StarTech.com USB32VGCAPRO Manuale utente

User Manual revision: 05/11/2021

For the latest information, technical specications, and support for

this product, please visit www.StarTech.com/USB32VGCAPRO.

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

USB32VGCAPRO

USB 3.0 Capture Device for VGA Video

*actualproduct may vary from photos

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Table of Contents

Product diagram ....................................................................................1

Front view .................................................................................................................................................... 1

Rear view...................................................................................................................................................... 1

Introduction............................................................................................2

Packaging contents.................................................................................................................................. 2

System requirements............................................................................................................................... 2

Software installation .............................................................................3

Driver installation for Windows computers..................................................................................... 3

Hardware installation............................................................................3

Warranty information............................................................................4

Product diagram

Front view

Rear view

VGA In

port Audio In

port

USB

port VGA Out

port

Introduction

Packaging contents

• 1 x USB 3.0 capture device for VGA video

• 1 x USB 3.0 cable

• 1 x User Manual

System requirements

• 1 x VGA video source with cabling

• 1 x VGA display with cabling (optional for video passthrough)

• 1 x computer system with minimum:

CPU Intel® Core™ i3

Memory: 4 GB

Video: 1024×768, DirectX® 9.0c compatible graphics card

Operating system: Windows® 10 (32/64), 8 / 8.1 (32/64bit), 7 (32/64bit), Vista

(32/64), XP (32/64)

• Operating system requirements are subject to change. For the latest requirements,

please visit www.StarTech.com/USB32VGCAPRO

Software installation

To use the video adapter in USB mode, ensure the software installation steps have

been completed before you connect the adapter to your computer.

Driver installation for Windows computers

Note: you will need to restart your computer during the driver installation process.

Please be sure to save any unsaved material before you install the drivers.

1. Download the latest drivers from the StarTech.com website:

http://www.StarTech.com/USB32VGCAPRO

2. The drivers will be compressed in a .zip folder. Extract the contents of the folder

to a location on your computer that’s easy to access, such as your Desktop or

Downloads folder.

3. Once the les have been extracted, open the Windows folder, and launch the

Setup(.exe) le. This installer le will install the capture device drivers.

4. Follow the on-screen prompts to complete the installation, and when instructed to

do so, restart your computer.

Hardware installation

1. Connect a VGA cable (sold separately) to the output port on your video source

device and to the video adapter’s VGA In port.

2. Connect the included USB cable to the video adapter’s USB port, and to a USB port

on your computer system.

3. Your computer will automatically detect the USB drivers for the video adapter and

install them.

4. To preview the video source that’s being sent through the capture device, by

connecting a VGA cable (not included) to the video adapter’s VGA Out port and to

a VGA display.

Quick start guide

Warranty information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship

for the periods noted, following the initial date of purchase. During this period,

the products may be returned for repair, or replacement with equivalent

products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan.

It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old

and new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they

need to go. Just talk to one of our tech advisors or visit our website. You’ll be

connected to the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products

and to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and

technology parts. StarTech.com was founded in 1985 and has operations in the

United States, Canada, the United Kingdom and Taiwan servicing a worldwide

market.

Reviews

Share your experiences using StarTech.com products, including product

applications and setup, what you love about the products, and areas for

improvement.

FR: fr.startech.com

DE: de.startech.com

ES: es.startech.com

NL: nl.startech.com

IT: it.startech.com

JP: jp.startech.com

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

StarTech.com Ltd.

45 Artisans

Crescent

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Road

Brackmills,

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South

Hamilton Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT

Hoofddorp

The Netherlands
