

I-Bus

I-Bus IBC2602 Manuale utente

Exsys

Exsys EX-60102 Manuale utente

Chelsio Communications

Chelsio Communications T5 Series Manuale utente

Conrad Electronic

Conrad Electronic 97 46 71 Manuale utente

Micro Innovations

Micro Innovations USB650A Manuale utente

KTI Networks

KTI Networks KF-310 Manuale utente

Asus

Asus SpaceLink WL230 Manuale utente

SIIG

SIIG SC2475 Manuale utente

TRENDnet

TRENDnet TEW-703PI Manuale utente

Belkin

Belkin F5D7000F Manuale utente

Pericom

Pericom PI7C7100 Manuale utente

ADLINK Technology

ADLINK Technology cPCI-3548 Manuale utente

Digium

Digium TE200 Series Manuale utente

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manuale utente

Western Digital

Western Digital FireWire PCI Adapter Manuale utente
