StarTech.com PEX2S553B Manuale del sistema

2 Port RS232 PCI Express Serial Card w/ Breakout Cable

StarTech ID: PEX2S553B

The PEX2S553B 2-Port PCI Express Serial Card w/ Breakout Cable lets you add two RS232 serial ports using a

single PCIe expansion slot. With the included break-out cable, you can easily add two ports to a single low

profile slot.

The PCIe serial card features a native single-chip design that provides optimum reliability and speed, reducing

the CPU load by up to 48% over conventional bridge-chip serial cards - a cost-effective solution for connecting

legacy serial devices to PCIe enabled computers.

The multiport PCIe Serial Adapter includes both full and low-profile/half-height brackets for compatibility with

standard and small form factor computers, and is compatible with a broad range of operating systems, including

Windows® 7/Server 2008 R2, 2003/Vista/XP (32 and 64 bit), Linux Kernel 2.6.11 and up, as well as MAC OS

10.5 and above.

This product is a replacement for our PEX2S552B card.

Backed by a StarTech.com lifetime warranty and free lifetime technical support.

intrl.startech.com

Applications

Point-of-Sale (POS credit/debit card readers, receipt printers, bar code scanners, cash registers, scales)

Manufacturing (CNC machinery, process control equipment, bar code scanners, serial printers)

Connect specialized parallel and serial devices like printers, scanners, ISDN terminal adapters, CD-

R/RWs, Zip® drives and memory card readers

Environmental Control (lighting, temperature, clocks)

Entertainment (video lottery terminals, slot machines, gaming systems)

Healthcare (patient monitoring equipment, nurses' stations, modems)

Security (UPS control, access key panels, video cameras, card readers, modems)

Hospitality/Restaurant (serial printers, bar code scanners, keyboard, mouse, receipt printer, credit/debit

card reader)

Consumer (modems, PDAs, digital cameras, printers)

ISDN Networking

Features

Full profile and low profile/half-height brackets included

Native single-chip design

Single-Lane (x1) PCI-Express with throughput up to 2.5Gbps

On-chip 256-byte depth FIFO in transmit/receive path of each port

Supports hardware and software flow control

Automated out-of-band flow control using CTS/RTS and DSR/DTR

Supports data transfer rates up to 250Kbps on each port

Compliant with PCI Express base specifications revision 1.0a

intrl.startech.com

Technical Specifications

Warranty Lifetime

Card Type Standard Profile (LP bracket incl.)

Ports 2

Interface serial

Bus Type PCI Express

Chipset ID ASIX/MosChip - MCS9922CV-AA

Connector

Type(s)

1 - PCI Express x1 Male

External Ports 2 - DB-9 (9 pin; D-Sub) Male

Maximum Data

Transfer Rate

250Kbps

Data Bits 5, 6, 7, 8

FIFO 256-byte depth FIFO

Flow Control Hardware and Software

Parity Even, Odd, None, Space, and Mark

Stop Bits 1, 2

OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), XP Embedded, POS Ready 2009,

Embedded System 2009, CE 6.0/5.0, 2000, 98SE, 95, DOS

Windows® Server 2008 R2, 2003(32/64)

Mac OS 10.4 and up (Tested up to 10.8)

Microsoft WHQL

Certified

Yes

Product Length 3.2 in [81 mm]

Product Width 0.6 in [14 mm]

Product Height 2.7 in [68.5 mm]

Product Weight 1.6 oz [46 g]

Operating

Temperature

0°C to 70°C (32°F to 158°F)

Storage

Temperature

-40°C to 85°C (-40°F to 185°F)

Humidity 5~85% RH

Shipping

(Package)

Weight

264

Included in

Package

1 - 2 Port PCI-Express RS-232 Serial Card

intrl.startech.com

Included in

Package

1 - Breakout cable

Included in

Package

1 - Low profile bracket

Included in

Package

1 - Driver CD

Included in

Package

1 - Instruction Manual

Certifications, Reports and Compatibility
